Stober PK - Page 103

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C5 (n
1N
= 3000 rpm, M
2acc,max
= 920 Nm)
86 234 292 1.4 3.4 C502_0350 MB23 EZ404U 850 1600 35.00 35/1 12 8.0 3400 3000 4000 12 23 60
86 234 292 1.4 3.4 C502_0350 MB23 EZ404U 850 1600 35.00 35/1 16 8.0 3400 3000 4000 12 23 60
86 251 272 1.5 3.2 C502_0350 MB23 EZ502U 850 1600 35.00 35/1 8.0 8.0 3400 3000 4000 14 23 60
86 251 272 1.5 3.2 C502_0350 MB23 EZ502U 850 1600 35.00 35/1 12 8.0 3400 3000 4000 14 23 60
86 251 272 1.5 3.2 C502_0350 MB23 EZ502U 850 1600 35.00 35/1 16 8.0 3400 3000 4000 14 23 60
86 329 377 1.9 2.4 C502_0350 MB23 EZ503U 850 1600 35.00 35/1 8.0 15 3400 3000 4000 18 23 62
86 458 543 2.7 1.7 C502_0350 MB23 EZ505U 850 1600 35.00 35/1 8.0 15 3400 3000 4000 22 23 65
96 209 261 1.3 3.8 C502_0310 MB23 EZ404U 879 1600 31.23 406/13 8.0 8.0 3400 3000 4000 12 23 60
96 209 261 1.3 3.8 C502_0310 MB23 EZ404U 879 1600 31.23 406/13 12 8.0 3400 3000 4000 12 23 60
96 209 261 1.3 3.8 C502_0310 MB23 EZ404U 879 1600 31.23 406/13 16 8.0 3400 3000 4000 12 23 60
96 224 242 1.4 3.6 C502_0310 MB23 EZ502U 920 1600 31.23 406/13 8.0 8.0 3400 3000 4000 14 23 60
96 224 242 1.4 3.6 C502_0310 MB23 EZ502U 920 1600 31.23 406/13 12 8.0 3400 3000 4000 14 23 60
96 224 242 1.4 3.6 C502_0310 MB23 EZ502U 920 1600 31.23 406/13 16 8.0 3400 3000 4000 14 23 60
96 294 336 1.8 2.7 C502_0310 MB23 EZ503U 920 1600 31.23 406/13 8.0 15 3400 3000 4000 18 23 62
96 294 336 1.8 2.7 C502_0310 MB23 EZ503U 920 1600 31.23 406/13 12 15 3400 3000 4000 18 23 62
96 409 485 2.6 2.0 C502_0310 MB23 EZ505U 920 1600 31.23 406/13 8.0 15 3400 3000 4000 22 23 65
96 409 485 2.6 2.0 C502_0310 MB23 EZ505U 920 1600 31.23 406/13 12 15 3400 3000 4000 22 23 65
107 188 234 1.2 4.3 C502_0280 MB23 EZ404U 790 1600 28.10 5395/192 8.0 8.0 3400 3000 4000 13 23 60
107 188 234 1.2 4.3 C502_0280 MB23 EZ404U 790 1600 28.10 5395/192 12 8.0 3400 3000 4000 13 23 60
107 188 234 1.2 4.3 C502_0280 MB23 EZ404U 790 1600 28.10 5395/192 16 8.0 3400 3000 4000 13 23 60
107 202 218 1.3 4.0 C502_0280 MB23 EZ502U 845 1600 28.10 5395/192 8.0 8.0 3400 3000 4000 15 23 60
107 202 218 1.3 4.0 C502_0280 MB23 EZ502U 845 1600 28.10 5395/192 12 8.0 3400 3000 4000 15 23 60
107 202 218 1.3 4.0 C502_0280 MB23 EZ502U 845 1600 28.10 5395/192 16 8.0 3400 3000 4000 15 23 60
107 202 226 1.3 4.0 C502_0280 MB33 EZ701U 545 1600 28.10 5395/192 16 15 3400 3000 4000 40 23 69
107 264 303 1.7 3.0 C502_0280 MB23 EZ503U 850 1600 28.10 5395/192 8.0 15 3400 3000 4000 18 23 62
107 264 303 1.7 3.0 C502_0280 MB23 EZ503U 850 1600 28.10 5395/192 12 15 3400 3000 4000 18 23 62
107 327 392 2.2 2.4 C502_0280 MB33 EZ702U 850 1600 28.10 5395/192 16 15 3400 3000 4000 45 23 72
107 368 436 2.4 2.2 C502_0280 MB23 EZ505U 850 1600 28.10 5395/192 8.0 15 3400 3000 4000 23 23 65
107 368 436 2.4 2.2 C502_0280 MB23 EZ505U 850 1600 28.10 5395/192 12 15 3400 3000 4000 23 23 65
120 168 209 1.2 4.8 C502_0250 MB23 EZ404U 705 1532 25.07 2407/96 8.0 8.0 3400 3000 4000 13 23 60
120 168 209 1.2 4.8 C502_0250 MB23 EZ404U 705 1532 25.07 2407/96 12 8.0 3400 3000 4000 13 23 60
120 168 209 1.2 4.8 C502_0250 MB23 EZ404U 705 1532 25.07 2407/96 16 8.0 3400 3000 4000 13 23 60
