Siemens SINAMICS G120 - Power-Dependent Data, PM240

Technical data
12.2 Technical data, Power Modules
Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
391
12.2.2.2
Power-dependent data, PM240
Note
The given input currents are valid for operation without a line reactor for a line voltage of 400
V with Vk = 1
% referred to the rated power of the inverter. If a line reactor is used, the
specified values are reduced by a few percent.
Table 12- 20 PM240, IP20, frame sizes A, 3 AC 380 V … 480 V
Order No. - without filter
6SL3224-…
…0BE13-7UA0
…0BE15-5UA0
…0BE17-5UA0
Rated/LO power
Rated/LO input current
Rated/LO output current
0.37 kW
1.6 A
1.3 A
0.55 kW
2.0 A
1.7 A
0.75 kW
2.5 A
2.2 A
HO power
HO input current
HO output current
0.37 kW
1.6 A
1.3 A
0.55 kW
2.0 A
1.7 A
0.75 kW
2.5 A
2.2 A
Fuse according to UL (from SIEMENS)
Fuse according to UL (Class J, K-1 or K-5)
3NE1813-0, 16 A
10 A
3NE1813-0, 16 A
10 A
3NE1813-0, 16 A
10 A
Power loss 0.097 kW 0.099 kW 0.102 kW
Required cooling air flow 4.8 l/s 4.8 l/s 4.8 l/s
Cross section of line and motor cables 1 … 2.5 mm
2
18 … 14 AWG
1 … 2.5 mm
2
18 … 14 AWG
1 … 2.5 mm
2
18 … 14 AWG
Tightening torque for line and motor cables
0.5 Nm / 4 lbf in
0.5 Nm / 4 lbf in
0.5 Nm / 4 lbf in
Weight 1.2 kg 1.2 kg 1.2 kg
Table 12- 21 PM240, IP20, frame sizes A, 3 AC 380 V … 480 V
Order No. - without filter
6SL3224-…
…0BE21-1UA0
…0BE21-5UA0
Rated/LO power
Rated/LO input current
Rated/LO output current
1.1 kW
3.9 A
3.1 A
1.5 kW
4.9 A
4.1 A
HO power
HO input current
HO output current
1.1 kW
3.8 A
3.1 A
1.5 kW
4.8 A
4.1 A
Fuse according to UL (from SIEMENS)
Fuse according to UL (Class J, K-1 or K-5)
3NE1813-0, 16 A
10 A
3NE1813-0, 16 A
10 A
Power loss
0.108 kW
0.114 kW
Required cooling air flow
4.8 l/s
4.8 l/s
Cross section of line and motor cables 1 … 2.5 mm
2
18 … 14 AWG
1 … 2.5 mm
2
18 … 14 AWG
Tightening torque for line and motor cables
0.5 Nm / 4 lbf in
0.5 Nm / 4 lbf in
Weight
1.1 kg
1.1 kg
