Stober PK - Page 101

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
324 108 129 2.0 4.3 C402_0093 MB33 EZ702U 368 1100 9.261 3445/372 32 15 2900 2500 4000 49 22 60
324 108 129 2.0 4.3 C402_0093 MB33 EZ702U 368 1100 9.261 3445/372 45 15 2900 2500 4000 49 22 60
324 148 187 2.7 3.1 C402_0093 MB33 EZ703U 550 1100 9.261 3445/372 16 32 2900 2500 4000 60 22 63
324 148 187 2.7 3.1 C402_0093 MB33 EZ703U 550 1100 9.261 3445/372 24 32 2900 2500 4000 60 22 63
324 148 187 2.7 3.1 C402_0093 MB33 EZ703U 550 1100 9.261 3445/372 32 32 2900 2500 4000 60 22 63
324 191 271 3.5 2.4 C402_0093 MB33 EZ705U 550 1100 9.261 3445/372 16 32 2900 2500 4000 73 22 68
324 191 271 3.5 2.4 C402_0093 MB33 EZ705U 550 1100 9.261 3445/372 24 32 2900 2500 4000 73 22 68
324 191 271 3.5 2.4 C402_0093 MB33 EZ705U 550 1100 9.261 3445/372 32 32 2900 2500 4000 73 22 68
362 96 116 1.9 4.6 C402_0083 MB33 EZ702U 329 1100 8.285 3339/403 16 15 2900 2500 4000 49 22 60
362 96 116 1.9 4.6 C402_0083 MB33 EZ702U 329 1100 8.285 3339/403 24 15 2900 2500 4000 49 22 60
362 96 116 1.9 4.6 C402_0083 MB33 EZ702U 329 1100 8.285 3339/403 32 15 2900 2500 4000 49 22 60
362 96 116 1.9 4.6 C402_0083 MB33 EZ702U 329 1100 8.285 3339/403 45 15 2900 2500 4000 49 22 60
362 133 167 2.7 3.4 C402_0083 MB33 EZ703U 522 1100 8.285 3339/403 16 32 2900 2500 4000 61 22 63
362 133 167 2.7 3.4 C402_0083 MB33 EZ703U 522 1100 8.285 3339/403 24 32 2900 2500 4000 61 22 63
362 133 167 2.7 3.4 C402_0083 MB33 EZ703U 522 1100 8.285 3339/403 32 32 2900 2500 4000 61 22 63
362 171 243 3.5 2.6 C402_0083 MB33 EZ705U 600 1100 8.285 3339/403 16 32 2900 2500 4000 73 22 68
362 171 243 3.5 2.6 C402_0083 MB33 EZ705U 600 1100 8.285 3339/403 24 32 2900 2500 4000 73 22 68
362 171 243 3.5 2.6 C402_0083 MB33 EZ705U 600 1100 8.285 3339/403 32 32 2900 2500 4000 73 22 68
384 56 61 2.0 4.7 C402_0078 MB23 EZ502U 235 478 7.816 2001/256 8.0 8.0 3500 3200 4000 15 17 48
384 56 61 2.0 4.7 C402_0078 MB23 EZ502U 235 478 7.816 2001/256 12 8.0 3500 3200 4000 15 17 48
384 56 61 2.0 4.7 C402_0078 MB23 EZ502U 235 478 7.816 2001/256 16 8.0 3500 3200 4000 15 17 48
384 74 84 2.6 3.6 C402_0078 MB23 EZ503U 284 478 7.816 2001/256 8.0 15 3500 3200 4000 18 17 50
384 74 84 2.6 3.6 C402_0078 MB23 EZ503U 284 478 7.816 2001/256 12 15 3500 3200 4000 18 17 50
384 91 109 2.7 3.5 C402_0078 MB33 EZ702U 311 850 7.816 2001/256 16 15 3500 3200 4000 45 17 60
384 91 109 2.7 3.5 C402_0078 MB33 EZ702U 311 850 7.816 2001/256 24 15 3500 3200 4000 45 17 60
384 91 109 2.7 3.5 C402_0078 MB33 EZ702U 311 850 7.816 2001/256 32 15 3500 3200 4000 45 17 60
384 91 109 2.7 3.5 C402_0078 MB33 EZ702U 311 850 7.816 2001/256 45 15 3500 3200 4000 45 17 60
384 102 121 3.6 2.6 C402_0078 MB23 EZ505U 284 478 7.816 2001/256 8.0 15 3500 3200 4000 23 17 53
384 102 121 3.6 2.6 C402_0078 MB23 EZ505U 284 478 7.816 2001/256 12 15 3500 3200 4000 23 17 53
384 125 158 3.7 2.5 C402_0078 MB33 EZ703U 493 850 7.816 2001/256 16 32 3500 3200 4000 57 17 63
384 125 158 3.7 2.5 C402_0078 MB33 EZ703U 493 850 7.816 2001/256 24 32 3500 3200 4000 57 17 63
