Description
3.4 System components for the Power Modules
Inverter with CU230P-2 Control Units
38 Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
Braking resistors for PM240
Power Module
Braking Module
Braking resistor
6SL3224-…
Power
6SL3300-…
Power
FSA …0BE13-7UA0,
…0BE15-5UA0,
…0BE17-5UA0,
…0BE21-1UA0,
…0BE21-5UA0
0.37 kW … 1.5 kW --- --- 6SE6400-4BD11-0AA0
FSB …0BE22-2A0,
…0BE23-0A0,
…0BE24-0A0
2.2 kW … 4.0 kW --- --- 6SL3201-0BE12-0AA0
FSC …0BE25-5A0,
…0BE27-5A0
…0BE31-1A0
7.5 kW … 15.0 kW --- --- 6SE6400-4BD16-5CA0
FSD …0BE31-5A0,
…0BE31-8A0,
…0BE32-2A0
18.5 kW … 30 kW --- --- 6SE6400-4BD21-2DA0
FSE …0BE33-0A0,
…0BE33-7A0
37 kW … 45 kW --- --- 6SE6400-4BD22-2EA1
FSF …0BE34-5A0,
…0BE35-5A0,
…0BE37-5A0
55 kW … 90 kW --- --- 6SE6400-4BD24-0FA0
…0BE38-8UA0,
…0BE41-1UA0
110 kW … 132 kW --- --- 6SE6400-4BD26-0FA0
FSGX
…0XE41-3UA0
160 kW
---
---
6SL3000-1BE31-3AA0
…0XE41-6UA0,
…0XE42-0UA0
200 kW … 250 kW …1AE32-5AA0 6SL3000-1BE32-5AA0
Braking resistors for PM240-2
Power Module 6SL321-…
Power
Braking resistor
FSA …1PE11-8L0, …1PE12-3L0,
…1PE13-2L0
0.55 kW … 1.1 kW 6SL3201-0BE14-3AA0
…1PE14-3L0, …1PE16-1L0,
…1PE18-0L0
1.5 kW … 3.0 kW 6SL3201-0BE21-0AA0
Braking Modules and braking resistors for PM330
Power Module
Braking Module
Braking resistor
6SL3310-…
Power
6SL3760-…
Power
6SE7032-…
GX …1PE33-0AA0,
…1PE33-7AA0
160 kW … 200 kW …1AE32-6AA0 50 kW …-5FS87-2DC0
