ST STM32WL55JC User Manual

RM0453 Rev 2 1363/1454
RM0453 Debug support (DBG)
1441
CTI trigger out x enable register (CTI_OUTENRx)
Address offset: 0x0A0 + 0x004 * x, (x = 0 to 7)
Reset value: 0x0000 0000
CTI trigger in status register (CTI_TRGISTSR)
Address offset: 0x130
Reset value: 0x0000 0000
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 TRIGINEN[3:0]: cross trigger event enable/disable
Enables or disables a cross trigger event on each of the four channels when CTITRIGINx is
activated (x = 0 to 7).
0000: Trigger does not generate events on any channel.
XXX1: Trigger n generates events on Channel 0.
XX1X: Trigger n generates events on Channel 1.
X1XX: Trigger n generates events on Channel 2.
1XXX: Trigger n generates events on Channel 3.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. TRIGOUTEN[3:0]
rw rw rw rw
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 TRIGOUTEN[3:0]: For each channel, defines whether an event on that channel generates a
trigger on CTITRIGOUTx (x = 0 to 7).
0000: Channel events do not generate triggers on any trigger output.
XXX1: Channel 0 events generate triggers on Trigger output n.
XX1X: Channel 1 events generate triggers on Trigger output n.
X1XX: Channel 2 events generate triggers on Trigger output n.
1XXX: Channel 3 events generate triggers on Trigger output n.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. TRIGINSTATUS[7:0]
rrrrrrrr
