Stober PK - Page 106

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C6 (n
1N
= 3000 rpm, M
2acc,max
= 1650 Nm)
109 319 383 1.4 4.1 C612_0270 MB33 EZ702U 1091 2600 27.43 192/7 16 15 3200 2900 4000 48 74 87
109 319 383 1.4 4.1 C612_0270 MB33 EZ702U 1091 2600 27.43 192/7 24 15 3200 2900 4000 48 74 87
109 319 383 1.4 4.1 C612_0270 MB33 EZ702U 1091 2600 27.43 192/7 32 15 3200 2900 4000 48 74 87
109 439 553 1.9 3.0 C612_0270 MB33 EZ703U 1380 2600 27.43 192/7 16 32 3200 2900 4000 60 74 90
109 567 804 2.5 2.3 C612_0270 MB33 EZ705U 1380 2600 27.43 192/7 16 32 3200 2900 4000 72 74 95
120 290 348 1.4 4.4 C612_0250 MB33 EZ702U 991 2900 24.93 5185/208 16 15 3200 2900 4000 46 74 87
120 290 348 1.4 4.4 C612_0250 MB33 EZ702U 991 2900 24.93 5185/208 24 15 3200 2900 4000 46 74 87
120 290 348 1.4 4.4 C612_0250 MB33 EZ702U 991 2900 24.93 5185/208 32 15 3200 2900 4000 46 74 87
120 290 348 1.4 4.4 C612_0250 MB33 EZ702U 991 2900 24.93 5185/208 45 15 3200 2900 4000 46 74 87
120 399 503 1.9 3.2 C612_0250 MB33 EZ703U 1572 2900 24.93 5185/208 16 32 3200 2900 4000 58 74 90
120 399 503 1.9 3.2 C612_0250 MB33 EZ703U 1572 2900 24.93 5185/208 24 32 3200 2900 4000 58 74 90
120 399 503 1.9 3.2 C612_0250 MB33 EZ703U 1572 2900 24.93 5185/208 32 32 3200 2900 4000 58 74 90
120 515 730 2.4 2.5 C612_0250 MB33 EZ705U 1650 2900 24.93 5185/208 16 32 3200 2900 4000 71 74 95
120 515 730 2.4 2.5 C612_0250 MB33 EZ705U 1650 2900 24.93 5185/208 24 32 3200 2900 4000 71 74 95
120 515 730 2.4 2.5 C612_0250 MB33 EZ705U 1650 2900 24.93 5185/208 32 32 3200 2900 4000 71 74 95
132 264 317 1.3 4.9 C612_0230 MB33 EZ702U 901 2600 22.67 68/3 16 15 3200 2900 4000 50 74 87
132 264 317 1.3 4.9 C612_0230 MB33 EZ702U 901 2600 22.67 68/3 24 15 3200 2900 4000 50 74 87
132 264 317 1.3 4.9 C612_0230 MB33 EZ702U 901 2600 22.67 68/3 32 15 3200 2900 4000 50 74 87
132 264 317 1.3 4.9 C612_0230 MB33 EZ702U 901 2600 22.67 68/3 45 15 3200 2900 4000 50 74 87
132 363 457 1.8 3.6 C612_0230 MB33 EZ703U 1380 2600 22.67 68/3 16 32 3200 2900 4000 61 74 90
132 363 457 1.8 3.6 C612_0230 MB33 EZ703U 1380 2600 22.67 68/3 24 32 3200 2900 4000 61 74 90
132 468 664 2.3 2.8 C612_0230 MB33 EZ705U 1380 2600 22.67 68/3 16 32 3200 2900 4000 74 74 95
132 468 664 2.3 2.8 C612_0230 MB33 EZ705U 1380 2600 22.67 68/3 24 32 3200 2900 4000 74 74 95
153 314 396 1.7 3.9 C612_0195 MB33 EZ703U 1236 2900 19.61 549/28 16 32 3200 2900 4000 60 74 90
153 314 396 1.7 3.9 C612_0195 MB33 EZ703U 1236 2900 19.61 549/28 24 32 3200 2900 4000 60 74 90
153 314 396 1.7 3.9 C612_0195 MB33 EZ703U 1236 2900 19.61 549/28 32 32 3200 2900 4000 60 74 90
153 314 396 1.7 3.9 C612_0195 MB33 EZ703U 1236 2900 19.61 549/28 45 32 3200 2900 4000 60 74 90
153 405 574 2.3 3.0 C612_0195 MB33 EZ705U 1650 2900 19.61 549/28 16 32 3200 2900 4000 72 74 95
153 405 574 2.3 3.0 C612_0195 MB33 EZ705U 1650 2900 19.61 549/28 24 32 3200 2900 4000 72 74 95
153 405 574 2.3 3.0 C612_0195 MB33 EZ705U 1650 2900 19.61 549/28 32 32 3200 2900 4000 72 74 95
153 405 574 2.3 3.0 C612_0195 MB33 EZ705U 1650 2900 19.61 549/28 45 32 3200 2900 4000 72 74 95
170 282 355 1.7 4.2 C612_0175 MB33 EZ703U 1110 2600 17.60 88/5 16 32 3000 2600 4000 65 74 90
