n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P831K (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
50 390 486 30 2.2 P831_0100K202_0060 MB23 EZ404U 1380 1380 2760 60.00 60/1 16 8.0 3000 2600 4000 12 132 63
50 418 452 32 2.0 P831_0100K202_0060 MB23 EZ502U 1380 1380 2760 60.00 60/1 8.0 8.0 3000 2600 4000 14 132 63
50 418 452 32 2.0 P831_0100K202_0060 MB23 EZ502U 1380 1380 2760 60.00 60/1 12 8.0 3000 2600 4000 14 132 63
50 418 452 32 2.0 P831_0100K202_0060 MB23 EZ502U 1380 1380 2760 60.00 60/1 16 8.0 3000 2600 4000 14 132 63
50 548 627 42 1.6 P831_0100K202_0060 MB23 EZ503U 1380 1380 2760 60.00 60/1 8.0 15 3000 2600 4000 18 132 65
50 762 903 58 1.1 P831_0100K202_0060 MB23 EZ505U 1380 1380 2760 60.00 60/1 8.0 15 3000 2600 4000 22 132 68
51 238 260 15 3.4 P831_0070K202_0084 MB23 EZ501U 885 880 2887 58.78 17458/297 8.0 8.0 3500 3100 4000 11 128 61
51 238 260 15 3.4 P831_0070K202_0084 MB23 EZ501U 885 880 2887 58.78 17458/297 12 8.0 3500 3100 4000 11 128 61
51 238 260 15 3.4 P831_0070K202_0084 MB23 EZ501U 885 880 2887 58.78 17458/297 16 8.0 3500 3100 4000 11 128 61
51 260 288 16 3.1 P831_0070K202_0084 MB23 EZ402U 885 880 2887 58.78 17458/297 8.0 8.0 3500 3100 4000 9.8 128 61
51 260 288 16 3.1 P831_0070K202_0084 MB23 EZ402U 885 880 2887 58.78 17458/297 12 8.0 3500 3100 4000 9.8 128 61
51 260 288 16 3.1 P831_0070K202_0084 MB23 EZ402U 885 880 2887 58.78 17458/297 16 8.0 3500 3100 4000 9.8 128 61
51 382 476 24 2.1 P831_0070K202_0084 MB23 EZ404U 1494 1490 2887 58.78 17458/297 8.0 8.0 3500 3100 4000 11 128 63
51 382 476 24 2.1 P831_0070K202_0084 MB23 EZ404U 1494 1490 2887 58.78 17458/297 12 8.0 3500 3100 4000 11 128 63
51 382 476 24 2.1 P831_0070K202_0084 MB23 EZ404U 1494 1490 2887 58.78 17458/297 16 8.0 3500 3100 4000 11 128 63
51 409 442 26 2.0 P831_0070K202_0084 MB23 EZ502U 1494 1490 2887 58.78 17458/297 8.0 8.0 3500 3100 4000 13 128 63
51 409 442 26 2.0 P831_0070K202_0084 MB23 EZ502U 1494 1490 2887 58.78 17458/297 12 8.0 3500 3100 4000 13 128 63
51 409 442 26 2.0 P831_0070K202_0084 MB23 EZ502U 1494 1490 2887 58.78 17458/297 16 8.0 3500 3100 4000 13 128 63
51 536 614 34 1.5 P831_0070K202_0084 MB23 EZ503U 1494 1490 2887 58.78 17458/297 8.0 15 3500 3100 4000 17 128 65
51 536 614 34 1.5 P831_0070K202_0084 MB23 EZ503U 1494 1490 2887 58.78 17458/297 12 15 3500 3100 4000 17 128 65
51 747 885 47 1.1 P831_0070K202_0084 MB23 EZ505U 1494 1490 2887 58.78 17458/297 8.0 15 3500 3100 4000 22 128 68
