4-14
PDW-700/V1 (E)
MARKER 2 Display (Setting the MARKER-related items)
Item Setting Function
USER BOX OFF/ON Turns ON/OFF the BOX cursor display
USER BOX WIDTH 3 to 479 Sets the horizontal width of the BOX cursor
USER BOX HEIGHT 3 to 269 Sets the vertical width of the BOX cursor
USER BOX H POS _477 to 476
*
Sets the BOX cursor center position (horizontal position)
USER BOX V POS _267 to 266
*
Sets the BOX cursor center position (vertical position)
CENTER H POS _480 to 479 Sets the CENTER MARKER position (horizontal position)
CENTER V POS _270 to 269 Sets the CENTER MARKER position (vertical position)
ASPECT SAFE ZONE OFF/ON Turns ON/OFF the SAFETY ZONE MARKER display with
respect to the ASPECT MARKER
ASPECT SAFE AREA 80%/90%/92.5%/95% Selects the ranges of the SAFETY ZONE MARKER display
with respect to the ASPECT MARKER
* : Range of this setting is different depending upon the above USER BOX WIDTH/HEIGHT setting.
GAIN SW Display (Setting GAIN)
Item Setting Function
GAIN LOW _6/_3/0/3/6/9/12/18/24/30/36/42 dB Sets the gain value when the GAIN switch is set to
the “L” position
GAIN MID _6/_3/0/3/6/9/12/18/24/30/36/42 dB Sets the gain value when the GAIN switch is set to
the “M” position
GAIN HIGH _6/_3/0/3/6/9/12/18/24/30/36/42 dB Sets the gain value when the GAIN switch is set to
the “H” position
GAIN TURBO _6/_3/0/3/6/9/12/18/24/30/36/42 dB Sets the gain value of the TURBO GAIN switch
TURBO SW IND OFF/ON Turns ON/OFF the function that disables L/M/H of
the GAIN switch while the TURBO GAIN is being
selected
SHOCKLESS GAIN
*
OFF/ON Turns ON/OFF the shockless gain
* : This does not appear when SYSTEM LINE is set to 720, SYSTEM FREQUENCY is set to 59.9P, and SCAN MODE is set to 23.9P.
O13 MARKER 2 TOP
USER BOX : OFF
USER BOX WIDTH : 240
USER BOX HEIGHT : 135
USER BOX H POS : 0
USER BOX V POS : 0
CENTER H POS : 0
CENTER V POS : 0
ASPECT SAFE ZONE: OFF
ASPECT SAFE AREA: 90%
O14 GAIN SW TOP
GAIN LOW : 0dB
GAIN MID : 6dB
GAIN HIGH : 12dB
GAIN TURBO : 42dB
TURBO SW IND : OFF
SHOCKLESS GAIN : OFF
To Next Page
