CTI application pulse register (CTI_APPPULSER)
Address offset: 0x01C
Reset value: 0x0000 0000
w
CTI trigger in x enable register (CTI_INENRx)
Address offset: 0x020 + 0x004 * x, (x = 0 to 7)
Reset value: 0x0000 0000
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 APPCLEAR[3:0]: channel event clearing
0000: No effect
XXX1: Clears event on Channel 0.
XX1X: Clears event on Channel 1.
X1XX: Clears event on Channel 2.
1XXX: Clears event on Channel 3.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. APPPULSE[3:0]
wwww
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 APPPULSE[3:0]: pulse channel event
This register clears itself immediately.
0000: No effect
XXX1: Generates pulse on Channel 0.
XX1X: Generates pulse on Channel 1.
X1XX: Generates pulse on Channel 2.
1XXX: Generates pulse on Channel 3.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. TRIGINEN[3:0]
rw rw rw rw
