Stober PK - Page 144

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
F4 (n
1N
= 3000 rpm, M
2acc,max
= 700 Nm)
417 84 101 2.3 4.2 F402_0072 MB33 EZ702U 286 1100 7.202 605/84 24 15 3200 2800 4000 50 39 65
417 84 101 2.3 4.2 F402_0072 MB33 EZ702U 286 1100 7.202 605/84 32 15 3200 2800 4000 50 39 65
417 84 101 2.3 4.2 F402_0072 MB33 EZ702U 286 1100 7.202 605/84 45 15 3200 2800 4000 50 39 65
417 94 112 3.5 2.8 F402_0072 MB23 EZ505U 262 440 7.202 605/84 8.0 15 3200 2800 4000 28 39 58
417 94 112 3.5 2.8 F402_0072 MB23 EZ505U 262 440 7.202 605/84 12 15 3200 2800 4000 28 39 58
417 115 145 3.2 3.1 F402_0072 MB33 EZ703U 454 1100 7.202 605/84 16 32 3200 2800 4000 62 39 68
417 115 145 3.2 3.1 F402_0072 MB33 EZ703U 454 1100 7.202 605/84 24 32 3200 2800 4000 62 39 68
417 115 145 3.2 3.1 F402_0072 MB33 EZ703U 454 1100 7.202 605/84 32 32 3200 2800 4000 62 39 68
417 115 145 3.2 3.1 F402_0072 MB33 EZ703U 454 1100 7.202 605/84 45 32 3200 2800 4000 62 39 68
417 149 211 4.1 2.4 F402_0072 MB33 EZ705U 550 1100 7.202 605/84 16 32 3200 2800 4000 74 39 74
417 149 211 4.1 2.4 F402_0072 MB33 EZ705U 550 1100 7.202 605/84 24 32 3200 2800 4000 74 39 74
417 149 211 4.1 2.4 F402_0072 MB33 EZ705U 550 1100 7.202 605/84 32 32 3200 2800 4000 74 39 74
417 149 211 4.1 2.4 F402_0072 MB33 EZ705U 550 1100 7.202 605/84 45 32 3200 2800 4000 74 39 74
516 68 81 2.2 4.9 F402_0058 MB33 EZ702U 231 1066 5.813 3784/651 16 15 2700 2300 4000 53 39 65
516 68 81 2.2 4.9 F402_0058 MB33 EZ702U 231 1066 5.813 3784/651 24 15 2700 2300 4000 53 39 65
516 68 81 2.2 4.9 F402_0058 MB33 EZ702U 231 1066 5.813 3784/651 32 15 2700 2300 4000 53 39 65
516 68 81 2.2 4.9 F402_0058 MB33 EZ702U 231 1066 5.813 3784/651 45 15 2700 2300 4000 53 39 65
516 93 117 3.1 3.5 F402_0058 MB33 EZ703U 367 1066 5.813 3784/651 16 32 2700 2300 4000 65 39 68
516 93 117 3.1 3.5 F402_0058 MB33 EZ703U 367 1066 5.813 3784/651 24 32 2700 2300 4000 65 39 68
516 93 117 3.1 3.5 F402_0058 MB33 EZ703U 367 1066 5.813 3784/651 32 32 2700 2300 4000 65 39 68
516 93 117 3.1 3.5 F402_0058 MB33 EZ703U 367 1066 5.813 3784/651 45 32 2700 2300 4000 65 39 68
516 120 170 3.9 2.7 F402_0058 MB33 EZ705U 550 1066 5.813 3784/651 16 32 2700 2300 4000 77 39 74
516 120 170 3.9 2.7 F402_0058 MB33 EZ705U 550 1066 5.813 3784/651 24 32 2700 2300 4000 77 39 74
516 120 170 3.9 2.7 F402_0058 MB33 EZ705U 550 1066 5.813 3784/651 32 32 2700 2300 4000 77 39 74
516 120 170 3.9 2.7 F402_0058 MB33 EZ705U 550 1066 5.813 3784/651 45 32 2700 2300 4000 77 39 74
516 150 272 4.9 2.2 F402_0058 MB43 EZ803U 550 1100 5.813 3784/651 50 65 2700 2300 3000 185 39 104
641 75 94 2.9 4.1 F402_0047 MB33 EZ703U 295 858 4.678 1408/301 16 32 2700 2300 4000 69 39 68
641 75 94 2.9 4.1 F402_0047 MB33 EZ703U 295 858 4.678 1408/301 24 32 2700 2300 4000 69 39 68
641 75 94 2.9 4.1 F402_0047 MB33 EZ703U 295 858 4.678 1408/301 32 32 2700 2300 4000 69 39 68
641 75 94 2.9 4.1 F402_0047 MB33 EZ703U 295 858 4.678 1408/301 45 32 2700 2300 4000 69 39 68
641 97 137 3.8 3.2 F402_0047 MB33 EZ705U 454 858 4.678 1408/301 16 32 2700 2300 4000 82 39 74
