Stober PK - Page 18

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P7 (n
1N
= 3000 rpm, M
2acc,max
= 810 Nm)
750 83 117 10 4.7 P731_0040 MB33 EZ705U 388 388 733 4.000 4/1 45 32 2500 4000 69 69 46
1000 62 88 23 3.9 P731_0030 MB33 EZ705U 291 291 550 3.000 3/1 16 32 2200 4000 74 68 46
1000 62 88 23 3.9 P731_0030 MB33 EZ705U 291 291 550 3.000 3/1 24 32 2200 4000 74 68 46
1000 62 88 23 3.9 P731_0030 MB33 EZ705U 291 291 550 3.000 3/1 32 32 2200 4000 74 68 46
1000 62 88 23 3.9 P731_0030 MB33 EZ705U 291 291 550 3.000 3/1 45 32 2200 4000 74 68 46
P8 (n
1N
= 2000 rpm, M
2acc,max
= 1500 Nm)
200 424 641 3.8 1.8 P831_0100 MB43 EZ805U 1380 1380 2760 10.00 10/1 50 115 2800 3000 260 150 104
250 339 513 4.8 2.4 P831_0080 MB43 EZ805U 1500 1500 2607 8.000 8/1 50 115 2800 3000 262 162 104
286 297 449 4.5 3.4 P831_0070 MB43 EZ805U 1392 1392 2281 7.000 7/1 50 115 2800 3000 263 170 104
400 212 321 6.9 4.6 P831_0050 MB43 EZ805U 994 994 1630 5.000 5/1 50 115 2500 3000 268 185 104
500 170 256 11 4.6 P831_0040 MB43 EZ805U 795 795 1304 4.000 4/1 50 115 2000 3000 276 187 104
667 127 192 21 4.6 P831_0030 MB43 EZ805U 597 597 978 3.000 3/1 50 115 1800 3000 299 190 104
P8 (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
60 352 394 0.6 3.6 P832_0500 MB33 EZ701U 950 950 3230 50.00 50/1 16 15 3000 4000 36 173 55
60 570 684 1.0 2.2 P832_0500 MB33 EZ702U 1840 1948 3230 50.00 50/1 16 15 3000 4000 42 173 58
75 281 315 0.9 3.6 P832_0400 MB33 EZ701U 760 760 3200 40.00 40/1 16 15 3000 4000 36 168 55
75 281 315 0.9 3.6 P832_0400 MB33 EZ701U 760 760 3200 40.00 40/1 24 15 3000 4000 36 168 55
75 456 547 1.4 2.2 P832_0400 MB33 EZ702U 1558 1558 3200 40.00 40/1 16 15 3000 4000 42 168 58
75 456 547 1.4 2.2 P832_0400 MB33 EZ702U 1558 1558 3200 40.00 40/1 24 15 3000 4000 42 168 58
86 399 479 1.2 3.2 P832_0350 MB33 EZ702U 1363 1363 3230 35.00 35/1 16 15 3000 4000 42 176 58
86 399 479 1.2 3.2 P832_0350 MB33 EZ702U 1363 1363 3230 35.00 35/1 24 15 3000 4000 42 176 58
86 399 479 1.2 3.2 P832_0350 MB33 EZ702U 1363 1363 3230 35.00 35/1 32 15 3000 4000 42 176 58
86 549 692 1.6 2.3 P832_0350 MB33 EZ703U 1840 2000 3230 35.00 35/1 16 32 3000 4000 54 176 60
86 708 1004 2.1 1.8 P832_0350 MB33 EZ705U 1840 2000 3230 35.00 35/1 16 32 3000 4000 66 176 66
94 225 252 1.0 4.5 P832_0320 MB33 EZ701U 608 608 3049 32.00 32/1 16 15 2700 4000 39 159 55
94 225 252 1.0 4.5 P832_0320 MB33 EZ701U 608 608 3049 32.00 32/1 24 15 2700 4000 39 159 55
94 225 252 1.0 4.5 P832_0320 MB33 EZ701U 608 608 3049 32.00 32/1 32 15 2700 4000 39 159 55
94 365 438 1.6 2.8 P832_0320 MB33 EZ702U 1246 1246 3049 32.00 32/1 16 15 2700 4000 45 159 58
94 365 438 1.6 2.8 P832_0320 MB33 EZ702U 1246 1246 3049 32.00 32/1 24 15 2700 4000 45 159 58
94 365 438 1.6 2.8 P832_0320 MB33 EZ702U 1246 1246 3049 32.00 32/1 32 15 2700 4000 45 159 58
94 502 632 2.1 2.0 P832_0320 MB33 EZ703U 1525 1595 3049 32.00 32/1 16 32 2700 4000 56 159 60
94 648 918 2.8 1.6 P832_0320 MB33 EZ705U 1525 1595 3049 32.00 32/1 16 32 2700 4000 69 159 66
107 319 383 1.7 3.2 P832_0280 MB33 EZ702U 1091 1091 3200 28.00 28/1 16 15 3000 4000 42 172 58
