1-29
PDW-700/V1 (E)
Ref.No. Bit Name Function Factory setting
S833 _ SUB CLIP Plays the clip list
*
_
S834 _ HOLD/CHAPTER Displays the display hold/chapter function
*
_
S835 _ RESET Resets the time counter display
*
_
S836 _ SHIFT Shift
*
_
S837 _ DISPLAY Switches the counter display
*
(CTL/TC/U_BIT) COUNTER : Displays the counter for the elapsed
record/playback time
TC : Displays time-code
U_BIT : Displays user-bit
S838 _ F_RUN/SET/R_RUN F_RUN : Continuous time-code steps
*
SET : Sets the time-code and user-bit
R_RUN : Time-code steps while recording
S839 _ RESET/REGEN/CLOCK Reset/regenerate/expand button
*
S840 _ DISP SEL/EXPAND Switches the display contents
*
_
S841 _ UP UP
*
_
S842 _ LEFT LEFT
*
_
S843 _ SET/S.SEL SET
*
_
S844 _ RIGHT RIGHT
*
_
S845 _ DOWN DOWN
*
_
S846 _ CLIP MENU MENU
*
_
S891 1 _ Factory-use OFF
2 _ Factory-use OFF
3 _ Factory-use OFF
4 _ Factory-use OFF
* : Refer to the “Operation Manual”.
