Expanding the Operator Interface (BE1) 08/2005
3 Syntax
© Siemens AG, 2005. All rights reserved
BE1/3-90 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Write from OUTPUT method in file
C:\TMP\MESSEN.MPF
END_PRESS
Note
To store the NC code from the OUTPUT method directly in the NC, the path must
be defined as follows:
"/_N_MPF_DIR/_N_MESSEN_MPF"
Note
With the following functions, both with HMI Embedded and with HMI Advanced,
DOS paths (e.g., \MPF.DIR\TEST.MPF) are used.
Activate Program (AP)
The AP (Activate Program) function transfers a file from the passive HMI file
system to the active NC file system. The file is loaded into the NC and enabled and
then deleted in the HMI file system.
With HMI Embedded, this function has the same effect as Set enable.
AP("File")
where:
File Complete path name of HMI file to be transferred
//M(TestGC/"Code generation:")
DEF VAR1 = (R//1)
DEF VAR2 = (R//2)
DEF D_NAME
LOAD
VAR1 = 123
VAR2 = -6
END_LOAD
OUTPUT(CODE1)
"Cycle123(" VAR1 "," VAR2 ")"
"M30"
END_OUTPUT
PRESS(VS1)
D_NAME = "C:\TMP\MESSEN.MPF"
GC("CODE1",D_NAME) ;Write code from OUTPUT method in
;Write file C:\TMP\MESSEN.MPF
END_PRESS
PRESS(HS8)
D_NAME = "\MPF.DIR\MESSEN.MPF"
AP(D_NAME) ;Load file into NC
END_PRESS
