Setting functions
8.7 Application-specific functions
Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
285
Table 8- 29 Advanced settings
p1201
Flying restart enable signal source
(factory setting: 1)
Defines a control command, e.g. a digital input, through which the flying restart function
p1202
Flying restart search current
(factory setting for Power Module PM230: 90%. Factory
setting for PM240, PM250, PM260 and PM330: 100%)
Defines the search current with respect to the magnetizing current (r0331), which flows
in the motor during the flying restart.
p1203
Flying restart search speed factor
(factory setting for Power Module PM230: 150%.
Factory setting for PM240, PM250, PM260 and PM330: 100%)
The value influences the speed with which the output frequency is changed during the
flying restart. A higher value results in a longer search time.
If the inverter does not find the motor, reduce the search speed (increase p1203).
The automatic restart includes two different functions:
● The inverter automatically acknowledges faults.
● After a fault occurs or after a power failure, the inverter automatically switches-on the
motor again.
The inverter interprets the following events as power failure:
● The inverter signals fault F30003 (DC-link undervoltage), as the line supply voltage of the
inverter has briefly failed.
● The inverter power supply has failed for a long enough time so that the inverter has been
switched-off.
Injuries from the automated machine restart
When the "automatic restart" function is active (p1210 > 1), the motor automatically
starts after a power failure. The movements that the machine executes may result in
serious injuries.
• Block the machine to prevent unintentional access.
• Before working on the machine switch the automatic restart mechanism off.
