08/2005 Commissioning HMI Advanced (IM4)
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
IM4/2-113
Syntax:
CycleX = L100(*
CycleX = L100(* „$85001“
The following is displayed, e.g.
„L100(2,3,4)“
Language-dependent text that is
stored in 85001
CycleX = L100(* „$85001/fixed text“
Language-dependent text that is
stored in 85001 + “/fixed text”
CycleX_Type
Definition of whether cycle is to be displayed as a subblock or a main block.
1: Subblock
0: Main block
CycleX_Ico
Associated icon, it must be located in the directory that was specified in IconPath.
[ProgSupport_User]
Machine manufacturers can enter their expansions for their own cycles here.
Example:
;Programming Support - Siemens Standard
[ProgSupport_Siemens]
NCG_1=CYC82
NCG_2=CYC86
NCG_3=CYC83
NCG_4=CYC84
NCG_5=CYC84_1
NCG_6=CYC840_1
NCG_7=HOL1
NCG_8=HOL2
NCG_9=POS1
NCG_10=WPOS
...
;drilling
[CYC82]
;drilling
NCG_1_Label=NC1
NCG_1_Text=$80854
NCG_1_Level=0
NCG_2_Label=NC2
NCG_2_Text=$80855
NCG_2_Level=0
;reaming
NCG_3_Label=NC3
NCG_3_Text=$80853
NCG_3_Level=0
