Stober PK - Page 143

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
F4 (n
1N
= 3000 rpm, M
2acc,max
= 700 Nm)
129 167 180 1.7 3.1 F402_0230 MB23 EZ502U 698 1400 23.21 325/14 16 8.0 3200 2800 4000 15 39 53
129 167 187 1.7 3.1 F402_0230 MB33 EZ701U 450 1400 23.21 325/14 16 15 3200 2800 4000 40 39 63
129 218 250 2.3 2.4 F402_0230 MB23 EZ503U 700 1400 23.21 325/14 8.0 15 3200 2800 4000 18 39 55
129 218 250 2.3 2.4 F402_0230 MB23 EZ503U 700 1400 23.21 325/14 12 15 3200 2800 4000 18 39 55
129 270 324 2.8 1.9 F402_0230 MB33 EZ702U 700 1400 23.21 325/14 16 15 3200 2800 4000 45 39 65
129 304 360 3.1 1.7 F402_0230 MB23 EZ505U 700 1400 23.21 325/14 8.0 15 3200 2800 4000 23 39 58
129 304 360 3.1 1.7 F402_0230 MB23 EZ505U 700 1400 23.21 325/14 12 15 3200 2800 4000 23 39 58
161 125 155 1.5 3.9 F402_0185 MB23 EZ404U 524 1138 18.62 3575/192 8.0 8.0 3200 2800 4000 14 39 54
161 125 155 1.5 3.9 F402_0185 MB23 EZ404U 524 1138 18.62 3575/192 12 8.0 3200 2800 4000 14 39 54
161 125 155 1.5 3.9 F402_0185 MB23 EZ404U 524 1138 18.62 3575/192 16 8.0 3200 2800 4000 14 39 54
161 134 144 1.7 3.6 F402_0185 MB23 EZ502U 560 1138 18.62 3575/192 8.0 8.0 3200 2800 4000 16 39 53
161 134 144 1.7 3.6 F402_0185 MB23 EZ502U 560 1138 18.62 3575/192 12 8.0 3200 2800 4000 16 39 53
161 134 144 1.7 3.6 F402_0185 MB23 EZ502U 560 1138 18.62 3575/192 16 8.0 3200 2800 4000 16 39 53
161 134 150 1.7 3.6 F402_0185 MB33 EZ701U 361 1400 18.62 3575/192 16 15 3200 2800 4000 41 39 63
161 134 150 1.7 3.6 F402_0185 MB33 EZ701U 361 1400 18.62 3575/192 24 15 3200 2800 4000 41 39 63
161 175 200 2.2 2.8 F402_0185 MB23 EZ503U 677 1138 18.62 3575/192 8.0 15 3200 2800 4000 19 39 55
161 175 200 2.2 2.8 F402_0185 MB23 EZ503U 677 1138 18.62 3575/192 12 15 3200 2800 4000 19 39 55
161 217 260 2.7 2.2 F402_0185 MB33 EZ702U 700 1400 18.62 3575/192 16 15 3200 2800 4000 46 39 65
161 217 260 2.7 2.2 F402_0185 MB33 EZ702U 700 1400 18.62 3575/192 24 15 3200 2800 4000 46 39 65
161 244 289 3.0 2.0 F402_0185 MB23 EZ505U 677 1138 18.62 3575/192 8.0 15 3200 2800 4000 24 39 58
161 244 289 3.0 2.0 F402_0185 MB23 EZ505U 677 1138 18.62 3575/192 12 15 3200 2800 4000 24 39 58
221 91 113 1.5 4.8 F402_0135 MB23 EZ404U 382 829 13.57 5984/441 8.0 8.0 3500 3100 4000 13 39 54
221 91 113 1.5 4.8 F402_0135 MB23 EZ404U 382 829 13.57 5984/441 12 8.0 3500 3100 4000 13 39 54
221 91 113 1.5 4.8 F402_0135 MB23 EZ404U 382 829 13.57 5984/441 16 8.0 3500 3100 4000 13 39 54
221 97 105 1.6 4.5 F402_0135 MB23 EZ502U 408 829 13.57 5984/441 8.0 8.0 3500 3100 4000 15 39 53
221 97 105 1.6 4.5 F402_0135 MB23 EZ502U 408 829 13.57 5984/441 12 8.0 3500 3100 4000 15 39 53
221 97 105 1.6 4.5 F402_0135 MB23 EZ502U 408 829 13.57 5984/441 16 8.0 3500 3100 4000 15 39 53
221 97 109 1.6 4.5 F402_0135 MB33 EZ701U 263 1100 13.57 5984/441 16 15 3500 3100 4000 40 39 63
221 97 109 1.6 4.5 F402_0135 MB33 EZ701U 263 1100 13.57 5984/441 24 15 3500 3100 4000 40 39 63
221 97 109 1.6 4.5 F402_0135 MB33 EZ701U 263 1100 13.57 5984/441 32 15 3500 3100 4000 40 39 63
221 128 146 2.1 3.4 F402_0135 MB23 EZ503U 494 829 13.57 5984/441 8.0 15 3500 3100 4000 18 39 55
