Stober PK - Page 192

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P831K (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
60 323 403 24 2.3 P831_0070K202_0071 MB23 EZ404U 1360 1360 2887 49.83 14749/296 16 8.0 3000 2600 4000 12 128 63
60 347 375 26 2.2 P831_0070K202_0071 MB23 EZ502U 1436 1440 2887 49.83 14749/296 8.0 8.0 3000 2600 4000 14 128 63
60 347 375 26 2.2 P831_0070K202_0071 MB23 EZ502U 1436 1440 2887 49.83 14749/296 12 8.0 3000 2600 4000 14 128 63
60 347 375 26 2.2 P831_0070K202_0071 MB23 EZ502U 1436 1440 2887 49.83 14749/296 16 8.0 3000 2600 4000 14 128 63
60 347 389 26 2.2 P831_0070K202_0071 MB33 EZ701U 938 940 2887 49.83 14749/296 16 15 3000 2600 4000 39 128 72
60 455 520 34 1.7 P831_0070K202_0071 MB23 EZ503U 1436 1440 2887 49.83 14749/296 8.0 15 3000 2600 4000 18 128 65
60 455 520 34 1.7 P831_0070K202_0071 MB23 EZ503U 1436 1440 2887 49.83 14749/296 12 15 3000 2600 4000 18 128 65
60 563 675 42 1.4 P831_0070K202_0071 MB33 EZ702U 1436 1440 2887 49.83 14749/296 16 15 3000 2600 4000 44 128 75
60 633 750 48 1.2 P831_0070K202_0071 MB23 EZ505U 1436 1440 2887 49.83 14749/296 8.0 15 3000 2600 4000 22 128 68
60 633 750 48 1.2 P831_0070K202_0071 MB23 EZ505U 1436 1440 2887 49.83 14749/296 12 15 3000 2600 4000 22 128 68
64 189 207 15 3.9 P831_0070K202_0067 MB23 EZ501U 704 700 2773 46.78 15953/341 8.0 8.0 3500 3100 4000 11 128 61
64 189 207 15 3.9 P831_0070K202_0067 MB23 EZ501U 704 700 2773 46.78 15953/341 12 8.0 3500 3100 4000 11 128 61
64 189 207 15 3.9 P831_0070K202_0067 MB23 EZ501U 704 700 2773 46.78 15953/341 16 8.0 3500 3100 4000 11 128 61
64 207 229 17 3.6 P831_0070K202_0067 MB23 EZ402U 704 700 2773 46.78 15953/341 8.0 8.0 3500 3100 4000 10 128 61
64 207 229 17 3.6 P831_0070K202_0067 MB23 EZ402U 704 700 2773 46.78 15953/341 12 8.0 3500 3100 4000 10 128 61
64 207 229 17 3.6 P831_0070K202_0067 MB23 EZ402U 704 700 2773 46.78 15953/341 16 8.0 3500 3100 4000 10 128 61
64 304 379 25 2.4 P831_0070K202_0067 MB23 EZ404U 1276 1280 2773 46.78 15953/341 8.0 8.0 3500 3100 4000 12 128 63
64 304 379 25 2.4 P831_0070K202_0067 MB23 EZ404U 1276 1280 2773 46.78 15953/341 12 8.0 3500 3100 4000 12 128 63
64 304 379 25 2.4 P831_0070K202_0067 MB23 EZ404U 1276 1280 2773 46.78 15953/341 16 8.0 3500 3100 4000 12 128 63
64 326 352 26 2.3 P831_0070K202_0067 MB23 EZ502U 1365 1360 2773 46.78 15953/341 8.0 8.0 3500 3100 4000 14 128 63
64 326 352 26 2.3 P831_0070K202_0067 MB23 EZ502U 1365 1360 2773 46.78 15953/341 12 8.0 3500 3100 4000 14 128 63
64 326 352 26 2.3 P831_0070K202_0067 MB23 EZ502U 1365 1360 2773 46.78 15953/341 16 8.0 3500 3100 4000 14 128 63
64 326 365 26 2.3 P831_0070K202_0067 MB33 EZ701U 880 880 2887 46.78 15953/341 16 15 3500 3100 4000 39 128 72
64 427 489 35 1.7 P831_0070K202_0067 MB23 EZ503U 1406 1410 2773 46.78 15953/341 8.0 15 3500 3100 4000 17 128 65
64 427 489 35 1.7 P831_0070K202_0067 MB23 EZ503U 1406 1410 2773 46.78 15953/341 12 15 3500 3100 4000 17 128 65
64 528 634 43 1.4 P831_0070K202_0067 MB33 EZ702U 1406 1410 2887 46.78 15953/341 16 15 3500 3100 4000 44 128 75
64 594 704 48 1.3 P831_0070K202_0067 MB23 EZ505U 1406 1410 2773 46.78 15953/341 8.0 15 3500 3100 4000 22 128 68
64 594 704 48 1.3 P831_0070K202_0067 MB23 EZ505U 1406 1410 2773 46.78 15953/341 12 15 3500 3100 4000 22 128 68
65 301 375 15 3.5 P831_0050K302_0093 MB23 EZ404U 1264 1260 2747 46.34 5375/116 8.0 8.0 3200 2800 4000 12 128 68
65 301 375 15 3.5 P831_0050K302_0093 MB23 EZ404U 1264 1260 2747 46.34 5375/116 12 8.0 3200 2800 4000 12 128 68
65 301 375 15 3.5 P831_0050K302_0093 MB23 EZ404U 1264 1260 2747 46.34 5375/116 16 8.0 3200 2800 4000 12 128 68
