Siemens SINUMERIK 840D Commissioning Manual

Expanding the Operator Interface (BE1) 08/2005
8 Terms, Tables, Lists, Examples
© Siemens AG, 2005. All rights reserved
BE1/8-198 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Service Explanation
Parameter
Example
_N_CREATO Create a tool with a specific T number. The following blocks in the active file
system are affected by this PI service:
Tool directory TV: The tool is entered as an existing tool
Tool offsets TO: The first tool edge D1 (with ZERO content) is set up
User edge data TUE: (If available) the first tool edge D1 (with ZERO
content) is set up
User tool data TU: (If available) an empty data block is made available for
the tool
Par1 Tool number 1 to 31999
After the tool with number 55 has been set up in T area 1, a further 2 edges
are created for it. The tool therefore now possesses a total of 3 edges.
PI_SERVICE("_N_CREATO“,55)
PI_SERVICE("_N_CREACE“,55)
PI_SERVICE("_N_CREACE“,55)
_N_DELECE Delete a tool edge. If the T number of an existing tool is entered in
parameter "T Number" of this PI service, then the tool edge for the relevant
tool is deleted (in this case, the parameter "D number, i.e., the number of
edge to be deleted, has a value range of 1-9). If a positive T number is
specified as a parameter and the tool for the T number entered does not
exist, then the PI service is aborted.
If a value of 0 is entered as the T number (model of absolute D numbers),
then the D number values can range from 1- 31999.
If the specified cutting edge does not exist, then the PI service is aborted in
both cases.
Par1 T number of the tool for which the associated tool cutting edge is to be
deleted.
A setting of 0 indicates that there is no reference to a specific tool (absolute
D number).
Par2 Cutting edge number of tool cutting edge that should be deleted.
Value range:
T number == 0 ==> 1 – 31999
T number > 0 ==> 1 –9
The tool edge with number 3 for the tool with number 17 in the current TO
area is deleted.
PI_SERVICE("_N_DELECE“,17,3)

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
