4-22
PDW-700/V1 (E)
When IMX50/40/30/DVCAM is selected in REC FORMAT
Item Setting Function
ASPECT RATIO(SD) 16:9/4:3 Sets the aspect ratio
AU DATA LEN (IMX)
*
16bit/24bit Sets the record format of audio
* : Displayed only when REC FORMAT is set to IMX50/40/30.
When 720 is selected in SYSTEM LINE
Item Setting Function
SYSTEM FREQUENCY
*1
59.9P (NTSC AREA) Sets the format when the power is turned on next
50P (PAL AREA) time
SCAN MODE
*2
59.9P/23.9P Sets the camera shooting frequency
When SCAN MODE is set to 23.9P, the video output
signals and video recording signals of this unit are
59.9 Hz signals after 2-3 pulldown
REC FORMAT See the right column Sets the recording format
Setting value :
HD422 50/HD420 HQ/HD420 SP/(IMX 50/IMX 40/
IMX 30/DVCAM)
Setting value in ( ) can be selected when CBKZ-MD01
SD Record and Playback Software is installed
(Cannot be selected when SYSTEM LIE is set to 720,
and SCAN MODE is set to 23.9P)
COUNTRY
*1
NTSC(J)AREA/NTSC AREA NTSC(J)AREA : NTSC area (Japan)
/PAL AREA NTSC AREA : NTSC area (for areas other than Japan)
PAL AREA : PAL area
*1 : The unit must be restarted to enable changes to this setting.
*2 : Displayed only when SYSTEM LINE is set to 720 and SYSTEM FREQUENCY is set to 59.9P.
REC FORMAT : IMX 50
ASPECT RATIO(SD): 16:9
AU DATA LEN(IMX): 16bit
COUNTRY : NTSC(J)AREA
O24 FORMAT TOP
SYSTEM LINE : 720
SYSTEM FREQUENCY: 59.9P
SCAN MODE : 59.9P
REC FORMAT : HD422 50
COUNTRY : NTSC(J)AREA
