Stober PK - Page 105

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C5 (n
1N
= 3000 rpm, M
2acc,max
= 920 Nm)
386 124 157 2.6 3.9 C502_0078 MB33 EZ703U 489 1250 7.763 621/80 45 32 3400 3000 4000 58 21 75
386 160 227 3.3 3.0 C502_0078 MB33 EZ705U 753 1250 7.763 621/80 16 32 3400 3000 4000 71 21 80
386 160 227 3.3 3.0 C502_0078 MB33 EZ705U 753 1250 7.763 621/80 24 32 3400 3000 4000 71 21 80
386 160 227 3.3 3.0 C502_0078 MB33 EZ705U 753 1250 7.763 621/80 32 32 3400 3000 4000 71 21 80
386 160 227 3.3 3.0 C502_0078 MB33 EZ705U 753 1250 7.763 621/80 45 32 3400 3000 4000 71 21 80
386 200 363 4.1 2.4 C502_0078 MB43 EZ803U 800 1250 7.763 621/80 50 65 3000 3000 3000 179 21 111
513 94 118 2.4 4.7 C502_0059 MB33 EZ703U 369 1072 5.850 117/20 16 32 3100 2700 4000 60 21 75
513 94 118 2.4 4.7 C502_0059 MB33 EZ703U 369 1072 5.850 117/20 24 32 3100 2700 4000 60 21 75
513 94 118 2.4 4.7 C502_0059 MB33 EZ703U 369 1072 5.850 117/20 32 32 3100 2700 4000 60 21 75
513 94 118 2.4 4.7 C502_0059 MB33 EZ703U 369 1072 5.850 117/20 45 32 3100 2700 4000 60 21 75
513 121 171 3.2 3.7 C502_0059 MB33 EZ705U 567 1072 5.850 117/20 16 32 3100 2700 4000 73 21 80
513 121 171 3.2 3.7 C502_0059 MB33 EZ705U 567 1072 5.850 117/20 24 32 3100 2700 4000 73 21 80
513 121 171 3.2 3.7 C502_0059 MB33 EZ705U 567 1072 5.850 117/20 32 32 3100 2700 4000 73 21 80
513 121 171 3.2 3.7 C502_0059 MB33 EZ705U 567 1072 5.850 117/20 45 32 3100 2700 4000 73 21 80
513 151 274 3.9 2.9 C502_0059 MB43 EZ803U 800 1250 5.850 117/20 50 65 3000 2700 3000 181 21 111
513 151 274 3.9 2.9 C502_0059 MB43 EZ803U 800 1250 5.850 117/20 72 65 3000 2700 3000 181 21 111
648 44 50 3.4 3.9 C502_0046 MB23 EZ503U 168 283 4.629 162/35 8.0 15 3100 2700 4000 24 21 62
648 44 50 3.4 3.9 C502_0046 MB23 EZ503U 168 283 4.629 162/35 12 15 3100 2700 4000 24 21 62
648 61 72 4.7 2.8 C502_0046 MB23 EZ505U 168 283 4.629 162/35 8.0 15 3100 2700 4000 29 21 65
648 61 72 4.7 2.8 C502_0046 MB23 EZ505U 168 283 4.629 162/35 12 15 3100 2700 4000 29 21 65
648 96 136 3.0 4.3 C502_0046 MB33 EZ705U 449 849 4.629 162/35 16 32 3100 2700 4000 75 21 80
648 96 136 3.0 4.3 C502_0046 MB33 EZ705U 449 849 4.629 162/35 24 32 3100 2700 4000 75 21 80
648 96 136 3.0 4.3 C502_0046 MB33 EZ705U 449 849 4.629 162/35 32 32 3100 2700 4000 75 21 80
648 96 136 3.0 4.3 C502_0046 MB33 EZ705U 449 849 4.629 162/35 45 32 3100 2700 4000 75 21 80
648 119 216 3.8 3.4 C502_0046 MB43 EZ803U 651 1236 4.629 162/35 50 65 3000 2700 3000 183 21 111
648 119 216 3.8 3.4 C502_0046 MB43 EZ803U 651 1236 4.629 162/35 72 65 3000 2700 3000 183 21 111
648 119 216 3.8 3.4 C502_0046 MB43 EZ803U 651 1236 4.629 162/35 100 65 3000 2700 3000 183 21 111
776 80 113 3.0 4.7 C502_0039 MB33 EZ705U 375 709 3.867 58/15 16 32 2800 2400 4000 78 21 80
776 80 113 3.0 4.7 C502_0039 MB33 EZ705U 375 709 3.867 58/15 24 32 2800 2400 4000 78 21 80
776 80 113 3.0 4.7 C502_0039 MB33 EZ705U 375 709 3.867 58/15 32 32 2800 2400 4000 78 21 80
776 80 113 3.0 4.7 C502_0039 MB33 EZ705U 375 709 3.867 58/15 45 32 2800 2400 4000 78 21 80
