4-25
PDW-700/V1 (E)
SELECT FUNCTION Display
**
**
*
(LETTER BOX/FOCUS MAG function ENABLE/DISABLE)
* : This does not appear when SYSTEM LINE is set to 1080 and SYSTEM FREQUENCY is set to 23.9P.
Item Setting Function
LETTER BOX DISABLE/ENABLE Enable the selection of “LETTR” (LETTER BOX) in the
DOWN CON MODE item on the OUTPUT 2 page
n
Breakup may occur in output signals and in the video and audio
of this unit for about 5 to 10 seconds immediately after this
setting is changed.
FOCUS MAG DISABLE/ENABLE Enable the assignment of the FOCUS MAG function to the
ASSIGN switches
n
Breakup may occur in output signals and in the video and audio
of this unit for about 5 to 10 seconds immediately after this
setting is changed.
HD
→
SD PHASE 0H Display only Displayed only when LETTER BOX and FOCUS MAG is set to
SYNCRO “DISABLE”
When ENABLE is selected in LETTER BOX or FOCUS MAG
Item Setting Function
HD
→
SD PHASE Display only Displayed only when LETTER BOX is set to “ENABLE”, or
DELAYED when FOCUS MAG is set to “ENABLE”
n
In these states, the phases of HD output and SD output from
this unit do not match.
REF
→
HD-Y PHASE Display only Displayed only when FOCUS MAG is set to “ENABLE”
DELAYED n
In this state, the phase of HD-Y output from this unit does not
match the phase of the GENLOCK IN signal. When multiple
PDW-700 units are daisy chained via this unit inter-system
phases do not match.
O29 SELECT FUNCTION TOP
LETTER BOX : DISABLE
FOCUS MAG : DISABLE
HD SD PHASE 0H SYNCRO
→
O29 SELECT FUNCTION TOP
LETTER BOX : DISABLE
FOCUS MAG : ENABLE
HD SD PHASE DELAYED
REF HD-Y PHASE DELAYED
→
→
To Next Page
