Stober PK - Page 142

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
F3 (n
1N
= 3000 rpm, M
2acc,max
= 450 Nm)
524 54 62 2.7 3.7 F302_0057 MB23 EZ503U 208 350 5.720 143/25 12 15 3000 2600 4000 22 20 47
524 67 80 3.4 3.0 F302_0057 MB33 EZ702U 227 642 5.720 143/25 16 15 3000 2600 4000 48 20 57
524 67 80 3.4 3.0 F302_0057 MB33 EZ702U 227 642 5.720 143/25 24 15 3000 2600 4000 48 20 57
524 67 80 3.4 3.0 F302_0057 MB33 EZ702U 227 642 5.720 143/25 32 15 3000 2600 4000 48 20 57
524 67 80 3.4 3.0 F302_0057 MB33 EZ702U 227 642 5.720 143/25 45 15 3000 2600 4000 48 20 57
524 75 89 3.8 2.6 F302_0057 MB23 EZ505U 208 350 5.720 143/25 8.0 15 3000 2600 4000 26 20 50
524 75 89 3.8 2.6 F302_0057 MB23 EZ505U 208 350 5.720 143/25 12 15 3000 2600 4000 26 20 50
524 92 115 4.6 2.2 F302_0057 MB33 EZ703U 350 642 5.720 143/25 16 32 3000 2600 4000 60 20 60
524 92 115 4.6 2.2 F302_0057 MB33 EZ703U 350 642 5.720 143/25 24 32 3000 2600 4000 60 20 60
524 118 168 6.0 1.7 F302_0057 MB33 EZ705U 350 642 5.720 143/25 16 32 3000 2600 4000 73 20 65
524 118 168 6.0 1.7 F302_0057 MB33 EZ705U 350 642 5.720 143/25 24 32 3000 2600 4000 73 20 65
646 44 50 2.9 3.9 F302_0046 MB23 EZ503U 169 284 4.644 4992/1075 8.0 15 3000 2600 4000 24 20 47
646 44 50 2.9 3.9 F302_0046 MB23 EZ503U 169 284 4.644 4992/1075 12 15 3000 2600 4000 24 20 47
646 54 65 3.3 3.4 F302_0046 MB33 EZ702U 185 650 4.644 4992/1075 16 15 3000 2600 4000 51 20 57
646 54 65 3.3 3.4 F302_0046 MB33 EZ702U 185 650 4.644 4992/1075 24 15 3000 2600 4000 51 20 57
646 54 65 3.3 3.4 F302_0046 MB33 EZ702U 185 650 4.644 4992/1075 32 15 3000 2600 4000 51 20 57
646 54 65 3.3 3.4 F302_0046 MB33 EZ702U 185 650 4.644 4992/1075 45 15 3000 2600 4000 51 20 57
646 61 72 4.0 2.8 F302_0046 MB23 EZ505U 169 284 4.644 4992/1075 8.0 15 3000 2600 4000 29 20 50
646 61 72 4.0 2.8 F302_0046 MB23 EZ505U 169 284 4.644 4992/1075 12 15 3000 2600 4000 29 20 50
646 74 94 4.5 2.5 F302_0046 MB33 EZ703U 293 650 4.644 4992/1075 16 32 3000 2600 4000 63 20 60
646 74 94 4.5 2.5 F302_0046 MB33 EZ703U 293 650 4.644 4992/1075 24 32 3000 2600 4000 63 20 60
646 74 94 4.5 2.5 F302_0046 MB33 EZ703U 293 650 4.644 4992/1075 32 32 3000 2600 4000 63 20 60
646 74 94 4.5 2.5 F302_0046 MB33 EZ703U 293 650 4.644 4992/1075 45 32 3000 2600 4000 63 20 60
646 96 136 5.8 1.9 F302_0046 MB33 EZ705U 349 650 4.644 4992/1075 16 32 3000 2600 4000 75 20 65
646 96 136 5.8 1.9 F302_0046 MB33 EZ705U 349 650 4.644 4992/1075 24 32 3000 2600 4000 75 20 65
646 96 136 5.8 1.9 F302_0046 MB33 EZ705U 349 650 4.644 4992/1075 32 32 3000 2600 4000 75 20 65
646 96 136 5.8 1.9 F302_0046 MB33 EZ705U 349 650 4.644 4992/1075 45 32 3000 2600 4000 75 20 65
F4 (n
1N
= 3000 rpm, M
2acc,max
= 700 Nm)
64 196 214 1.1 3.4 F402_0470 MB23 EZ501U 700 1400 46.94 845/18 8.0 8.0 3800 3500 4000 11 39 52
64 214 237 1.2 3.1 F402_0470 MB23 EZ402U 700 1400 46.94 845/18 8.0 8.0 3800 3500 4000 9.8 39 52
64 314 392 1.8 2.1 F402_0470 MB23 EZ404U 700 1400 46.94 845/18 8.0 8.0 3800 3500 4000 11 39 54
64 337 364 1.9 2.0 F402_0470 MB23 EZ502U 700 1400 46.94 845/18 8.0 8.0 3800 3500 4000 13 39 53
