Stober PK - Page 100

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
144 150 162 1.6 3.7 C402_0210 MB23 EZ502U 600 1100 20.90 4347/208 16 8.0 3500 3200 4000 14 22 48
144 197 225 2.0 2.8 C402_0210 MB23 EZ503U 600 1100 20.90 4347/208 8.0 15 3500 3200 4000 18 22 50
144 197 225 2.0 2.8 C402_0210 MB23 EZ503U 600 1100 20.90 4347/208 12 15 3500 3200 4000 18 22 50
144 274 324 2.8 2.0 C402_0210 MB23 EZ505U 600 1100 20.90 4347/208 8.0 15 3500 3200 4000 22 22 53
144 274 324 2.8 2.0 C402_0210 MB23 EZ505U 600 1100 20.90 4347/208 12 15 3500 3200 4000 22 22 53
170 118 147 1.3 4.7 C402_0175 MB23 EZ404U 495 1076 17.60 845/48 8.0 8.0 3300 2800 4000 13 22 49
170 118 147 1.3 4.7 C402_0175 MB23 EZ404U 495 1076 17.60 845/48 12 8.0 3300 2800 4000 13 22 49
170 118 147 1.3 4.7 C402_0175 MB23 EZ404U 495 1076 17.60 845/48 16 8.0 3300 2800 4000 13 22 49
170 126 137 1.4 4.4 C402_0175 MB23 EZ502U 529 1076 17.60 845/48 8.0 8.0 3300 2800 4000 15 22 48
170 126 137 1.4 4.4 C402_0175 MB23 EZ502U 529 1076 17.60 845/48 12 8.0 3300 2800 4000 15 22 48
170 126 137 1.4 4.4 C402_0175 MB23 EZ502U 529 1076 17.60 845/48 16 8.0 3300 2800 4000 15 22 48
170 126 142 1.4 4.4 C402_0175 MB33 EZ701U 342 1100 17.60 845/48 16 15 3300 2800 4000 40 22 58
170 166 190 1.9 3.3 C402_0175 MB23 EZ503U 550 1076 17.60 845/48 8.0 15 3300 2800 4000 19 22 50
170 166 190 1.9 3.3 C402_0175 MB23 EZ503U 550 1076 17.60 845/48 12 15 3300 2800 4000 19 22 50
170 205 246 2.3 2.7 C402_0175 MB33 EZ702U 550 1100 17.60 845/48 16 15 3300 2800 4000 45 22 60
170 231 273 2.6 2.4 C402_0175 MB23 EZ505U 550 1076 17.60 845/48 8.0 15 3300 2800 4000 23 22 53
170 231 273 2.6 2.4 C402_0175 MB23 EZ505U 550 1076 17.60 845/48 12 15 3300 2800 4000 23 22 53
190 113 122 1.3 4.9 C402_0160 MB23 EZ502U 474 962 15.75 63/4 8.0 8.0 3300 2800 4000 15 22 48
190 113 122 1.3 4.9 C402_0160 MB23 EZ502U 474 962 15.75 63/4 12 8.0 3300 2800 4000 15 22 48
190 113 122 1.3 4.9 C402_0160 MB23 EZ502U 474 962 15.75 63/4 16 8.0 3300 2800 4000 15 22 48
190 113 127 1.3 4.9 C402_0160 MB33 EZ701U 306 1100 15.75 63/4 16 15 3300 2800 4000 40 22 58
190 113 127 1.3 4.9 C402_0160 MB33 EZ701U 306 1100 15.75 63/4 24 15 3300 2800 4000 40 22 58
190 148 170 1.8 3.7 C402_0160 MB23 EZ503U 573 962 15.75 63/4 8.0 15 3300 2800 4000 19 22 50
190 148 170 1.8 3.7 C402_0160 MB23 EZ503U 573 962 15.75 63/4 12 15 3300 2800 4000 19 22 50
190 183 220 2.2 3.0 C402_0160 MB33 EZ702U 600 1100 15.75 63/4 16 15 3300 2800 4000 45 22 60
190 183 220 2.2 3.0 C402_0160 MB33 EZ702U 600 1100 15.75 63/4 24 15 3300 2800 4000 45 22 60
190 206 244 2.5 2.7 C402_0160 MB23 EZ505U 573 962 15.75 63/4 8.0 15 3300 2800 4000 23 22 53
190 206 244 2.5 2.7 C402_0160 MB23 EZ505U 573 962 15.75 63/4 12 15 3300 2800 4000 23 22 53
214 132 151 1.8 3.9 C402_0140 MB23 EZ503U 509 855 13.99 2015/144 8.0 15 3300 2800 4000 19 22 50
214 132 151 1.8 3.9 C402_0140 MB23 EZ503U 509 855 13.99 2015/144 12 15 3300 2800 4000 19 22 50
214 163 195 2.1 3.3 C402_0140 MB33 EZ702U 550 1100 13.99 2015/144 16 15 3300 2800 4000 46 22 60
214 163 195 2.1 3.3 C402_0140 MB33 EZ702U 550 1100 13.99 2015/144 24 15 3300 2800 4000 46 22 60