641 97 137 3.8 3.2 F402_0047 MB33 EZ705U 454 858 4.678 1408/301 24 32 2700 2300 4000 82 39 74
641 97 137 3.8 3.2 F402_0047 MB33 EZ705U 454 858 4.678 1408/301 32 32 2700 2300 4000 82 39 74
641 97 137 3.8 3.2 F402_0047 MB33 EZ705U 454 858 4.678 1408/301 45 32 2700 2300 4000 82 39 74
641 121 219 4.7 2.5 F402_0047 MB43 EZ803U 550 1100 4.678 1408/301 50 65 2700 2300 3000 190 39 104
641 121 219 4.7 2.5 F402_0047 MB43 EZ803U 550 1100 4.678 1408/301 72 65 2700 2300 3000 190 39 104
F6 (n
1N
= 2000 rpm, M
2acc,max
= 880 Nm)
353 240 364 4.9 2.6 F602_0057 MB43 EZ805U 1000 1537 5.673 1407/248 50 115 2500 2100 3000 287 73 147
440 193 291 4.7 3.0 F602_0045 MB43 EZ805U 904 1232 4.546 1273/280 50 115 2500 2100 3000 299 73 147
F6 (n
1N
= 3000 rpm, M
2acc,max
= 1100 Nm)
54 232 254 0.8 4.7 F602_0560 MB23 EZ501U 865 2000 55.71 390/7 8.0 8.0 3500 3200 4000 12 77 79
54 232 254 0.8 4.7 F602_0560 MB23 EZ501U 865 2000 55.71 390/7 12 8.0 3500 3200 4000 12 77 79
54 254 281 0.9 4.3 F602_0560 MB23 EZ402U 865 2000 55.71 390/7 8.0 8.0 3500 3200 4000 10 77 79
54 254 281 0.9 4.3 F602_0560 MB23 EZ402U 865 2000 55.71 390/7 12 8.0 3500 3200 4000 10 77 79
54 373 465 1.4 3.0 F602_0560 MB23 EZ404U 1100 2000 55.71 390/7 8.0 8.0 3500 3200 4000 12 77 81
54 373 465 1.4 3.0 F602_0560 MB23 EZ404U 1100 2000 55.71 390/7 12 8.0 3500 3200 4000 12 77 81
54 400 432 1.5 2.8 F602_0560 MB23 EZ502U 1100 2000 55.71 390/7 8.0 8.0 3500 3200 4000 14 77 80
54 400 432 1.5 2.8 F602_0560 MB23 EZ502U 1100 2000 55.71 390/7 12 8.0 3500 3200 4000 14 77 80
64 313 390 1.2 3.5 F602_0470 MB23 EZ404U 1100 2000 46.72 1495/32 8.0 8.0 3500 3200 4000 12 77 81
64 313 390 1.2 3.5 F602_0470 MB23 EZ404U 1100 2000 46.72 1495/32 12 8.0 3500 3200 4000 12 77 81
64 313 390 1.2 3.5 F602_0470 MB23 EZ404U 1100 2000 46.72 1495/32 16 8.0 3500 3200 4000 12 77 81
64 335 363 1.3 3.3 F602_0470 MB23 EZ502U 1100 2000 46.72 1495/32 8.0 8.0 3500 3200 4000 15 77 80
64 335 363 1.3 3.3 F602_0470 MB23 EZ502U 1100 2000 46.72 1495/32 12 8.0 3500 3200 4000 15 77 80
64 335 363 1.3 3.3 F602_0470 MB23 EZ502U 1100 2000 46.72 1495/32 16 8.0 3500 3200 4000 15 77 80
64 440 503 1.8 2.5 F602_0470 MB23 EZ503U 1100 2000 46.72 1495/32 8.0 15 3500 3200 4000 18 77 82
64 612 725 2.4 1.8 F602_0470 MB23 EZ505U 1100 2000 46.72 1495/32 8.0 15 3500 3200 4000 23 77 85
85 236 294 1.2 4.3 F602_0350 MB23 EZ404U 990 2000 35.21 845/24 8.0 8.0 3300 2800 4000 13 77 81
85 236 294 1.2 4.3 F602_0350 MB23 EZ404U 990 2000 35.21 845/24 12 8.0 3300 2800 4000 13 77 81
85 236 294 1.2 4.3 F602_0350 MB23 EZ404U 990 2000 35.21 845/24 16 8.0 3300 2800 4000 13 77 81
85 253 273 1.3 4.0 F602_0350 MB23 EZ502U 1059 2000 35.21 845/24 8.0 8.0 3300 2800 4000 16 77 80
85 253 273 1.3 4.0 F602_0350 MB23 EZ502U 1059 2000 35.21 845/24 12 8.0 3300 2800 4000 16 77 80
85 253 273 1.3 4.0 F602_0350 MB23 EZ502U 1059 2000 35.21 845/24 16 8.0 3300 2800 4000 16 77 80
85 253 283 1.3 4.0 F602_0350 MB33 EZ701U 683 2000 35.21 845/24 16 15 3300 2800 4000 41 77 90
85 331 379 1.7 3.0 F602_0350 MB23 EZ503U 1100 2000 35.21 845/24 8.0 15 3300 2800 4000 19 77 82
6.2 Selection tables 6 Foffset helical geared motors
144
