Stober PK - Page 102

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
641 97 137 4.4 2.7 C402_0047 MB33 EZ705U 454 850 4.682 899/192 45 32 3300 2800 4000 72 17 68
641 121 219 5.5 2.2 C402_0047 MB43 EZ803U 502 850 4.682 899/192 50 65 3000 2800 3000 179 17 99
770 37 42 3.4 3.9 C402_0039 MB23 EZ503U 142 238 3.894 841/216 8.0 15 2900 2500 4000 22 17 50
770 37 42 3.4 3.9 C402_0039 MB23 EZ503U 142 238 3.894 841/216 12 15 2900 2500 4000 22 17 50
770 51 60 4.7 2.8 C402_0039 MB23 EZ505U 142 238 3.894 841/216 8.0 15 2900 2500 4000 27 17 53
770 51 60 4.7 2.8 C402_0039 MB23 EZ505U 142 238 3.894 841/216 12 15 2900 2500 4000 27 17 53
770 62 79 3.3 4.0 C402_0039 MB33 EZ703U 246 714 3.894 841/216 16 32 2900 2500 4000 61 17 63
770 62 79 3.3 4.0 C402_0039 MB33 EZ703U 246 714 3.894 841/216 24 32 2900 2500 4000 61 17 63
770 62 79 3.3 4.0 C402_0039 MB33 EZ703U 246 714 3.894 841/216 32 32 2900 2500 4000 61 17 63
770 62 79 3.3 4.0 C402_0039 MB33 EZ703U 246 714 3.894 841/216 45 32 2900 2500 4000 61 17 63
770 80 114 4.2 3.1 C402_0039 MB33 EZ705U 378 714 3.894 841/216 16 32 2900 2500 4000 73 17 68
770 80 114 4.2 3.1 C402_0039 MB33 EZ705U 378 714 3.894 841/216 24 32 2900 2500 4000 73 17 68
770 80 114 4.2 3.1 C402_0039 MB33 EZ705U 378 714 3.894 841/216 32 32 2900 2500 4000 73 17 68
770 80 114 4.2 3.1 C402_0039 MB33 EZ705U 378 714 3.894 841/216 45 32 2900 2500 4000 73 17 68
770 100 182 5.3 2.5 C402_0039 MB43 EZ803U 472 850 3.894 841/216 50 65 2900 2500 3000 181 17 99
770 100 182 5.3 2.5 C402_0039 MB43 EZ803U 472 850 3.894 841/216 72 65 2900 2500 3000 181 17 99
968 50 63 3.2 4.7 C402_0031 MB33 EZ703U 195 568 3.099 1537/496 16 32 2900 2500 4000 63 17 63
968 50 63 3.2 4.7 C402_0031 MB33 EZ703U 195 568 3.099 1537/496 24 32 2900 2500 4000 63 17 63
968 50 63 3.2 4.7 C402_0031 MB33 EZ703U 195 568 3.099 1537/496 32 32 2900 2500 4000 63 17 63
968 50 63 3.2 4.7 C402_0031 MB33 EZ703U 195 568 3.099 1537/496 45 32 2900 2500 4000 63 17 63
968 64 91 4.1 3.6 C402_0031 MB33 EZ705U 301 568 3.099 1537/496 16 32 2900 2500 4000 75 17 68
968 64 91 4.1 3.6 C402_0031 MB33 EZ705U 301 568 3.099 1537/496 24 32 2900 2500 4000 75 17 68
968 64 91 4.1 3.6 C402_0031 MB33 EZ705U 301 568 3.099 1537/496 32 32 2900 2500 4000 75 17 68
968 64 91 4.1 3.6 C402_0031 MB33 EZ705U 301 568 3.099 1537/496 45 32 2900 2500 4000 75 17 68
968 80 145 5.1 2.9 C402_0031 MB43 EZ803U 436 838 3.099 1537/496 50 65 2900 2500 3000 183 17 99
968 80 145 5.1 2.9 C402_0031 MB43 EZ803U 436 838 3.099 1537/496 72 65 2900 2500 3000 183 17 99
968 80 145 5.1 2.9 C402_0031 MB43 EZ803U 436 838 3.099 1537/496 100 65 2900 2500 3000 183 17 99
1221 51 72 3.9 4.2 C402_0025 MB33 EZ705U 238 450 2.456 609/248 16 32 2500 2100 3500 79 17 68
1221 51 72 3.9 4.2 C402_0025 MB33 EZ705U 238 450 2.456 609/248 24 32 2500 2100 3500 79 17 68
1221 51 72 3.9 4.2 C402_0025 MB33 EZ705U 238 450 2.456 609/248 32 32 2500 2100 3500 79 17 68
1221 51 72 3.9 4.2 C402_0025 MB33 EZ705U 238 450 2.456 609/248 45 32 2500 2100 3500 79 17 68
1221 63 115 4.9 3.4 C402_0025 MB43 EZ803U 345 665 2.456 609/248 50 65 2500 2100 3000 187 17 99
