Starting Up HMI Embedded (IM2) 08/2005
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM2/4-86 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
9410 TM_LOAD_PLACE
H05
CR: BO
- Number of loading station INTEGER 3/4
OP30, Emb OP30: 0, Emb: 0
*** ***
Power On -
9411 TM_NUM_MAG
H05
CR: BO
- Number of work magazine INTEGER 3/4
OP30, Emb OP30: 0, Emb: 0
*** ***
Power On -
9412 TM_DEFAULT_TOOLSIZE
H05
CR: FBW
- Default for tool size REAL 3/4
Emb Emb: 1111
1111 7777
IMMEDIATE
LY
SW4.1
9414 TM_KIND_OF_TOOLMANAGEMENT
H01, H02,
H05
CR: FBW
- Type of representation of the tool management
0: Old, 1: New (SW 5.2 and higher)
BYTE 3/4
SM, ST, Emb SM: 1, ST: 1,
Emb: 0
0 1
Power On SW5
9415 TM_DEFAULT_TOOLPLACESPEC
H05
CR: FBW
- Default value for location type BYTE 3/4
Emb Emb: 1
1 99
IMMEDIATE
LY
SW4.2
9416 TM_DEFAULT_TOOLTYPE
H05
CR: FBW
- Default for location type REAL 3/4
Emb Emb: 120
100 900
IMMEDIATE
LY
SW4.1
9417 TM_DEFAULT_TOOLSTATE
H05
CR: FBW
- Default for tool status load INTEGER 3/4
Emb Emb: 2
0 255
IMMEDIATE
LY
SW4.1
9419 TM_DEFAULT_DELETE_TOOL
H05
CR: FBW
- Default for tool data auto. Delete BYTE 3/4
Emb Emb: 0
0 1
IMMEDIATE
LY
SW4.1
9420 MA_ONLY_MKS_DIST_TO_GO
H05
CR: FBW
- Distance-to-go display in the Work window
0: Work value
1: Machine value
BYTE 3/4
Emb Emb: 0
0 1
IMMEDIATE
LY
SW4.1
9421 MA_AXES_SHOW_GEO_FIRST
H05
CR: K1
- Actual-value display with leading geo axes BYTE 3/4
Adv, Emb Adv: 1, Emb: 1
0 1
IMMEDIATE
LY
SW 2
9422 MA_PRESET_MODE
H05
CR: K1
- Selecting PRESET/base offset in JOG
0 No Preset, no preset actual value memory
1 PRESET
2 Preset actual value memory
3 Preset actual value memory s. Online help
BYTE 3/4
Adv, Emb Adv: 1, Emb: 1
0 3
IMMEDIATE
LY
SW5
