Stober PK - Page 99

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C3 (n
1N
= 3000 rpm, M
2acc,max
= 400 Nm)
1378 56 102 6.5 2.5 C302_0022 MB43 EZ803U 267 538 2.177 468/215 72 65 2700 2300 3000 181 7.1 89
1378 56 102 6.5 2.5 C302_0022 MB43 EZ803U 267 538 2.177 468/215 100 65 2700 2300 3000 181 7.1 89
1485 32 41 4.0 4.3 C302_0020 MB33 EZ703U 127 370 2.020 608/301 16 32 2700 2300 4000 62 7.1 53
1485 32 41 4.0 4.3 C302_0020 MB33 EZ703U 127 370 2.020 608/301 24 32 2700 2300 4000 62 7.1 53
1485 32 41 4.0 4.3 C302_0020 MB33 EZ703U 127 370 2.020 608/301 32 32 2700 2300 4000 62 7.1 53
1485 32 41 4.0 4.3 C302_0020 MB33 EZ703U 127 370 2.020 608/301 45 32 2700 2300 4000 62 7.1 53
1485 42 59 5.1 3.3 C302_0020 MB33 EZ705U 196 370 2.020 608/301 16 32 2700 2300 4000 74 7.1 58
1485 42 59 5.1 3.3 C302_0020 MB33 EZ705U 196 370 2.020 608/301 24 32 2700 2300 4000 74 7.1 58
1485 42 59 5.1 3.3 C302_0020 MB33 EZ705U 196 370 2.020 608/301 32 32 2700 2300 4000 74 7.1 58
1485 42 59 5.1 3.3 C302_0020 MB33 EZ705U 196 370 2.020 608/301 45 32 2700 2300 4000 74 7.1 58
1485 52 94 6.4 2.6 C302_0020 MB43 EZ803U 261 499 2.020 608/301 50 65 2700 2300 3000 182 7.1 89
1485 52 94 6.4 2.6 C302_0020 MB43 EZ803U 261 499 2.020 608/301 72 65 2700 2300 3000 182 7.1 89
1485 52 94 6.4 2.6 C302_0020 MB43 EZ803U 261 499 2.020 608/301 100 65 2700 2300 3000 182 7.1 89
C4 (n
1N
= 2000 rpm, M
2acc,max
= 440 Nm)
645 131 199 7.3 2.0 C402_0031 MB43 EZ805U 437 838 3.099 1537/496 50 115 2900 2500 3000 271 17 115
814 104 157 7.0 2.4 C402_0025 MB43 EZ805U 405 665 2.456 609/248 50 115 2500 2100 3000 275 17 115
1016 83 126 6.8 2.7 C402_0020 MB43 EZ805U 376 533 1.968 551/280 50 115 2500 2100 3000 280 17 115
C4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
86 145 159 1.2 3.8 C402_0350 MB23 EZ501U 540 1100 34.82 975/28 8.0 8.0 3500 3200 4000 11 22 47
86 159 176 1.3 3.5 C402_0350 MB23 EZ402U 540 1100 34.82 975/28 8.0 8.0 3500 3200 4000 9.9 22 46
86 233 290 1.9 2.4 C402_0350 MB23 EZ404U 550 1100 34.82 975/28 8.0 8.0 3500 3200 4000 11 22 49
86 250 270 2.0 2.2 C402_0350 MB23 EZ502U 550 1100 34.82 975/28 8.0 8.0 3500 3200 4000 13 22 48
96 130 142 1.1 4.2 C402_0310 MB23 EZ501U 484 1100 31.15 405/13 8.0 8.0 3500 3200 4000 11 22 47
96 130 142 1.1 4.2 C402_0310 MB23 EZ501U 484 1100 31.15 405/13 12 8.0 3500 3200 4000 11 22 47
96 142 157 1.2 3.9 C402_0310 MB23 EZ402U 484 1100 31.15 405/13 8.0 8.0 3500 3200 4000 9.9 22 46
96 142 157 1.2 3.9 C402_0310 MB23 EZ402U 484 1100 31.15 405/13 12 8.0 3500 3200 4000 9.9 22 46
96 209 260 1.8 2.6 C402_0310 MB23 EZ404U 600 1100 31.15 405/13 8.0 8.0 3500 3200 4000 11 22 49
96 209 260 1.8 2.6 C402_0310 MB23 EZ404U 600 1100 31.15 405/13 12 8.0 3500 3200 4000 11 22 49
96 224 242 1.9 2.5 C402_0310 MB23 EZ502U 600 1100 31.15 405/13 8.0 8.0 3500 3200 4000 13 22 48
96 224 242 1.9 2.5 C402_0310 MB23 EZ502U 600 1100 31.15 405/13 12 8.0 3500 3200 4000 13 22 48
108 116 127 1.0 4.7 C402_0280 MB23 EZ501U 432 1100 27.86 195/7 8.0 8.0 3500 3200 4000 12 22 47
108 116 127 1.0 4.7 C402_0280 MB23 EZ501U 432 1100 27.86 195/7 12 8.0 3500 3200 4000 12 22 47