221 128 146 2.1 3.4 F402_0135 MB23 EZ503U 494 829 13.57 5984/441 12 15 3500 3100 4000 18 39 55
221 158 190 2.6 2.8 F402_0135 MB33 EZ702U 540 1100 13.57 5984/441 16 15 3500 3100 4000 45 39 65
221 158 190 2.6 2.8 F402_0135 MB33 EZ702U 540 1100 13.57 5984/441 24 15 3500 3100 4000 45 39 65
221 158 190 2.6 2.8 F402_0135 MB33 EZ702U 540 1100 13.57 5984/441 32 15 3500 3100 4000 45 39 65
221 178 211 2.9 2.5 F402_0135 MB23 EZ505U 494 829 13.57 5984/441 8.0 15 3500 3100 4000 23 39 58
221 178 211 2.9 2.5 F402_0135 MB23 EZ505U 494 829 13.57 5984/441 12 15 3500 3100 4000 23 39 58
277 102 117 2.0 3.9 F402_0110 MB23 EZ503U 394 662 10.83 682/63 8.0 15 3500 3100 4000 20 39 55
277 102 117 2.0 3.9 F402_0110 MB23 EZ503U 394 662 10.83 682/63 12 15 3500 3100 4000 20 39 55
277 126 151 2.5 3.2 F402_0110 MB33 EZ702U 431 1100 10.83 682/63 16 15 3500 3100 4000 46 39 65
277 126 151 2.5 3.2 F402_0110 MB33 EZ702U 431 1100 10.83 682/63 24 15 3500 3100 4000 46 39 65
277 126 151 2.5 3.2 F402_0110 MB33 EZ702U 431 1100 10.83 682/63 32 15 3500 3100 4000 46 39 65
277 126 151 2.5 3.2 F402_0110 MB33 EZ702U 431 1100 10.83 682/63 45 15 3500 3100 4000 46 39 65
277 142 168 2.8 2.8 F402_0110 MB23 EZ505U 394 662 10.83 682/63 8.0 15 3500 3100 4000 24 39 58
277 142 168 2.8 2.8 F402_0110 MB23 EZ505U 394 662 10.83 682/63 12 15 3500 3100 4000 24 39 58
277 173 218 3.4 2.3 F402_0110 MB33 EZ703U 550 1100 10.83 682/63 16 32 3500 3100 4000 58 39 68
277 224 317 4.4 1.8 F402_0110 MB33 EZ705U 550 1100 10.83 682/63 16 32 3500 3100 4000 70 39 74
334 84 97 2.2 3.9 F402_0090 MB23 EZ503U 327 549 8.980 440/49 8.0 15 3200 2800 4000 21 39 55
334 84 97 2.2 3.9 F402_0090 MB23 EZ503U 327 549 8.980 440/49 12 15 3200 2800 4000 21 39 55
334 105 125 2.4 3.6 F402_0090 MB33 EZ702U 357 1100 8.980 440/49 16 15 3200 2800 4000 48 39 65
334 105 125 2.4 3.6 F402_0090 MB33 EZ702U 357 1100 8.980 440/49 24 15 3200 2800 4000 48 39 65
334 105 125 2.4 3.6 F402_0090 MB33 EZ702U 357 1100 8.980 440/49 32 15 3200 2800 4000 48 39 65
334 105 125 2.4 3.6 F402_0090 MB33 EZ702U 357 1100 8.980 440/49 45 15 3200 2800 4000 48 39 65
334 118 139 3.1 2.8 F402_0090 MB23 EZ505U 327 549 8.980 440/49 8.0 15 3200 2800 4000 25 39 58
334 118 139 3.1 2.8 F402_0090 MB23 EZ505U 327 549 8.980 440/49 12 15 3200 2800 4000 25 39 58
334 144 181 3.3 2.6 F402_0090 MB33 EZ703U 550 1100 8.980 440/49 16 32 3200 2800 4000 59 39 68
334 144 181 3.3 2.6 F402_0090 MB33 EZ703U 550 1100 8.980 440/49 24 32 3200 2800 4000 59 39 68
334 144 181 3.3 2.6 F402_0090 MB33 EZ703U 550 1100 8.980 440/49 32 32 3200 2800 4000 59 39 68
334 186 263 4.2 2.1 F402_0090 MB33 EZ705U 550 1100 8.980 440/49 16 32 3200 2800 4000 72 39 74
334 186 263 4.2 2.1 F402_0090 MB33 EZ705U 550 1100 8.980 440/49 24 32 3200 2800 4000 72 39 74
334 186 263 4.2 2.1 F402_0090 MB33 EZ705U 550 1100 8.980 440/49 32 32 3200 2800 4000 72 39 74
417 68 78 2.5 3.9 F402_0072 MB23 EZ503U 262 440 7.202 605/84 8.0 15 3200 2800 4000 23 39 55
417 68 78 2.5 3.9 F402_0072 MB23 EZ503U 262 440 7.202 605/84 12 15 3200 2800 4000 23 39 55
417 84 101 2.3 4.2 F402_0072 MB33 EZ702U 286 1100 7.202 605/84 16 15 3200 2800 4000 50 39 65
6 Foffset helical geared motors 6.2 Selection tables