86 146 160 1.1 4.1 F402_0350 MB23 EZ501U 544 1400 35.08 2210/63 8.0 8.0 3500 3100 4000 12 39 52
86 146 160 1.1 4.1 F402_0350 MB23 EZ501U 544 1400 35.08 2210/63 12 8.0 3500 3100 4000 12 39 52
86 160 177 1.2 3.7 F402_0350 MB23 EZ402U 544 1400 35.08 2210/63 8.0 8.0 3500 3100 4000 10 39 52
86 160 177 1.2 3.7 F402_0350 MB23 EZ402U 544 1400 35.08 2210/63 12 8.0 3500 3100 4000 10 39 52
86 235 293 1.7 2.6 F402_0350 MB23 EZ404U 700 1400 35.08 2210/63 8.0 8.0 3500 3100 4000 12 39 54
86 235 293 1.7 2.6 F402_0350 MB23 EZ404U 700 1400 35.08 2210/63 12 8.0 3500 3100 4000 12 39 54
86 252 272 1.8 2.4 F402_0350 MB23 EZ502U 700 1400 35.08 2210/63 8.0 8.0 3500 3100 4000 14 39 53
86 252 272 1.8 2.4 F402_0350 MB23 EZ502U 700 1400 35.08 2210/63 12 8.0 3500 3100 4000 14 39 53
107 117 128 1.0 4.8 F402_0280 MB23 EZ501U 434 1400 27.99 2015/72 8.0 8.0 3500 3100 4000 12 39 52
107 117 128 1.0 4.8 F402_0280 MB23 EZ501U 434 1400 27.99 2015/72 12 8.0 3500 3100 4000 12 39 52
107 117 128 1.0 4.8 F402_0280 MB23 EZ501U 434 1400 27.99 2015/72 16 8.0 3500 3100 4000 12 39 52
107 128 141 1.1 4.4 F402_0280 MB23 EZ402U 434 1400 27.99 2015/72 8.0 8.0 3500 3100 4000 11 39 52
107 128 141 1.1 4.4 F402_0280 MB23 EZ402U 434 1400 27.99 2015/72 12 8.0 3500 3100 4000 11 39 52
107 128 141 1.1 4.4 F402_0280 MB23 EZ402U 434 1400 27.99 2015/72 16 8.0 3500 3100 4000 11 39 52
107 187 233 1.7 3.0 F402_0280 MB23 EZ404U 700 1400 27.99 2015/72 8.0 8.0 3500 3100 4000 12 39 54
107 187 233 1.7 3.0 F402_0280 MB23 EZ404U 700 1400 27.99 2015/72 12 8.0 3500 3100 4000 12 39 54
107 187 233 1.7 3.0 F402_0280 MB23 EZ404U 700 1400 27.99 2015/72 16 8.0 3500 3100 4000 12 39 54
107 201 217 1.8 2.8 F402_0280 MB23 EZ502U 700 1400 27.99 2015/72 8.0 8.0 3500 3100 4000 14 39 53
107 201 217 1.8 2.8 F402_0280 MB23 EZ502U 700 1400 27.99 2015/72 12 8.0 3500 3100 4000 14 39 53
107 201 217 1.8 2.8 F402_0280 MB23 EZ502U 700 1400 27.99 2015/72 16 8.0 3500 3100 4000 14 39 53
107 263 301 2.3 2.1 F402_0280 MB23 EZ503U 700 1400 27.99 2015/72 8.0 15 3500 3100 4000 18 39 55
107 263 301 2.3 2.1 F402_0280 MB23 EZ503U 700 1400 27.99 2015/72 12 15 3500 3100 4000 18 39 55
107 366 434 3.2 1.5 F402_0280 MB23 EZ505U 700 1400 27.99 2015/72 8.0 15 3500 3100 4000 22 39 58
107 366 434 3.2 1.5 F402_0280 MB23 EZ505U 700 1400 27.99 2015/72 12 15 3500 3100 4000 22 39 58
129 106 117 1.1 4.9 F402_0230 MB23 EZ402U 360 1400 23.21 325/14 8.0 8.0 3200 2800 4000 11 39 52
129 106 117 1.1 4.9 F402_0230 MB23 EZ402U 360 1400 23.21 325/14 12 8.0 3200 2800 4000 11 39 52
129 106 117 1.1 4.9 F402_0230 MB23 EZ402U 360 1400 23.21 325/14 16 8.0 3200 2800 4000 11 39 52
129 155 194 1.6 3.4 F402_0230 MB23 EZ404U 653 1400 23.21 325/14 8.0 8.0 3200 2800 4000 13 39 54
129 155 194 1.6 3.4 F402_0230 MB23 EZ404U 653 1400 23.21 325/14 12 8.0 3200 2800 4000 13 39 54
129 155 194 1.6 3.4 F402_0230 MB23 EZ404U 653 1400 23.21 325/14 16 8.0 3200 2800 4000 13 39 54
129 167 180 1.7 3.1 F402_0230 MB23 EZ502U 698 1400 23.21 325/14 8.0 8.0 3200 2800 4000 15 39 53
129 167 180 1.7 3.1 F402_0230 MB23 EZ502U 698 1400 23.21 325/14 12 8.0 3200 2800 4000 15 39 53
6.2 Selection tables 6 Foffset helical geared motors
142
