Setting functions
8.7 Application-specific functions
Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
303
Table 8- 31 Parameters to set the multi-zone control:
Technology controller enable
Set technology controller as main setpoint
P31020 = …
Multi-zone control interconnection
(factory setting: 0)
A subsequent parameterization is performed by activating or deactivating the multi-
Subsequent connection for p31020 = 1 (activate multi-
zone control)
Subsequent connection
for p31020 = 0
(deactivate multi-zone
p31023[0] = 0755.0 (AI0)
p31023[2] = 0755.1 (AI1)
p31026[0] = 0755.2 (AI2)
p31026[1] = 0755.3 (AI3)
p2253 = 31024 (setpoint output, technology controller)
p2264 = 31027 (actual value output, technology
controller)
p31023[0] = 0
p31023[2] = 0
p31026[0] = 0
p31026[1] = 0
p2253 = 0
p2264 = 0
P31021 = …
Configuration of multi-zone control
• 0 = Setpoint 1 / several actual values (factory setting)
• 1 = Two zones / maximum value setting
• 2 = Two zones / minimum value setting
p31022 = …
Processing of actual values for multi-zone control
(only for p31021 = 0)
Possible values: 0 … 11 (factory setting: 0)
p31023[0 … 3]
= …
Setpoints for multi-zone control
Parameters for selecting the source for setpoints in multi-zone control
r31024 = …
Multi-zone control setpoint output for technology controller
p31025 = …
Switching from day to night mode for multi-zone control
Parameters for selection of the source for switching between day and night
operation by the multi-zone control (factory setting: 0)
p31026[0 … 2]
= …
Actual values for multi-zone control
Parameters for selecting the source for actual values of the multi-zone control
r31027 = …
Multi-zone control actual value output for the technology controller
CO parameters
Note
If you deactivate the multi
-zone control, the inverter resets the switch on its analog inputs to
