Stober PK - Page 19

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P8 (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
250 188 237 4.4 4.3 P832_0120 MB33 EZ703U 741 741 2155 12.00 12/1 32 32 2200 4000 59 168 60
250 188 237 4.4 4.3 P832_0120 MB33 EZ703U 741 741 2155 12.00 12/1 45 32 2200 4000 59 168 60
250 243 344 5.7 3.3 P832_0120 MB33 EZ705U 1140 1140 2155 12.00 12/1 16 32 2200 4000 71 168 66
250 243 344 5.7 3.3 P832_0120 MB33 EZ705U 1140 1140 2155 12.00 12/1 24 32 2200 4000 71 168 66
250 243 344 5.7 3.3 P832_0120 MB33 EZ705U 1140 1140 2155 12.00 12/1 32 32 2200 4000 71 168 66
250 243 344 5.7 3.3 P832_0120 MB33 EZ705U 1140 1140 2155 12.00 12/1 45 32 2200 4000 71 168 66
300 258 468 2.7 2.6 P831_0100 MB43 EZ803U 1380 1380 2760 10.00 10/1 50 65 2800 3000 172 150 88
300 258 468 2.7 2.6 P831_0100 MB43 EZ803U 1380 1380 2760 10.00 10/1 72 65 2800 3000 172 150 88
300 258 468 2.7 2.6 P831_0100 MB43 EZ803U 1380 1380 2760 10.00 10/1 100 65 2800 3000 172 150 88
375 206 374 3.4 3.4 P831_0080 MB43 EZ803U 1125 1125 2607 8.000 8/1 50 65 2800 3000 173 162 88
375 206 374 3.4 3.4 P831_0080 MB43 EZ803U 1125 1125 2607 8.000 8/1 72 65 2800 3000 173 162 88
375 206 374 3.4 3.4 P831_0080 MB43 EZ803U 1125 1125 2607 8.000 8/1 100 65 2800 3000 173 162 88
429 181 327 3.2 4.8 P831_0070 MB43 EZ803U 985 985 2281 7.000 7/1 50 65 2800 3000 175 170 88
429 181 327 3.2 4.8 P831_0070 MB43 EZ803U 985 985 2281 7.000 7/1 72 65 2800 3000 175 170 88
429 181 327 3.2 4.8 P831_0070 MB43 EZ803U 985 985 2281 7.000 7/1 100 65 2800 3000 175 170 88
P9 (n
1N
= 2000 rpm, M
2acc,max
= 3450 Nm)
100 830 1256 3.1 3.0 P932_0200 MB43 EZ805U 3450 – 6384 20.00 20/1 50 115 2000 3000 276 407 138
125 664 1005 4.4 3.0 P932_0160 MB43 EZ805U 3000 – 5107 16.00 16/1 50 115 2000 3000 277 406 138
P9 (n
1N
= 3000 rpm, M
2acc,max
= 3300 Nm)
86 884 1603 1.5 2.7 P932_0350 MB43 EZ803U 3300 – 6600 35.00 35/1 50 65 2800 3000 175 404 122
107 708 1282 1.8 3.2 P932_0280 MB43 EZ803U 3000 – 6000 28.00 28/1 50 65 2800 3000 175 402 122
120 632 1145 1.7 3.9 P932_0250 MB43 EZ803U 3300 – 6600 25.00 25/1 50 65 2500 3000 180 407 122
120 632 1145 1.7 3.9 P932_0250 MB43 EZ803U 3300 – 6600 25.00 25/1 72 65 2500 3000 180 407 122
150 505 916 1.9 4.9 P932_0200 MB43 EZ803U 2755 – 6384 20.00 20/1 50 65 2000 3000 187 407 122
150 505 916 1.9 4.9 P932_0200 MB43 EZ803U 2755 – 6384 20.00 20/1 72 65 2000 3000 187 407 122
150 505 916 1.9 4.9 P932_0200 MB43 EZ803U 2755 – 6384 20.00 20/1 100 65 2000 3000 187 407 122
188 404 733 2.7 4.9 P932_0160 MB43 EZ803U 2204 – 5107 16.00 16/1 50 65 2000 3000 188 406 122
188 404 733 2.7 4.9 P932_0160 MB43 EZ803U 2204 – 5107 16.00 16/1 72 65 2000 3000 188 406 122
188 404 733 2.7 4.9 P932_0160 MB43 EZ803U 2204 – 5107 16.00 16/1 100 65 2000 3000 188 406 122
2 Pplanetary geared motors 2.2 Selection tables
