Setting functions
8.7 Application-specific functions
Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
317
p2394
Energy-saving mode boost duration
0 (factory setting) … 3599 s. Before the inverter switches over into the energy-
saving mode, the motor is accelerated for the time set in p2394 according to
the acceleration ramp, but not to more than the speed set in P2395.
x x
p2395
Energy-saving mode boost speed
0 (factory setting) … 21000 rpm. Before the inverter switches over into the
energy-saving mode, the motor is accelerated for the time set in p2394
according to the acceleration ramp, but not to more than the speed set in
p2395.
Caution:
The boost may not result in any overpressure or overrun.
x x
p2396
Maximum energy-saving mode shutdown time
0 (factory setting) … 863999 s. At the latest when this time expires, the
inverter switches to normal operation and is accelerated up to the start speed
(p1080 + p2390). If the inverter is switched to normal operation in advance,
the shutdown time is reset to the value set in this parameter.
With p2396 =
0, automatic changeover to normal operation after a certain time
is deactivated.
x x
Status of the energy-saving mode
Display of the setpoint/actual value deviation of the technology controller
r2397
Actual energy-saving mode output speed
Actual boost speed before the pulses are inhibited or the actual start speed after restart.
r2399
Energy-saving mode status word
00 Energy-saving mode enabled (P2398 <> 0)
01 Energy-saving mode active
02 Energy-saving mode delay time active
03 Energy-saving mode boost active
04 Energy-saving mode motor switched off
05 Energy-saving mode motor switched off, cyclic restart active
06 Energy-saving mode motor restarts
07 Energy-saving mode supplies the total setpoint of the ramp-function generator
08 Energy-saving mode bypasses the ramp-function generator in the setpoint channel
