4-52
PDW-700/V1 (E)
GENLOCK Display (Setting on GENLOCK input connector)
Item Setting Function
GENLOCK OFF/ON Turns ON/OFF the function that synchronizes the
internal reference signal with the video signal that is
connected to the GENLOCK connector
GL HD H PHASE (_99 to 99) GENLOCK phase adjustment (HD)
GL SD H PHASE
*
(_99 to 99) GENLOCK phase adjustment (SD)
REFERENCE Display only Displays the type of genlocked reference signal
* : This does not appear when SYSTEM LINE is set to 1080 and SYSTEM FREQUENCY is set to 23.9P.
ND COMP Display (ND OFFSET compensation)
Item Setting Function
ND OFFSET ADJUST OFF/ON Turns ON/OFF the ND OFFSET adjustment mode
CLEAR ND OFFSET Press the MENU knob to Returns the ND OFFSET value to the production
execute this menu item adjustment value
M19 GENLOCK TOP
GENLOCK : ON
GL HD H PHASE : 0
GL SD H PHASE : 0
REFERENCE :INTERNAL
M20 ND COMP TOP
ND OFFSET ADJUST: OFF
CLEAR ND OFFSET : EXEC
