V MODULATION Display (Adjusting Temporary WHITE V SAW SHADING for LENS)
Item Setting Function
V MOD OFF/ON Turns ON/OFF the V. modulation function
MASTER VMOD (_99 to 99) Adjusts amount of the master V. modulation correction
(All of the R, G and B V. modulation corrections are controlled)
R VMOD (_99 to 99) Adjusts amount of the R V. modulation correction
G VMOD (_99 to 99) Adjusts amount of the G V. modulation correction
B VMOD (_99 to 99) Adjusts amount of the B V. modulation correction
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST OUT
connector
SATURATION Display (Setting the saturation)
Item Setting Function
LOW KEY SAT OFF/ON Turns ON/OFF the low key saturation function
L KEY SAT LEVEL (_99 to 99) Sets the saturation level of low luminance part
L KEY SAT RANGE LOW/L.MID/ Sets the range of video signal in which the low key
H.MID/HIGH saturation correction is effective
LOW : 0 to 3.6 %
L.MID : 0 to 7.2 %
H.MID : 0 to 14.4 %
HIGH : 0 to 28.8 %
Y BLACK GAMMA OFF/ON Turns ON/OFF the Y black gamma correction function
Y BLK GAM LEVEL (_99 to 99) Adjust the gamma curve in the low luminance part
Y BLK GAM RANGE LOW/L.MID/ Sets the range of video signal in which the Y black
H.MID/HIGH gamma correction is effective
LOW : 0 to 3.6 %
L.MID : 0 to 7.2 %
H.MID : 0 to 14.4 %
HIGH : 0 to 28.8 %
P13 V MODULATION TOP
V MOD : ON
MASTER VMOD : 0
R VMOD : 0
G VMOD : 0
B VMOD : 0
TEST OUT SELECT : VBS
P14 SATURATION TOP
LOW KEY SAT : OFF
L KEY SAT LEVEL : 0
L KEY SAT RANGE : HIGH
Y BLACK GAMMA : OFF
Y BLK GAM LEVEL : 0
Y BLK GAM RANGE : HIGH