384 161 229 4.8 2.0 C402_0078 MB33 EZ705U 550 850 7.816 2001/256 16 32 3500 3200 4000 69 17 68
384 161 229 4.8 2.0 C402_0078 MB33 EZ705U 550 850 7.816 2001/256 24 32 3500 3200 4000 69 17 68
509 55 63 2.8 3.9 C402_0059 MB23 EZ503U 214 360 5.891 377/64 8.0 15 3300 2800 4000 19 17 50
509 55 63 2.8 3.9 C402_0059 MB23 EZ503U 214 360 5.891 377/64 12 15 3300 2800 4000 19 17 50
509 69 82 2.6 4.2 C402_0059 MB33 EZ702U 234 850 5.891 377/64 16 15 3300 2800 4000 46 17 60
509 69 82 2.6 4.2 C402_0059 MB33 EZ702U 234 850 5.891 377/64 24 15 3300 2800 4000 46 17 60
509 69 82 2.6 4.2 C402_0059 MB33 EZ702U 234 850 5.891 377/64 32 15 3300 2800 4000 46 17 60
509 69 82 2.6 4.2 C402_0059 MB33 EZ702U 234 850 5.891 377/64 45 15 3300 2800 4000 46 17 60
509 77 91 3.9 2.8 C402_0059 MB23 EZ505U 214 360 5.891 377/64 8.0 15 3300 2800 4000 24 17 53
509 77 91 3.9 2.8 C402_0059 MB23 EZ505U 214 360 5.891 377/64 12 15 3300 2800 4000 24 17 53
509 94 119 3.5 3.0 C402_0059 MB33 EZ703U 371 850 5.891 377/64 16 32 3300 2800 4000 58 17 63
509 94 119 3.5 3.0 C402_0059 MB33 EZ703U 371 850 5.891 377/64 24 32 3300 2800 4000 58 17 63
509 94 119 3.5 3.0 C402_0059 MB33 EZ703U 371 850 5.891 377/64 32 32 3300 2800 4000 58 17 63
509 94 119 3.5 3.0 C402_0059 MB33 EZ703U 371 850 5.891 377/64 45 32 3300 2800 4000 58 17 63
509 122 173 4.5 2.4 C402_0059 MB33 EZ705U 542 850 5.891 377/64 16 32 3300 2800 4000 70 17 68
509 122 173 4.5 2.4 C402_0059 MB33 EZ705U 542 850 5.891 377/64 24 32 3300 2800 4000 70 17 68
509 122 173 4.5 2.4 C402_0059 MB33 EZ705U 542 850 5.891 377/64 32 32 3300 2800 4000 70 17 68
509 122 173 4.5 2.4 C402_0059 MB33 EZ705U 542 850 5.891 377/64 45 32 3300 2800 4000 70 17 68
641 44 50 3.1 3.9 C402_0047 MB23 EZ503U 170 286 4.682 899/192 8.0 15 3300 2800 4000 21 17 50
641 44 50 3.1 3.9 C402_0047 MB23 EZ503U 170 286 4.682 899/192 12 15 3300 2800 4000 21 17 50
641 54 65 2.5 4.9 C402_0047 MB33 EZ702U 186 850 4.682 899/192 16 15 3300 2800 4000 47 17 60
641 54 65 2.5 4.9 C402_0047 MB33 EZ702U 186 850 4.682 899/192 24 15 3300 2800 4000 47 17 60
641 54 65 2.5 4.9 C402_0047 MB33 EZ702U 186 850 4.682 899/192 32 15 3300 2800 4000 47 17 60
641 54 65 2.5 4.9 C402_0047 MB33 EZ702U 186 850 4.682 899/192 45 15 3300 2800 4000 47 17 60
641 61 73 4.3 2.8 C402_0047 MB23 EZ505U 170 286 4.682 899/192 8.0 15 3300 2800 4000 25 17 53
641 61 73 4.3 2.8 C402_0047 MB23 EZ505U 170 286 4.682 899/192 12 15 3300 2800 4000 25 17 53
641 75 94 3.4 3.5 C402_0047 MB33 EZ703U 295 850 4.682 899/192 16 32 3300 2800 4000 59 17 63
641 75 94 3.4 3.5 C402_0047 MB33 EZ703U 295 850 4.682 899/192 24 32 3300 2800 4000 59 17 63
641 75 94 3.4 3.5 C402_0047 MB33 EZ703U 295 850 4.682 899/192 32 32 3300 2800 4000 59 17 63
641 75 94 3.4 3.5 C402_0047 MB33 EZ703U 295 850 4.682 899/192 45 32 3300 2800 4000 59 17 63
641 97 137 4.4 2.7 C402_0047 MB33 EZ705U 454 850 4.682 899/192 16 32 3300 2800 4000 72 17 68
641 97 137 4.4 2.7 C402_0047 MB33 EZ705U 454 850 4.682 899/192 24 32 3300 2800 4000 72 17 68
641 97 137 4.4 2.7 C402_0047 MB33 EZ705U 454 850 4.682 899/192 32 32 3300 2800 4000 72 17 68
5 Chelical geared motors 5.2 Selection tables
