4-35
PDW-700/V1 (E)
MTX LINEAR Display (Setting user-set matrix)
Item Setting Function
MATRIX OFF/ON Turns ON/OFF the linear matrix and user-set matrix functions
MATRIX (USER) OFF/ON Turns ON/OFF the user-set linear matrix function
MATRIX (PRESET) OFF/ON Turns ON/OFF the preset matrix function
MATRIX (PRST) SEL 1/2/3/4/5/6 Selects the preset matrix
1 : equivalent to SMPTE 240M 2 : equivalent to ITU-709
3 : equivalent to SMPTE WIDE 4 : equivalent to NTSC
5 : equivalent to EBU 6 : equivalent to ITU-601
MATRIX (USER) R-G (_99 to 99) Sets the R-G user-set matrix coefficients
MATRIX (USER) R-B (_99 to 99) Sets the R-B user-set matrix coefficients
MATRIX (USER) G-R (_99 to 99) Sets the G-R user-set matrix coefficients
MATRIX (USER) G-B (_99 to 99) Sets the G-B user-set matrix coefficients
MATRIX (USER) B-R (_99 to 99) Sets the B-R user-set matrix coefficients
MATRIX (USER) B-G (_99 to 99) Sets the B-G user-set matrix coefficients
MTX MULTI Display (Setting multi matrix)
Item Setting Function
MATRIX OFF/ON Turns ON/OFF the linear matrix and multi matrix correction functions
MATRIX (MULTI) OFF/ON Turns ON/OFF the multi matrix function
MTRIX AREA IND OFF/ON Turns ON/OFF the function that shows the zebra pattern indicating the
detecting region of the multi matrix correction, inside VF
MTRIX COLOR DET Press the MENU knob Automatic color detection function
to execute this menu item Move the cursor to the desired object color and press the MENU knob
Then the MTX (MULTI) AXIS will be set automatically
MTX (MULTI) PRESET Press the MENU knob Return MTX (MULTI) HUE and MTX (MULTI) SAT values to preset values
to execute this menu item for each of the 16 axes
MTX (MULTI) AXIS B/B+/MG_/MG/MG+/ Sets the chroma phase for the sixteen axes that are the target of the multi
R/R+/YL_/YL+/ matrix correction function
G_/G/G+/CY/CY+/B_
MTX (MULTI) HUE (_99 to 99) Adjusts the chroma phase (HUE) of the multi matrix correction
(every sixteen axis)
MTX (MULTI) SAT (_99 to 99) Adjusts the saturation (SAT) of the multi matrix correction
(every sixteen axis)
P11 MTX LINEAR TOP
MATRIX : OFF
MATRIX(USER) : OFF
MATRIX(PRESET) : ON
MATRIX(PRST)SEL : 2
MATRIX(USER) R-G: 0
MATRIX(USER) R-B: 0
MATRIX(USER) G-R: 0
MATRIX(USER) G-B: 0
MATRIX(USER) B-R: 0
MATRIX(USER) B-G: 0
P12 MTX MULTI TOP
MATRIX : OFF
MATRIX (MULTI) : OFF
MATRIX AREA IND : OFF
MATRIX COLOR DET : EXEC
MTX(MULTI) PRESET: EXEC
MTX(MULTI) AXIS : B
MTX(MULTI) HUE : 0
MTX(MULTI) SAT : 0
