Siemens SINAMICS G120 - Power-Dependent Data, PM250

Technical data
12.2 Technical data, Power Modules
Inverter with CU230P-2 Control Units
402 Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
12.2.4.3
Power-dependent data, PM250
Table 12- 36 PM250, IP20, Frame Sizes C, 3 AC 380 V … 480 V
Order No. - Filtered
6SL3225-…
0BE25-5AA0
0BE27-5AA0
0BE31-1AA0
Rated / LO power
Rated / LO input current
Rated / LO Output current
7.5 kW
18 A
18 A
11 kW
25 A
25 A
15 kW
32 A
32 A
HO power
HO input current
HO output current
5. 5 kW
13.2 A
13.2 A
7.5 kW
19 A
19 A
11 kW
26 A
26 A
Fuse
20 A, Class J
32 A, Class J
35 A, Class J
Power losses
0.24 kW
0.30 kW
0.31 kW
Required cooling air flow
38 l/s
38 l/s
38 l/s
Cross section of line and motor cable 2.5 … 10 mm
2
14 … 8 AWG
4.0 … 10 mm
2
12 … 8 AWG
4.0 … 10 mm
2
12 … 8 AWG
Tightening torque for line and motor cable
2.3 Nm / 20 lbf in
2.3 Nm / 20 lbf in
2.3 Nm / 20 lbf in
Weight
7.5 kg
7.5 kg
7.5 kg
Table 12- 37 PM250, IP20, Frame Sizes D, 3 AC 380 V … 480 V
Order No. - Filtered
6SL3225-…
0BE31-5AA0
0BE31-8AA0
0BE32-2AA0
Rated / LO power
Rated / LO input current
Rated / LO Output current
18.5 kW
36 A
38 A
22 kW
42 A
45 A
30 kW
56 A
60 A
HO power
HO input current
HO output current
15 kW
30 A
32 A
18.5 kW
36 A
38 A
22 kW
42 A
45 A
Fuse according to IEC
Fuse according to UL
3NA3820
50 A, Class J
3NA3822
63 A, Class J
3NA3824
80 A, Class J
Power losses
0.44 kW
0.55 kW
0.72 kW
Required cooling air flow
22 l/s
22 l/s
39 l/s
Cross section of line and motor cable 10 … 35 mm
2
7 … 2 AWG
10 … 35 mm
2
7 … 2 AWG
16 … 35 mm
2
6 … 2 AWG
Tightening torque for line and motor cable
6 Nm / 53 lbf in
6 Nm / 53 lbf in
6 Nm / 53 lbf in
Weight
15 kg
15 kg
16 kg