214 183 217 2.5 2.8 C402_0140 MB23 EZ505U 509 855 13.99 2015/144 8.0 15 3300 2800 4000 24 22 53
214 183 217 2.5 2.8 C402_0140 MB23 EZ505U 509 855 13.99 2015/144 12 15 3300 2800 4000 24 22 53
240 118 135 1.9 3.9 C402_0125 MB23 EZ503U 455 765 12.52 651/52 8.0 15 3300 2800 4000 20 22 50
240 118 135 1.9 3.9 C402_0125 MB23 EZ503U 455 765 12.52 651/52 12 15 3300 2800 4000 20 22 50
240 146 175 2.1 3.5 C402_0125 MB33 EZ702U 498 1100 12.52 651/52 16 15 3300 2800 4000 46 22 60
240 146 175 2.1 3.5 C402_0125 MB33 EZ702U 498 1100 12.52 651/52 24 15 3300 2800 4000 46 22 60
240 146 175 2.1 3.5 C402_0125 MB33 EZ702U 498 1100 12.52 651/52 32 15 3300 2800 4000 46 22 60
240 164 194 2.6 2.8 C402_0125 MB23 EZ505U 455 765 12.52 651/52 8.0 15 3300 2800 4000 24 22 53
240 164 194 2.6 2.8 C402_0125 MB23 EZ505U 455 765 12.52 651/52 12 15 3300 2800 4000 24 22 53
258 109 125 2.0 3.9 C402_0115 MB23 EZ503U 423 711 11.64 1885/162 8.0 15 2900 2500 4000 20 22 50
258 109 125 2.0 3.9 C402_0115 MB23 EZ503U 423 711 11.64 1885/162 12 15 2900 2500 4000 20 22 50
258 135 163 2.1 3.7 C402_0115 MB33 EZ702U 463 1100 11.64 1885/162 16 15 2900 2500 4000 47 22 60
258 135 163 2.1 3.7 C402_0115 MB33 EZ702U 463 1100 11.64 1885/162 24 15 2900 2500 4000 47 22 60
258 135 163 2.1 3.7 C402_0115 MB33 EZ702U 463 1100 11.64 1885/162 32 15 2900 2500 4000 47 22 60
258 152 181 2.7 2.8 C402_0115 MB23 EZ505U 423 711 11.64 1885/162 8.0 15 2900 2500 4000 25 22 53
258 152 181 2.7 2.8 C402_0115 MB23 EZ505U 423 711 11.64 1885/162 12 15 2900 2500 4000 25 22 53
258 186 235 2.8 2.7 C402_0115 MB33 EZ703U 550 1100 11.64 1885/162 16 32 2900 2500 4000 59 22 63
258 240 341 3.7 2.1 C402_0115 MB33 EZ705U 550 1100 11.64 1885/162 16 32 2900 2500 4000 71 22 68
288 98 112 2.1 3.9 C402_0105 MB23 EZ503U 379 636 10.41 406/39 8.0 15 2900 2500 4000 20 22 50
288 98 112 2.1 3.9 C402_0105 MB23 EZ503U 379 636 10.41 406/39 12 15 2900 2500 4000 20 22 50
288 121 145 2.0 4.0 C402_0105 MB33 EZ702U 414 1100 10.41 406/39 16 15 2900 2500 4000 47 22 60
288 121 145 2.0 4.0 C402_0105 MB33 EZ702U 414 1100 10.41 406/39 24 15 2900 2500 4000 47 22 60
288 121 145 2.0 4.0 C402_0105 MB33 EZ702U 414 1100 10.41 406/39 32 15 2900 2500 4000 47 22 60
288 121 145 2.0 4.0 C402_0105 MB33 EZ702U 414 1100 10.41 406/39 45 15 2900 2500 4000 47 22 60
288 136 162 2.9 2.8 C402_0105 MB23 EZ505U 379 636 10.41 406/39 8.0 15 2900 2500 4000 25 22 53
288 136 162 2.9 2.8 C402_0105 MB23 EZ505U 379 636 10.41 406/39 12 15 2900 2500 4000 25 22 53
288 167 210 2.8 2.9 C402_0105 MB33 EZ703U 600 1100 10.41 406/39 16 32 2900 2500 4000 59 22 63
288 167 210 2.8 2.9 C402_0105 MB33 EZ703U 600 1100 10.41 406/39 24 32 2900 2500 4000 59 22 63
288 215 305 3.6 2.2 C402_0105 MB33 EZ705U 600 1100 10.41 406/39 16 32 2900 2500 4000 71 22 68
288 215 305 3.6 2.2 C402_0105 MB33 EZ705U 600 1100 10.41 406/39 24 32 2900 2500 4000 71 22 68
324 108 129 2.0 4.3 C402_0093 MB33 EZ702U 368 1100 9.261 3445/372 16 15 2900 2500 4000 49 22 60
324 108 129 2.0 4.3 C402_0093 MB33 EZ702U 368 1100 9.261 3445/372 24 15 2900 2500 4000 49 22 60
5.2 Selection tables 5 Chelical geared motors
