4-12
PDW-700/V1 (E)
O11 '!' LED TOP
GAIN<!> : ON
SHUTTER<!> : ON
WHT PRESET<!> : ON
ATW RUN<!> : ON
EXTENDER<!> : ON
FILTER<!> : OFF
OVERRIDE<!> : ON
‘!’ LED Display (Selecting the conditions to turn on the ‘!’ indicator on VF)
Item Setting Function
GAIN <!> OFF/ON OFF : Does not turn on
ON : Turns on when the GAIN value is other than 0 dB
SHUTTER <!> OFF/ON OFF : Does not turn on
ON : Turns on when the SHUTTER switch is ON
WHITE PRESET <!> OFF/ON OFF : Does not turn on
ON : Turns on when the WHITE BAL switch is set to PRST
ATW RUN <!> OFF/ON OFF : Does not turn on
ON : Turns on when ATW is used
EXTENDER <!> OFF/ON OFF : Does not turn on
ON : Turns on when the lens extender is used
FILTER <!> OFF/ON OFF : Does not turn on
ON : Turns on when the filter knob is set to the setting other than ND:1
OVERRIDE <!> OFF/ON OFF : Does not turn on
ON : Turns on when the reference value of the auto iris is other than
the standard value