51 747 885 47 1.1 P831_0070K202_0084 MB23 EZ505U 1494 1490 2887 58.78 17458/297 12 15 3500 3100 4000 22 128 68
52 235 257 9.3 4.7 P831_0050K302_0115 MB23 EZ501U 874 870 3230 58.05 1161/20 8.0 8.0 3200 2800 4000 12 128 66
52 235 257 9.3 4.7 P831_0050K302_0115 MB23 EZ501U 874 870 3230 58.05 1161/20 12 8.0 3200 2800 4000 12 128 66
52 235 257 9.3 4.7 P831_0050K302_0115 MB23 EZ501U 874 870 3230 58.05 1161/20 16 8.0 3200 2800 4000 12 128 66
52 257 284 10 4.3 P831_0050K302_0115 MB23 EZ402U 874 870 3230 58.05 1161/20 8.0 8.0 3200 2800 4000 10 128 66
52 257 284 10 4.3 P831_0050K302_0115 MB23 EZ402U 874 870 3230 58.05 1161/20 12 8.0 3200 2800 4000 10 128 66
52 257 284 10 4.3 P831_0050K302_0115 MB23 EZ402U 874 870 3230 58.05 1161/20 16 8.0 3200 2800 4000 10 128 66
52 377 470 15 2.9 P831_0050K302_0115 MB23 EZ404U 1584 1580 3230 58.05 1161/20 8.0 8.0 3200 2800 4000 12 128 68
52 377 470 15 2.9 P831_0050K302_0115 MB23 EZ404U 1584 1580 3230 58.05 1161/20 12 8.0 3200 2800 4000 12 128 68
52 377 470 15 2.9 P831_0050K302_0115 MB23 EZ404U 1584 1580 3230 58.05 1161/20 16 8.0 3200 2800 4000 12 128 68
52 404 437 16 2.7 P831_0050K302_0115 MB23 EZ502U 1693 1690 3230 58.05 1161/20 8.0 8.0 3200 2800 4000 14 128 68
52 404 437 16 2.7 P831_0050K302_0115 MB23 EZ502U 1693 1690 3230 58.05 1161/20 12 8.0 3200 2800 4000 14 128 68
52 404 437 16 2.7 P831_0050K302_0115 MB23 EZ502U 1693 1690 3230 58.05 1161/20 16 8.0 3200 2800 4000 14 128 68
52 404 453 16 2.7 P831_0050K302_0115 MB33 EZ701U 1092 1090 3230 58.05 1161/20 16 15 3200 2800 4000 39 128 77
52 530 606 21 2.1 P831_0050K302_0115 MB23 EZ503U 1840 1870 3230 58.05 1161/20 8.0 15 3200 2800 4000 18 128 70
52 530 606 21 2.1 P831_0050K302_0115 MB23 EZ503U 1840 1870 3230 58.05 1161/20 12 15 3200 2800 4000 18 128 70
52 655 787 26 1.7 P831_0050K302_0115 MB33 EZ702U 1840 1870 3230 58.05 1161/20 16 15 3200 2800 4000 44 128 80
52 737 874 29 1.5 P831_0050K302_0115 MB23 EZ505U 1840 1870 3230 58.05 1161/20 8.0 15 3200 2800 4000 22 128 73
52 737 874 29 1.5 P831_0050K302_0115 MB23 EZ505U 1840 1870 3230 58.05 1161/20 12 15 3200 2800 4000 22 128 73
58 209 229 18 4.1 P831_0100K202_0052 MB23 EZ501U 779 780 2760 51.77 21070/407 8.0 8.0 3000 2600 4000 12 132 61
58 209 229 18 4.1 P831_0100K202_0052 MB23 EZ501U 779 780 2760 51.77 21070/407 12 8.0 3000 2600 4000 12 132 61
58 209 229 18 4.1 P831_0100K202_0052 MB23 EZ501U 779 780 2760 51.77 21070/407 16 8.0 3000 2600 4000 12 132 61