120 180 195 1.3 4.4 C502_0250 MB23 EZ502U 754 1532 25.07 2407/96 8.0 8.0 3400 3000 4000 15 23 60
120 180 195 1.3 4.4 C502_0250 MB23 EZ502U 754 1532 25.07 2407/96 12 8.0 3400 3000 4000 15 23 60
120 180 195 1.3 4.4 C502_0250 MB23 EZ502U 754 1532 25.07 2407/96 16 8.0 3400 3000 4000 15 23 60
120 180 202 1.3 4.4 C502_0250 MB33 EZ701U 486 1600 25.07 2407/96 16 15 3400 3000 4000 40 23 69
120 236 270 1.6 3.4 C502_0250 MB23 EZ503U 912 1532 25.07 2407/96 8.0 15 3400 3000 4000 18 23 62
120 236 270 1.6 3.4 C502_0250 MB23 EZ503U 912 1532 25.07 2407/96 12 15 3400 3000 4000 18 23 62
120 292 350 2.0 2.7 C502_0250 MB33 EZ702U 920 1600 25.07 2407/96 16 15 3400 3000 4000 45 23 72
120 328 389 2.3 2.4 C502_0250 MB23 EZ505U 912 1532 25.07 2407/96 8.0 15 3400 3000 4000 23 23 65
120 328 389 2.3 2.4 C502_0250 MB23 EZ505U 912 1532 25.07 2407/96 12 15 3400 3000 4000 23 23 65
128 168 181 1.2 4.8 C502_0230 MB23 EZ502U 702 1427 23.36 1495/64 8.0 8.0 3400 3000 4000 16 23 60
128 168 181 1.2 4.8 C502_0230 MB23 EZ502U 702 1427 23.36 1495/64 12 8.0 3400 3000 4000 16 23 60
128 168 181 1.2 4.8 C502_0230 MB23 EZ502U 702 1427 23.36 1495/64 16 8.0 3400 3000 4000 16 23 60
128 168 188 1.2 4.8 C502_0230 MB33 EZ701U 453 1600 23.36 1495/64 16 15 3400 3000 4000 41 23 69
128 168 188 1.2 4.8 C502_0230 MB33 EZ701U 453 1600 23.36 1495/64 24 15 3400 3000 4000 41 23 69
128 220 252 1.6 3.6 C502_0230 MB23 EZ503U 850 1427 23.36 1495/64 8.0 15 3400 3000 4000 19 23 62
128 220 252 1.6 3.6 C502_0230 MB23 EZ503U 850 1427 23.36 1495/64 12 15 3400 3000 4000 19 23 62
128 272 326 2.0 2.9 C502_0230 MB33 EZ702U 850 1600 23.36 1495/64 16 15 3400 3000 4000 46 23 72
128 272 326 2.0 2.9 C502_0230 MB33 EZ702U 850 1600 23.36 1495/64 24 15 3400 3000 4000 46 23 72
128 306 363 2.2 2.6 C502_0230 MB23 EZ505U 850 1427 23.36 1495/64 8.0 15 3400 3000 4000 24 23 65
128 306 363 2.2 2.6 C502_0230 MB23 EZ505U 850 1427 23.36 1495/64 12 15 3400 3000 4000 24 23 65
144 196 224 1.6 3.9 C502_0210 MB23 EZ503U 758 1274 20.84 667/32 8.0 15 3400 3000 4000 19 23 62
144 196 224 1.6 3.9 C502_0210 MB23 EZ503U 758 1274 20.84 667/32 12 15 3400 3000 4000 19 23 62
144 243 291 1.9 3.3 C502_0210 MB33 EZ702U 829 1600 20.84 667/32 16 15 3400 3000 4000 46 23 72
144 243 291 1.9 3.3 C502_0210 MB33 EZ702U 829 1600 20.84 667/32 24 15 3400 3000 4000 46 23 72
144 273 323 2.2 2.8 C502_0210 MB23 EZ505U 758 1274 20.84 667/32 8.0 15 3400 3000 4000 24 23 65
144 273 323 2.2 2.8 C502_0210 MB23 EZ505U 758 1274 20.84 667/32 12 15 3400 3000 4000 24 23 65
170 205 246 1.7 3.9 C502_0175 MB33 EZ702U 700 1600 17.60 845/48 16 15 3100 2700 4000 47 23 72
170 205 246 1.7 3.9 C502_0175 MB33 EZ702U 700 1600 17.60 845/48 24 15 3100 2700 4000 47 23 72
170 205 246 1.7 3.9 C502_0175 MB33 EZ702U 700 1600 17.60 845/48 32 15 3100 2700 4000 47 23 72
170 282 355 2.4 2.8 C502_0175 MB33 EZ703U 850 1600 17.60 845/48 16 32 3100 2700 4000 59 23 75
170 364 516 3.0 2.2 C502_0175 MB33 EZ705U 850 1600 17.60 845/48 16 32 3100 2700 4000 72 23 80
191 183 219 1.6 4.4 C502_0155 MB33 EZ702U 625 1600 15.71 377/24 16 15 3100 2700 4000 47 23 72
5 Chelical geared motors 5.2 Selection tables
103
