Commissioning HMI Advanced (IM4) 08/2005
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM4/2-66 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
Commands:
DisableHSK(<SoftkeyList>)
The horizontal softkeys are removed from the softkey list. Individual softkeys can
be separated by commas or specified using softkey ranges <from> - <to>, e.g.,
DisableHSK(1,3,5-7).
Note
Softkeys in the ETC bar cannot be removed.
DisableVSK(<SoftkeyList>)
The vertical softkeys are removed from the softkey list. Individual softkeys can be
separated by commas or specified using softkey ranges <from> - <to>, e.g.,
DisableVSK(1,3,5-7).
DoVSK=<SoftkeyIndex>
The action of the vertical softkey (1-8) is initiated.
Recall(<StatusList>)
On reaching a status from the list the application returns to the calling application.
The statuses can be separated by commas or specified as ranges <from> - <to>,
e.g. Recall(1,5-7,48).
Highlight=<SoftkeyIndex>
The horizontal (1 – 8) or vertical (9 – 16) softkey is displayed with a blue
background when the application is called.
ZuMat=<StatusMatrix>
The status matrix (e.g. dg\dg.zus) transferred is read and replaces the original
status matrix.
RE_GR.INI
[HSoftkeyTexts]
HSK7 = "Special menu" // 20
The creation of OEM applications in HMI Advanced is described in:
References: / HMI Configuring Package /
Please contact your local sales office for the latest electronic documentation.