108 127 141 1.1 4.3 C402_0280 MB23 EZ402U 432 1100 27.86 195/7 8.0 8.0 3500 3200 4000 10 22 46
108 127 141 1.1 4.3 C402_0280 MB23 EZ402U 432 1100 27.86 195/7 12 8.0 3500 3200 4000 10 22 46
108 186 232 1.7 3.0 C402_0280 MB23 EZ404U 550 1100 27.86 195/7 8.0 8.0 3500 3200 4000 12 22 49
108 186 232 1.7 3.0 C402_0280 MB23 EZ404U 550 1100 27.86 195/7 12 8.0 3500 3200 4000 12 22 49
108 200 216 1.8 2.8 C402_0280 MB23 EZ502U 550 1100 27.86 195/7 8.0 8.0 3500 3200 4000 14 22 48
108 200 216 1.8 2.8 C402_0280 MB23 EZ502U 550 1100 27.86 195/7 12 8.0 3500 3200 4000 14 22 48
120 114 126 1.1 4.8 C402_0250 MB23 EZ402U 387 1100 24.92 324/13 8.0 8.0 3500 3200 4000 10 22 46
120 114 126 1.1 4.8 C402_0250 MB23 EZ402U 387 1100 24.92 324/13 12 8.0 3500 3200 4000 10 22 46
120 114 126 1.1 4.8 C402_0250 MB23 EZ402U 387 1100 24.92 324/13 16 8.0 3500 3200 4000 10 22 46
120 167 208 1.6 3.3 C402_0250 MB23 EZ404U 600 1100 24.92 324/13 8.0 8.0 3500 3200 4000 12 22 49
120 167 208 1.6 3.3 C402_0250 MB23 EZ404U 600 1100 24.92 324/13 12 8.0 3500 3200 4000 12 22 49
120 167 208 1.6 3.3 C402_0250 MB23 EZ404U 600 1100 24.92 324/13 16 8.0 3500 3200 4000 12 22 49
120 179 193 1.7 3.1 C402_0250 MB23 EZ502U 600 1100 24.92 324/13 8.0 8.0 3500 3200 4000 14 22 48
120 179 193 1.7 3.1 C402_0250 MB23 EZ502U 600 1100 24.92 324/13 12 8.0 3500 3200 4000 14 22 48
120 179 193 1.7 3.1 C402_0250 MB23 EZ502U 600 1100 24.92 324/13 16 8.0 3500 3200 4000 14 22 48
120 235 268 2.2 2.3 C402_0250 MB23 EZ503U 600 1100 24.92 324/13 8.0 15 3500 3200 4000 17 22 50
120 326 387 3.1 1.7 C402_0250 MB23 EZ505U 600 1100 24.92 324/13 8.0 15 3500 3200 4000 22 22 53
128 156 195 1.5 3.5 C402_0230 MB23 EZ404U 550 1100 23.36 1495/64 8.0 8.0 3500 3200 4000 12 22 49
128 156 195 1.5 3.5 C402_0230 MB23 EZ404U 550 1100 23.36 1495/64 12 8.0 3500 3200 4000 12 22 49
128 156 195 1.5 3.5 C402_0230 MB23 EZ404U 550 1100 23.36 1495/64 16 8.0 3500 3200 4000 12 22 49
128 168 181 1.6 3.3 C402_0230 MB23 EZ502U 550 1100 23.36 1495/64 8.0 8.0 3500 3200 4000 14 22 48
128 168 181 1.6 3.3 C402_0230 MB23 EZ502U 550 1100 23.36 1495/64 12 8.0 3500 3200 4000 14 22 48
128 168 181 1.6 3.3 C402_0230 MB23 EZ502U 550 1100 23.36 1495/64 16 8.0 3500 3200 4000 14 22 48
128 220 252 2.2 2.5 C402_0230 MB23 EZ503U 550 1100 23.36 1495/64 8.0 15 3500 3200 4000 18 22 50
128 220 252 2.2 2.5 C402_0230 MB23 EZ503U 550 1100 23.36 1495/64 12 15 3500 3200 4000 18 22 50
128 306 363 3.0 1.8 C402_0230 MB23 EZ505U 550 1100 23.36 1495/64 8.0 15 3500 3200 4000 22 22 53
128 306 363 3.0 1.8 C402_0230 MB23 EZ505U 550 1100 23.36 1495/64 12 15 3500 3200 4000 22 22 53
144 140 174 1.4 3.9 C402_0210 MB23 EZ404U 588 1100 20.90 4347/208 8.0 8.0 3500 3200 4000 12 22 49
144 140 174 1.4 3.9 C402_0210 MB23 EZ404U 588 1100 20.90 4347/208 12 8.0 3500 3200 4000 12 22 49
144 140 174 1.4 3.9 C402_0210 MB23 EZ404U 588 1100 20.90 4347/208 16 8.0 3500 3200 4000 12 22 49
144 150 162 1.6 3.7 C402_0210 MB23 EZ502U 600 1100 20.90 4347/208 8.0 8.0 3500 3200 4000 14 22 48
144 150 162 1.6 3.7 C402_0210 MB23 EZ502U 600 1100 20.90 4347/208 12 8.0 3500 3200 4000 14 22 48
5 Chelical geared motors 5.2 Selection tables
99