776 100 181 3.7 3.9 C502_0039 MB43 EZ803U 544 1047 3.867 58/15 50 65 2800 2400 3000 186 21 111
776 100 181 3.7 3.9 C502_0039 MB43 EZ803U 544 1047 3.867 58/15 72 65 2800 2400 3000 186 21 111
776 100 181 3.7 3.9 C502_0039 MB43 EZ803U 544 1047 3.867 58/15 100 65 2800 2400 3000 186 21 111
975 64 90 3.4 4.7 C502_0031 MB33 EZ705U 298 564 3.077 477/155 16 32 2800 2400 4000 82 21 80
975 64 90 3.4 4.7 C502_0031 MB33 EZ705U 298 564 3.077 477/155 24 32 2800 2400 4000 82 21 80
975 64 90 3.4 4.7 C502_0031 MB33 EZ705U 298 564 3.077 477/155 32 32 2800 2400 4000 82 21 80
975 64 90 3.4 4.7 C502_0031 MB33 EZ705U 298 564 3.077 477/155 45 32 2800 2400 4000 82 21 80
975 79 144 3.5 4.5 C502_0031 MB43 EZ803U 433 834 3.077 477/155 50 65 2800 2400 3000 190 21 111
975 79 144 3.5 4.5 C502_0031 MB43 EZ803U 433 834 3.077 477/155 72 65 2800 2400 3000 190 21 111
975 79 144 3.5 4.5 C502_0031 MB43 EZ803U 433 834 3.077 477/155 100 65 2800 2400 3000 190 21 111
1518 41 58 4.2 4.7 C502_0020 MB33 EZ705U 192 362 1.976 81/41 16 32 2400 2000 3200 97 21 80
1518 41 58 4.2 4.7 C502_0020 MB33 EZ705U 192 362 1.976 81/41 24 32 2400 2000 3200 97 21 80
1518 41 58 4.2 4.7 C502_0020 MB33 EZ705U 192 362 1.976 81/41 32 32 2400 2000 3200 97 21 80
1518 41 58 4.2 4.7 C502_0020 MB33 EZ705U 192 362 1.976 81/41 45 32 2400 2000 3200 97 21 80
C6 (n
1N
= 2000 rpm, M
2acc,max
= 1650 Nm)
198 429 648 3.6 2.6 C612_0100 MB43 EZ805U 1650 2900 10.11 3721/368 50 115 3000 2600 3000 278 74 142
219 387 585 3.5 2.8 C612_0091 MB43 EZ805U 1380 2600 9.118 848/93 50 115 2700 2300 3000 286 74 142
244 347 525 3.5 3.0 C612_0082 MB43 EZ805U 1629 2669 8.190 1769/216 50 115 2700 2300 3000 282 74 142
281 301 456 3.4 3.3 C612_0071 MB43 EZ805U 1380 2318 7.111 64/9 50 115 2300 1900 3000 295 74 142
307 276 418 3.3 3.5 C612_0065 MB43 EZ805U 1296 2124 6.518 3233/496 50 115 2700 2300 3000 289 74 142
342 248 375 3.3 3.8 C612_0059 MB43 EZ805U 1164 1908 5.854 240/41 50 115 2300 1900 3000 305 74 142
393 215 326 3.2 4.2 C612_0051 MB43 EZ805U 1011 1657 5.083 61/12 50 115 2300 1900 3000 299 74 142
478 177 268 3.2 4.6 C612_0042 MB43 EZ805U 832 1364 4.184 2745/656 50 115 2300 1900 3000 310 74 142
C6 (n
1N
= 3000 rpm, M
2acc,max
= 1650 Nm)
66 325 365 1.1 4.0 C612_0450 MB33 EZ701U 879 2600 45.33 136/3 16 15 3200 2900 4000 40 74 84
66 528 633 1.8 2.5 C612_0450 MB33 EZ702U 1380 2600 45.33 136/3 16 15 3200 2900 4000 45 74 87
76 283 317 1.1 4.3 C612_0390 MB33 EZ701U 764 2441 39.40 1891/48 16 15 3200 2900 4000 39 74 84
76 459 550 1.8 2.7 C612_0390 MB33 EZ702U 1465 2441 39.40 1891/48 16 15 3200 2900 4000 44 74 87
86 406 487 1.6 3.2 C612_0350 MB33 EZ702U 1380 2600 34.87 1360/39 16 15 3200 2900 4000 46 74 87
86 406 487 1.6 3.2 C612_0350 MB33 EZ702U 1380 2600 34.87 1360/39 24 15 3200 2900 4000 46 74 87
93 377 453 1.5 3.5 C612_0320 MB33 EZ702U 1289 2900 32.41 1037/32 16 15 3200 2900 4000 45 74 87
93 377 453 1.5 3.5 C612_0320 MB33 EZ702U 1289 2900 32.41 1037/32 24 15 3200 2900 4000 45 74 87
93 377 453 1.5 3.5 C612_0320 MB33 EZ702U 1289 2900 32.41 1037/32 32 15 3200 2900 4000 45 74 87
5 Chelical geared motors 5.2 Selection tables
105