107 319 383 1.7 3.2 P832_0280 MB33 EZ702U 1091 1091 3200 28.00 28/1 24 15 3000 4000 42 172 58
107 319 383 1.7 3.2 P832_0280 MB33 EZ702U 1091 1091 3200 28.00 28/1 32 15 3000 4000 42 172 58
107 439 553 2.3 2.3 P832_0280 MB33 EZ703U 1600 1600 3200 28.00 28/1 16 32 3000 4000 54 172 60
107 567 803 3.0 1.8 P832_0280 MB33 EZ705U 1600 1600 3200 28.00 28/1 16 32 3000 4000 67 172 66
120 285 342 1.4 4.4 P832_0250 MB33 EZ702U 974 974 3230 25.00 25/1 16 15 2900 4000 43 177 58
120 285 342 1.4 4.4 P832_0250 MB33 EZ702U 974 974 3230 25.00 25/1 24 15 2900 4000 43 177 58
120 285 342 1.4 4.4 P832_0250 MB33 EZ702U 974 974 3230 25.00 25/1 32 15 2900 4000 43 177 58
120 285 342 1.4 4.4 P832_0250 MB33 EZ702U 974 974 3230 25.00 25/1 45 15 2900 4000 43 177 58
120 392 494 1.9 3.2 P832_0250 MB33 EZ703U 1544 1544 3230 25.00 25/1 16 32 2900 4000 55 177 60
120 392 494 1.9 3.2 P832_0250 MB33 EZ703U 1544 1544 3230 25.00 25/1 24 32 2900 4000 55 177 60
120 392 494 1.9 3.2 P832_0250 MB33 EZ703U 1544 1544 3230 25.00 25/1 32 32 2900 4000 55 177 60
120 506 717 2.5 2.5 P832_0250 MB33 EZ705U 1840 2000 3230 25.00 25/1 16 32 2900 4000 68 177 66
120 506 717 2.5 2.5 P832_0250 MB33 EZ705U 1840 2000 3230 25.00 25/1 24 32 2900 4000 68 177 66
120 506 717 2.5 2.5 P832_0250 MB33 EZ705U 1840 2000 3230 25.00 25/1 32 32 2900 4000 68 177 66
150 314 395 2.2 4.0 P832_0200 MB33 EZ703U 1235 1235 3230 20.00 20/1 16 32 2700 4000 57 177 60
150 314 395 2.2 4.0 P832_0200 MB33 EZ703U 1235 1235 3230 20.00 20/1 24 32 2700 4000 57 177 60
150 314 395 2.2 4.0 P832_0200 MB33 EZ703U 1235 1235 3230 20.00 20/1 32 32 2700 4000 57 177 60
150 314 395 2.2 4.0 P832_0200 MB33 EZ703U 1235 1235 3230 20.00 20/1 45 32 2700 4000 57 177 60
150 405 574 2.8 3.1 P832_0200 MB33 EZ705U 1840 1900 3230 20.00 20/1 16 32 2700 4000 69 177 66
150 405 574 2.8 3.1 P832_0200 MB33 EZ705U 1840 1900 3230 20.00 20/1 24 32 2700 4000 69 177 66
150 405 574 2.8 3.1 P832_0200 MB33 EZ705U 1840 1900 3230 20.00 20/1 32 32 2700 4000 69 177 66
150 405 574 2.8 3.1 P832_0200 MB33 EZ705U 1840 1900 3230 20.00 20/1 45 32 2700 4000 69 177 66
188 251 316 3.0 4.0 P832_0160 MB33 EZ703U 988 988 2873 16.00 16/1 16 32 2700 4000 57 174 60
188 251 316 3.0 4.0 P832_0160 MB33 EZ703U 988 988 2873 16.00 16/1 24 32 2700 4000 57 174 60
188 251 316 3.0 4.0 P832_0160 MB33 EZ703U 988 988 2873 16.00 16/1 32 32 2700 4000 57 174 60
188 251 316 3.0 4.0 P832_0160 MB33 EZ703U 988 988 2873 16.00 16/1 45 32 2700 4000 57 174 60
188 324 459 3.9 3.1 P832_0160 MB33 EZ705U 1520 1520 2873 16.00 16/1 16 32 2700 4000 70 174 66
188 324 459 3.9 3.1 P832_0160 MB33 EZ705U 1520 1520 2873 16.00 16/1 24 32 2700 4000 70 174 66
188 324 459 3.9 3.1 P832_0160 MB33 EZ705U 1520 1520 2873 16.00 16/1 32 32 2700 4000 70 174 66
188 324 459 3.9 3.1 P832_0160 MB33 EZ705U 1520 1520 2873 16.00 16/1 45 32 2700 4000 70 174 66
250 188 237 4.4 4.3 P832_0120 MB33 EZ703U 741 741 2155 12.00 12/1 16 32 2200 4000 59 168 60
250 188 237 4.4 4.3 P832_0120 MB33 EZ703U 741 741 2155 12.00 12/1 24 32 2200 4000 59 168 60
