Starting Up HMI Embedded (IM2) 08/2005
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM2/4-78 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
9054 PLC_SYMBOL_FILTER
H05
CR:
- Filter settings for PLC icons REAL 3/4
Adv, Emb Adv: 0, Emb: 0
0 0xFFFF
IMMEDIATE
LY
SW6.3
9055 PLC_ALARM_PICTURE
H05
CR:
- Acknowledgement icon selection for PLC alarms INTEGER 3/4
Adv, Emb Adv: 1, Emb: 1
-1 1
Power On SW6.3
9056
ALARM_ROTATION_CYCLE H05
CR:
- Rotation cycle time for the alarm display INTEGER 3/4
Emb Emb: 0
0 10000
IMMEDIATE
LY
SW6.4
9180 USER_CLASS_READ_TCARR
H04, H05
CR: A2
- Protection level read toolholder offsets BYTE 3/4
Emb Emb: 7
0 7
IMMEDIATE
LY
SW6.1
9181 USER_CLASS_WRITE_TCARR
H04, H05
CR: A2
- Protection level write toolholder offsets BYTE 3/4
Emb Emb: 7
0 7
IMMEDIATE
LY
SW6.1
9182 USER_CLASS_INCH_METRIC
H04, H05
CR: EMB
- Protection level inch/metric switchover BYTE 3/4
Emb Emb: 7
0 7
IMMEDIATE
LY
SW6.2
9183 USER_WRITE_TOOLFRAME
H04, H05
CR:
- Protection level write toolholder BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
SW6.4
9184 USER_WRITE_PARTFRAME
H04, H05
CR:
- Protection level write tool reference point BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
SW6.4
9185 USER_WRITE_WPFRAME
H04, H05
CR:
- Protection level write workpiece reference point BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
SW6.4
9186 USER_WRITE_CYCFRAME
H04, H05
CR:
- Protection level write cycle frame BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
SW6.4
9187 USER_WRITE_TRAFRAME
H04, H05
CR:
- Protection level write transformation frame BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
SW6.4
9188 USER_WRITE_EXTFRAME
H04, H05
CR:
- Protection level write external WO BYTE 3/4
Adv, Emb Adv: 7, Emb: 0
0 7
IMMEDIATE
LY
SW6.4