65 323 349 16 3.2 P831_0050K302_0093 MB23 EZ502U 1351 1350 2747 46.34 5375/116 8.0 8.0 3200 2800 4000 15 128 68
65 323 349 16 3.2 P831_0050K302_0093 MB23 EZ502U 1351 1350 2747 46.34 5375/116 12 8.0 3200 2800 4000 15 128 68
65 323 349 16 3.2 P831_0050K302_0093 MB23 EZ502U 1351 1350 2747 46.34 5375/116 16 8.0 3200 2800 4000 15 128 68
65 323 362 16 3.2 P831_0050K302_0093 MB33 EZ701U 872 870 3230 46.34 5375/116 16 15 3200 2800 4000 40 128 77
65 323 362 16 3.2 P831_0050K302_0093 MB33 EZ701U 872 870 3230 46.34 5375/116 24 15 3200 2800 4000 40 128 77
65 423 484 21 2.5 P831_0050K302_0093 MB23 EZ503U 1635 1630 2747 46.34 5375/116 8.0 15 3200 2800 4000 18 128 70
65 423 484 21 2.5 P831_0050K302_0093 MB23 EZ503U 1635 1630 2747 46.34 5375/116 12 15 3200 2800 4000 18 128 70
65 523 628 26 2.0 P831_0050K302_0093 MB33 EZ702U 1787 1790 3230 46.34 5375/116 16 15 3200 2800 4000 45 128 80
65 523 628 26 2.0 P831_0050K302_0093 MB33 EZ702U 1787 1790 3230 46.34 5375/116 24 15 3200 2800 4000 45 128 80
65 589 698 29 1.8 P831_0050K302_0093 MB23 EZ505U 1635 1630 2747 46.34 5375/116 8.0 15 3200 2800 4000 23 128 73
65 589 698 29 1.8 P831_0050K302_0093 MB23 EZ505U 1635 1630 2747 46.34 5375/116 12 15 3200 2800 4000 23 128 73
71 170 186 15 4.2 P831_0070K202_0060 MB23 EZ501U 632 630 2490 42.00 42/1 8.0 8.0 3000 2600 4000 12 128 61
71 170 186 15 4.2 P831_0070K202_0060 MB23 EZ501U 632 630 2490 42.00 42/1 12 8.0 3000 2600 4000 12 128 61
71 170 186 15 4.2 P831_0070K202_0060 MB23 EZ501U 632 630 2490 42.00 42/1 16 8.0 3000 2600 4000 12 128 61
71 186 205 17 3.9 P831_0070K202_0060 MB23 EZ402U 632 630 2490 42.00 42/1 8.0 8.0 3000 2600 4000 11 128 61
71 186 205 17 3.9 P831_0070K202_0060 MB23 EZ402U 632 630 2490 42.00 42/1 12 8.0 3000 2600 4000 11 128 61
71 186 205 17 3.9 P831_0070K202_0060 MB23 EZ402U 632 630 2490 42.00 42/1 16 8.0 3000 2600 4000 11 128 61
71 273 340 25 2.6 P831_0070K202_0060 MB23 EZ404U 1146 1150 2490 42.00 42/1 8.0 8.0 3000 2600 4000 12 128 63
71 273 340 25 2.6 P831_0070K202_0060 MB23 EZ404U 1146 1150 2490 42.00 42/1 12 8.0 3000 2600 4000 12 128 63
71 273 340 25 2.6 P831_0070K202_0060 MB23 EZ404U 1146 1150 2490 42.00 42/1 16 8.0 3000 2600 4000 12 128 63
71 292 316 27 2.5 P831_0070K202_0060 MB23 EZ502U 1225 1230 2490 42.00 42/1 8.0 8.0 3000 2600 4000 14 128 63
71 292 316 27 2.5 P831_0070K202_0060 MB23 EZ502U 1225 1230 2490 42.00 42/1 12 8.0 3000 2600 4000 14 128 63
71 292 316 27 2.5 P831_0070K202_0060 MB23 EZ502U 1225 1230 2490 42.00 42/1 16 8.0 3000 2600 4000 14 128 63
71 292 328 27 2.5 P831_0070K202_0060 MB33 EZ701U 790 790 2887 42.00 42/1 16 15 3000 2600 4000 39 128 72
71 292 328 27 2.5 P831_0070K202_0060 MB33 EZ701U 790 790 2887 42.00 42/1 24 15 3000 2600 4000 39 128 72
71 383 439 35 1.9 P831_0070K202_0060 MB23 EZ503U 1356 1360 2490 42.00 42/1 8.0 15 3000 2600 4000 18 128 65
71 383 439 35 1.9 P831_0070K202_0060 MB23 EZ503U 1356 1360 2490 42.00 42/1 12 15 3000 2600 4000 18 128 65
71 474 569 43 1.5 P831_0070K202_0060 MB33 EZ702U 1356 1360 2887 42.00 42/1 16 15 3000 2600 4000 45 128 75
71 474 569 43 1.5 P831_0070K202_0060 MB33 EZ702U 1356 1360 2887 42.00 42/1 24 15 3000 2600 4000 45 128 75
71 533 632 48 1.3 P831_0070K202_0060 MB23 EZ505U 1356 1360 2490 42.00 42/1 8.0 15 3000 2600 4000 23 128 68
71 533 632 48 1.3 P831_0070K202_0060 MB23 EZ505U 1356 1360 2490 42.00 42/1 12 15 3000 2600 4000 23 128 68
75 177 196 18 4.8 P831_0100K202_0040 MB23 EZ402U 602 600 2371 40.00 40/1 8.0 8.0 3000 2600 4000 12 132 61
75 177 196 18 4.8 P831_0100K202_0040 MB23 EZ402U 602 600 2371 40.00 40/1 12 8.0 3000 2600 4000 12 132 61
7.2 Selection tables 7 PKright-angle planetary geared motors
192
