Siemens SINAMICS G120 - 12 Technical Data; Technical Data for CU230 P-2

Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
373
Technical data
12
12.1
Technical data for CU230P-2
Feature
Data / explanation
Order numbers
6SL3243-0BB30-1CA3
With CANopen interface
6SL3243-0BB30-1HA3
6SL3243-6BB30-1HA3
With RS485 interface for the following protocols:
• USS
• Modbus RTU
• BACnet MS/TP
• P1
6SL3243-0BB30-1PA3
With PROFIBUS interface.
6SL3243-0BB30-1FA0
With PROFINET interface.
Operating voltage You have two options for the Control Unit power supply:
• Supply from the Power Module
• External supply via terminals 31 and 32 with 20.4 ... 28.8 VDC.
Use a power supply with (PELV = Protective Extra Low Voltage according to
EN 61800-5-1), Class 2.
The 0 V of the power supply must be connected low-resistant with the PE of the system.
Current consumption Max 0.5 A
The current consumption can be higher if the Control Unit supplies external components.
Power loss
5.0 W
Output voltages
+24 V out (terminal 9), 18 V … 28.8 V, max. 100 mA
+10 V out (terminals 1 and 35), 9.5 V … 10.5 V, max. 10 mA
Setpoint resolution
0.01 Hz
Digital inputs 6 (DI 0 … DI 5)
• Low < 5V, high > 11V
• Electrically isolated
• 30 V maximum input voltage
• 5.5 mA current consumption
• SIMATIC-compatible
• PNP/NPN switchable
• 10 ms response time for debounce time p0724 = 0.