1221 63 115 4.9 3.4 C402_0025 MB43 EZ803U 345 665 2.456 609/248 72 65 2500 2100 3000 187 17 99
1221 63 115 4.9 3.4 C402_0025 MB43 EZ803U 345 665 2.456 609/248 100 65 2500 2100 3000 187 17 99
1524 41 58 3.9 4.7 C402_0020 MB33 EZ705U 191 361 1.968 551/280 16 32 2500 2100 3500 84 17 68
1524 41 58 3.9 4.7 C402_0020 MB33 EZ705U 191 361 1.968 551/280 24 32 2500 2100 3500 84 17 68
1524 41 58 3.9 4.7 C402_0020 MB33 EZ705U 191 361 1.968 551/280 32 32 2500 2100 3500 84 17 68
1524 41 58 3.9 4.7 C402_0020 MB33 EZ705U 191 361 1.968 551/280 45 32 2500 2100 3500 84 17 68
1524 51 92 4.7 3.9 C402_0020 MB43 EZ803U 277 533 1.968 551/280 50 65 2500 2100 3000 192 17 99
1524 51 92 4.7 3.9 C402_0020 MB43 EZ803U 277 533 1.968 551/280 72 65 2500 2100 3000 192 17 99
1524 51 92 4.7 3.9 C402_0020 MB43 EZ803U 277 533 1.968 551/280 100 65 2500 2100 3000 192 17 99
C5 (n
1N
= 2000 rpm, M
2acc,max
= 700 Nm)
432 196 297 5.4 2.4 C502_0046 MB43 EZ805U 775 1236 4.629 162/35 50 115 3000 2700 3000 271 21 127
517 164 248 5.3 2.7 C502_0039 MB43 EZ805U 730 1047 3.867 58/15 50 115 2800 2400 3000 274 21 127
650 130 197 5.1 3.1 C502_0031 MB43 EZ805U 612 834 3.077 477/155 50 115 2800 2400 3000 278 21 127
1012 84 127 4.7 4.2 C502_0020 MB43 EZ805U 393 644 1.976 81/41 50 115 2400 2000 3000 293 21 127
C5 (n
1N
= 3000 rpm, M
2acc,max
= 920 Nm)
60 208 227 1.0 3.9 C502_0500 MB23 EZ501U 773 1600 49.82 1943/39 8.0 8.0 3400 3000 4000 11 23 58
60 227 251 1.1 3.5 C502_0500 MB23 EZ402U 773 1600 49.82 1943/39 8.0 8.0 3400 3000 4000 9.7 23 58
60 333 416 1.7 2.4 C502_0500 MB23 EZ404U 920 1600 49.82 1943/39 8.0 8.0 3400 3000 4000 11 23 60
60 358 387 1.8 2.2 C502_0500 MB23 EZ502U 920 1600 49.82 1943/39 8.0 8.0 3400 3000 4000 13 23 60
64 195 213 1.0 4.1 C502_0470 MB23 EZ501U 725 1600 46.72 1495/32 8.0 8.0 3400 3000 4000 11 23 58
64 213 236 1.1 3.8 C502_0470 MB23 EZ402U 725 1600 46.72 1495/32 8.0 8.0 3400 3000 4000 10 23 58
64 313 390 1.6 2.6 C502_0470 MB23 EZ404U 850 1600 46.72 1495/32 8.0 8.0 3400 3000 4000 11 23 60
64 335 363 1.7 2.4 C502_0470 MB23 EZ502U 850 1600 46.72 1495/32 8.0 8.0 3400 3000 4000 14 23 60
72 174 190 0.9 4.6 C502_0420 MB23 EZ501U 647 1600 41.69 667/16 8.0 8.0 3400 3000 4000 11 23 58
72 174 190 0.9 4.6 C502_0420 MB23 EZ501U 647 1600 41.69 667/16 12 8.0 3400 3000 4000 11 23 58
72 190 210 1.0 4.2 C502_0420 MB23 EZ402U 647 1600 41.69 667/16 8.0 8.0 3400 3000 4000 10 23 58
72 190 210 1.0 4.2 C502_0420 MB23 EZ402U 647 1600 41.69 667/16 12 8.0 3400 3000 4000 10 23 58
72 279 348 1.5 2.9 C502_0420 MB23 EZ404U 920 1600 41.69 667/16 8.0 8.0 3400 3000 4000 11 23 60
72 279 348 1.5 2.9 C502_0420 MB23 EZ404U 920 1600 41.69 667/16 12 8.0 3400 3000 4000 11 23 60
72 299 323 1.6 2.7 C502_0420 MB23 EZ502U 920 1600 41.69 667/16 8.0 8.0 3400 3000 4000 14 23 60
72 299 323 1.6 2.7 C502_0420 MB23 EZ502U 920 1600 41.69 667/16 12 8.0 3400 3000 4000 14 23 60
86 234 292 1.4 3.4 C502_0350 MB23 EZ404U 850 1600 35.00 35/1 8.0 8.0 3400 3000 4000 12 23 60
5.2 Selection tables 5 Chelical geared motors