170 282 355 1.7 4.2 C612_0175 MB33 EZ703U 1110 2600 17.60 88/5 24 32 3000 2600 4000 65 74 90
170 282 355 1.7 4.2 C612_0175 MB33 EZ703U 1110 2600 17.60 88/5 32 32 3000 2600 4000 65 74 90
170 282 355 1.7 4.2 C612_0175 MB33 EZ703U 1110 2600 17.60 88/5 45 32 3000 2600 4000 65 74 90
170 364 516 2.2 3.3 C612_0175 MB33 EZ705U 1380 2600 17.60 88/5 16 32 3000 2600 4000 77 74 95
170 364 516 2.2 3.3 C612_0175 MB33 EZ705U 1380 2600 17.60 88/5 24 32 3000 2600 4000 77 74 95
170 364 516 2.2 3.3 C612_0175 MB33 EZ705U 1380 2600 17.60 88/5 32 32 3000 2600 4000 77 74 95
170 364 516 2.2 3.3 C612_0175 MB33 EZ705U 1380 2600 17.60 88/5 45 32 3000 2600 4000 77 74 95
185 259 327 1.7 4.5 C612_0160 MB33 EZ703U 1022 2900 16.20 1037/64 16 32 3200 2900 4000 62 74 90
185 259 327 1.7 4.5 C612_0160 MB33 EZ703U 1022 2900 16.20 1037/64 24 32 3200 2900 4000 62 74 90
185 259 327 1.7 4.5 C612_0160 MB33 EZ703U 1022 2900 16.20 1037/64 32 32 3200 2900 4000 62 74 90
185 259 327 1.7 4.5 C612_0160 MB33 EZ703U 1022 2900 16.20 1037/64 45 32 3200 2900 4000 62 74 90
185 335 475 2.2 3.5 C612_0160 MB33 EZ705U 1572 2900 16.20 1037/64 16 32 3200 2900 4000 74 74 95
185 335 475 2.2 3.5 C612_0160 MB33 EZ705U 1572 2900 16.20 1037/64 24 32 3200 2900 4000 74 74 95
185 335 475 2.2 3.5 C612_0160 MB33 EZ705U 1572 2900 16.20 1037/64 32 32 3200 2900 4000 74 74 95
185 335 475 2.2 3.5 C612_0160 MB33 EZ705U 1572 2900 16.20 1037/64 45 32 3200 2900 4000 74 74 95
185 418 758 2.7 2.8 C612_0160 MB43 EZ803U 1650 2900 16.20 1037/64 50 65 3000 2900 3000 182 74 126
212 226 285 1.6 4.9 C612_0140 MB33 EZ703U 892 2593 14.15 976/69 16 32 3000 2600 4000 68 74 90
212 226 285 1.6 4.9 C612_0140 MB33 EZ703U 892 2593 14.15 976/69 24 32 3000 2600 4000 68 74 90
212 226 285 1.6 4.9 C612_0140 MB33 EZ703U 892 2593 14.15 976/69 32 32 3000 2600 4000 68 74 90
212 226 285 1.6 4.9 C612_0140 MB33 EZ703U 892 2593 14.15 976/69 45 32 3000 2600 4000 68 74 90
212 292 414 2.1 3.8 C612_0140 MB33 EZ705U 1372 2593 14.15 976/69 16 32 3000 2600 4000 81 74 95
212 292 414 2.1 3.8 C612_0140 MB33 EZ705U 1372 2593 14.15 976/69 24 32 3000 2600 4000 81 74 95
212 292 414 2.1 3.8 C612_0140 MB33 EZ705U 1372 2593 14.15 976/69 32 32 3000 2600 4000 81 74 95
212 292 414 2.1 3.8 C612_0140 MB33 EZ705U 1372 2593 14.15 976/69 45 32 3000 2600 4000 81 74 95
212 365 661 2.6 3.0 C612_0140 MB43 EZ803U 1380 2600 14.15 976/69 50 65 3000 2600 3000 189 74 126
238 260 369 2.1 4.1 C612_0125 MB33 EZ705U 1220 2306 12.58 2013/160 16 32 3000 2600 4000 78 74 95
238 260 369 2.1 4.1 C612_0125 MB33 EZ705U 1220 2306 12.58 2013/160 24 32 3000 2600 4000 78 74 95
238 260 369 2.1 4.1 C612_0125 MB33 EZ705U 1220 2306 12.58 2013/160 32 32 3000 2600 4000 78 74 95
238 260 369 2.1 4.1 C612_0125 MB33 EZ705U 1220 2306 12.58 2013/160 45 32 3000 2600 4000 78 74 95
238 325 588 2.6 3.3 C612_0125 MB43 EZ803U 1650 2900 12.58 2013/160 50 65 3000 2600 3000 186 74 126
238 325 588 2.6 3.3 C612_0125 MB43 EZ803U 1650 2900 12.58 2013/160 72 65 3000 2600 3000 186 74 126
262 237 336 2.0 4.4 C612_0115 MB33 EZ705U 1111 2100 11.46 928/81 16 32 2700 2300 3800 85 74 95
5.2 Selection tables 5 Chelical geared motors
106
