ST STM32WL55JC User Manual

General-purpose I/Os (GPIO) RM0453
422/1454 RM0453 Rev 2
10.4.32 GPIOH bit reset register (GPIOH_BRR)
Address offset: 0x1C28
Reset value: 0x0000 0000
10.4.33 GPIOA register map
The following table gives the GPIOA register map and reset values.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. BR3 Res. Res. Res.
rc_w1
Bits 31:4 Reserved, must be kept at reset value.
Bit 3 BR3: Port PH3 reset output data bit [3] in GPIOH_ODR
This bit is read clear-write 1. A read to this bit returns the value 0.
0: No action on the corresponding GPIOH_ODR.OD3
1: Resets the corresponding GPIOH_ODR.OD3.
Bits 2:0 Reserved, must be kept at reset value.
Table 71. GPIOA register map and reset values
Offset Register name
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x0000
GPIOA_MODER
MODE15[1:0] MODE14[1:0] MODE13[1:0] MODE12[1:0]
MODE11[1:0]
MODE10[1:0]
MODE9[1:0] MODE8[1:0] MODE7[1:0] MODE6[1:0] MODE5[1:0] MODE4[1:0] MODE3[1:0] MODE2[1:0] MODE1[1:0] MODE0[1:0]
Reset value 10101011111111111111111111111111
0x0004
GPIOA_OTYPER
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
OT15 OT14 OT13 OT12
OT11
OT10
OT9 OT8 OT7 OT6 OT5 OT4 OT3 OT2 OT1 OT0
Reset value 0000000000000000
0x0008
GPIOA_OSPEEDR
OSPEED15[1:0] OSPEED14[1:0] OSPEED13[1:0] OSPEED12[1:0]
OSPEED11[1:0]
OSPEED10[1:0]
OSPEED9[1:0] OSPEED8[1:0] OSPEED7[1:0] OSPEED6[1:0] OSPEED5[1:0] OSPEED4[1:0] OSPEED3[1:0] OSPEED2[1:0] OSPEED1[1:0] OSPEED0[1:0]
Reset value 00001100000000000000000000000000
0x000C
GPIOA_PUPDR
PUPD15[1:0] PUPD14[1:0] PUPD13[1:0] PUPD12[1:0]
PUPD11[1:0]
PUPD10[1:0]
PUPD9[1:0] PUPD8[1:0] PUPD7[1:0] PUPD6[1:0] PUPD5[1:0] PUPD4[1:0] PUPD3[1:0] PUPD2[1:0] PUPD1[1:0] PUPD0[1:0]
Reset value 01100100000000000000000000000000
0x0010
GPIOA_IDR
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
ID15 ID14 ID13 ID12
ID11
ID10
ID9 ID8 ID7 ID6 ID5 ID4 ID3 ID2 ID1 ID0
Reset value xxxxxxxxxxxxxxxx
0x0014
GPIOA_ODR
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
OD15 OD14 OD13 OD12
OD11
OD10
OD9 OD8 OD7 OD6 OD5 OD4 OD3 OD2 OD1 OD0
Reset value 0000000000000000