58 229 253 20 3.7 P831_0100K202_0052 MB23 EZ402U 779 780 2760 51.77 21070/407 8.0 8.0 3000 2600 4000 11 132 61
58 229 253 20 3.7 P831_0100K202_0052 MB23 EZ402U 779 780 2760 51.77 21070/407 12 8.0 3000 2600 4000 11 132 61
58 229 253 20 3.7 P831_0100K202_0052 MB23 EZ402U 779 780 2760 51.77 21070/407 16 8.0 3000 2600 4000 11 132 61
58 336 419 29 2.5 P831_0100K202_0052 MB23 EZ404U 1380 1380 2760 51.77 21070/407 8.0 8.0 3000 2600 4000 12 132 63
58 336 419 29 2.5 P831_0100K202_0052 MB23 EZ404U 1380 1380 2760 51.77 21070/407 12 8.0 3000 2600 4000 12 132 63
58 336 419 29 2.5 P831_0100K202_0052 MB23 EZ404U 1380 1380 2760 51.77 21070/407 16 8.0 3000 2600 4000 12 132 63
58 360 390 31 2.4 P831_0100K202_0052 MB23 EZ502U 1380 1380 2760 51.77 21070/407 8.0 8.0 3000 2600 4000 14 132 63
58 360 390 31 2.4 P831_0100K202_0052 MB23 EZ502U 1380 1380 2760 51.77 21070/407 12 8.0 3000 2600 4000 14 132 63
58 360 390 31 2.4 P831_0100K202_0052 MB23 EZ502U 1380 1380 2760 51.77 21070/407 16 8.0 3000 2600 4000 14 132 63
58 472 541 40 1.8 P831_0100K202_0052 MB23 EZ503U 1380 1380 2760 51.77 21070/407 8.0 15 3000 2600 4000 18 132 65
58 472 541 40 1.8 P831_0100K202_0052 MB23 EZ503U 1380 1380 2760 51.77 21070/407 12 15 3000 2600 4000 18 132 65
58 658 779 56 1.3 P831_0100K202_0052 MB23 EZ505U 1380 1380 2760 51.77 21070/407 8.0 15 3000 2600 4000 22 132 68
58 658 779 56 1.3 P831_0100K202_0052 MB23 EZ505U 1380 1380 2760 51.77 21070/407 12 15 3000 2600 4000 22 132 68
60 202 220 15 3.8 P831_0070K202_0071 MB23 EZ501U 750 750 2887 49.83 14749/296 8.0 8.0 3000 2600 4000 12 128 61
60 202 220 15 3.8 P831_0070K202_0071 MB23 EZ501U 750 750 2887 49.83 14749/296 12 8.0 3000 2600 4000 12 128 61
60 202 220 15 3.8 P831_0070K202_0071 MB23 EZ501U 750 750 2887 49.83 14749/296 16 8.0 3000 2600 4000 12 128 61
60 220 244 17 3.4 P831_0070K202_0071 MB23 EZ402U 750 750 2887 49.83 14749/296 8.0 8.0 3000 2600 4000 10 128 61
60 220 244 17 3.4 P831_0070K202_0071 MB23 EZ402U 750 750 2887 49.83 14749/296 12 8.0 3000 2600 4000 10 128 61
60 220 244 17 3.4 P831_0070K202_0071 MB23 EZ402U 750 750 2887 49.83 14749/296 16 8.0 3000 2600 4000 10 128 61
60 323 403 24 2.3 P831_0070K202_0071 MB23 EZ404U 1360 1360 2887 49.83 14749/296 8.0 8.0 3000 2600 4000 12 128 63
60 323 403 24 2.3 P831_0070K202_0071 MB23 EZ404U 1360 1360 2887 49.83 14749/296 12 8.0 3000 2600 4000 12 128 63
7 PKright-angle planetary geared motors 7.2 Selection tables
