VF SETTING display (Setting VF)
Item Setting Function
ZEBRA OFF/ON Turns ON/OFF all the zebra display
*1
ZEBRA SELECT 1/2/BOTH Selects the zebra pattern type
ZEBRA1 DET LVL 20% to 107% Sets the ZEBRA1 display level (center value)
ZEBRA1 APT LVL 1% to 20% Sets the ZEBRA1 aperture level (center value)
ZEBRA2 DET LVL 52% to 109% Sets the ZEBRA2 display level (lower limit value)
VF DETAIL LEVEL (_99 to 99) Sets the amount of details of the VF picture
(Details of the main line video output remain unchanged)
VF ASPECT (SD)
*2
AUTO/16:9 Specifies whether to set the viewfinder screen and LCD
monitor aspect ratio automatically or to set it to 16:9
When “16:9” is selected, then the screen is always displayed
as a 16:9 screen (before being cut out to 4:3), even when
ASPECT RATIO (SD) is set to “4:3”
*1 : When you use the viewfinder which is not equipped with the ZEBRA switch, turns the display on or off using this item. When you use
the viewfinder with the ZEBRA switch, the most recent operation of the ZEBRA switch and this menu operation is effective.
*2 : Displayed only when REC FORMAT is set to IMX50/40/30 or DAVCAM.
O15 VF SETTING TOP
ZEBRA : OFF
ZEBRA SELECT : 1
ZEBRA1 DET LVL : 70%
ZEBRA1 APT LVL : 10%
ZEBRA2 DET LVL : 100%
VF DETAIL LEVEL : 0
VF ASPECT (SD) : AUTO
To Next Page
