RM0453 Rev 2 1369/1454
RM0453 Debug support (DBG)
1441
CTI device type identifier register (CTI_DEVTYPER)
Address offset: 0xFCC
Reset value: 0x0000 0014
CTI CoreSight peripheral identity register 4 (CTI_PIDR4)
Address offset: 0xFD0
Reset value: 0x0000 0004
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. SUBTYPE[3:0] MAJORTYPE[3:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 SUBTYPE[3:0]: sub-classification
0x1: Indicates that this component is a cross-triggering component.
Bits 3:0 MAJORTYPE[3:0]: major classification
0x4: Indicates that this component allows a debugger to control other components in a
CoreSight™ SoC-400 system.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. F4KCOUNT[3:0] JEP106CON[3:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 F4KCOUNT[3:0]: register file size
0x0: The register file occupies a single 4-Kbyte region
Bits 3:0 JEP106CON[3:0]: JEP106 continuation code
0x4: Arm
®
JEDEC code
