Commissioning HMI Advanced (IM4) 08/2005
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM4/2-112 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
sync1
Definition of search string. The following syntax applies:
* Wildcard; text replaced by ´*´ must be the same in all channels.
n Identification by means of a number , e.g., WAITM(*n,1,2,3)
Wait marks can be assigned using this number.
*c Channel number, these numbers does not have to be in the same order
The program coordination channel does not have to be specified.
(e.g.: WAITM(1,*c,*c,*c).
# Channel separators: Text before
separator is searched for in one channel,
Text after
separator is searched in all other channels. These synchronization
marks cannot be synchronized with each other.
sync1_Ico
Associated icon, it must be located in the directory that was specified in IconPath.
sync1_Chans
Here, it can be specified whether the associated synchronization marks will be
searched for in certain channels only. If no entry is made, the search will be carried
out in all channels or in those that are specified if *c was configured.
Example:
M4711 is a synchronization that affects Channel 1, 2, and 6 only. The entry must
be made as follows:
sync2 = M4711
sync2_Ico = clock.bmp
sync2_Chans = 1,2,6
[Old_or_User_Cycles_User]
Machine manufacturers can enter their expansions for their own cycles here.
Examples:
Cycle1 = Cycle*
Cycle1_Type = 1
Cycle1_Ico = cycle.bmp
Cycle2 = Pocket*
Cycle2_Type = 1
Cycle2_Ico = cycle.bmp
...
CycleX
Definition of cycles without graphical support. Subprogram calls can also be
entered here. A language-specific text can also be specified. X stands for a cycle
number, which must be the same over three associated entries.
