n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P831K (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
75 177 196 18 4.8 P831_0100K202_0040 MB23 EZ402U 602 600 2371 40.00 40/1 16 8.0 3000 2600 4000 12 132 61
75 260 324 27 3.3 P831_0100K202_0040 MB23 EZ404U 1091 1090 2371 40.00 40/1 8.0 8.0 3000 2600 4000 13 132 63
75 260 324 27 3.3 P831_0100K202_0040 MB23 EZ404U 1091 1090 2371 40.00 40/1 12 8.0 3000 2600 4000 13 132 63
75 260 324 27 3.3 P831_0100K202_0040 MB23 EZ404U 1091 1090 2371 40.00 40/1 16 8.0 3000 2600 4000 13 132 63
75 279 301 29 3.1 P831_0100K202_0040 MB23 EZ502U 1167 1170 2371 40.00 40/1 8.0 8.0 3000 2600 4000 15 132 63
75 279 301 29 3.1 P831_0100K202_0040 MB23 EZ502U 1167 1170 2371 40.00 40/1 12 8.0 3000 2600 4000 15 132 63
75 279 301 29 3.1 P831_0100K202_0040 MB23 EZ502U 1167 1170 2371 40.00 40/1 16 8.0 3000 2600 4000 15 132 63
75 279 312 29 3.1 P831_0100K202_0040 MB33 EZ701U 753 750 2760 40.00 40/1 16 15 3000 2600 4000 40 132 72
75 279 312 29 3.1 P831_0100K202_0040 MB33 EZ701U 753 750 2760 40.00 40/1 24 15 3000 2600 4000 40 132 72
75 365 418 38 2.3 P831_0100K202_0040 MB23 EZ503U 1380 1380 2371 40.00 40/1 8.0 15 3000 2600 4000 19 132 65
75 365 418 38 2.3 P831_0100K202_0040 MB23 EZ503U 1380 1380 2371 40.00 40/1 12 15 3000 2600 4000 19 132 65
75 452 542 47 1.9 P831_0100K202_0040 MB33 EZ702U 1380 1380 2760 40.00 40/1 16 15 3000 2600 4000 45 132 75
75 452 542 47 1.9 P831_0100K202_0040 MB33 EZ702U 1380 1380 2760 40.00 40/1 24 15 3000 2600 4000 45 132 75
75 508 602 53 1.7 P831_0100K202_0040 MB23 EZ505U 1380 1380 2371 40.00 40/1 8.0 15 3000 2600 4000 23 132 68
75 508 602 53 1.7 P831_0100K202_0040 MB23 EZ505U 1380 1380 2371 40.00 40/1 12 15 3000 2600 4000 23 132 68
81 240 299 15 4.0 P831_0050K302_0074 MB23 EZ404U 1008 1010 2191 36.96 2365/64 8.0 8.0 2700 2300 4000 13 128 68
81 240 299 15 4.0 P831_0050K302_0074 MB23 EZ404U 1008 1010 2191 36.96 2365/64 12 8.0 2700 2300 4000 13 128 68
81 240 299 15 4.0 P831_0050K302_0074 MB23 EZ404U 1008 1010 2191 36.96 2365/64 16 8.0 2700 2300 4000 13 128 68
81 257 278 16 3.7 P831_0050K302_0074 MB23 EZ502U 1078 1080 2191 36.96 2365/64 8.0 8.0 2700 2300 4000 15 128 68
81 257 278 16 3.7 P831_0050K302_0074 MB23 EZ502U 1078 1080 2191 36.96 2365/64 12 8.0 2700 2300 4000 15 128 68
81 257 278 16 3.7 P831_0050K302_0074 MB23 EZ502U 1078 1080 2191 36.96 2365/64 16 8.0 2700 2300 4000 15 128 68
81 257 289 16 3.7 P831_0050K302_0074 MB33 EZ701U 695 700 3230 36.96 2365/64 16 15 2700 2300 4000 40 128 77
81 257 289 16 3.7 P831_0050K302_0074 MB33 EZ701U 695 700 3230 36.96 2365/64 24 15 2700 2300 4000 40 128 77
81 257 289 16 3.7 P831_0050K302_0074 MB33 EZ701U 695 700 3230 36.96 2365/64 32 15 2700 2300 4000 40 128 77
81 337 386 22 2.9 P831_0050K302_0074 MB23 EZ503U 1304 1300 2191 36.96 2365/64 8.0 15 2700 2300 4000 19 128 70
81 337 386 22 2.9 P831_0050K302_0074 MB23 EZ503U 1304 1300 2191 36.96 2365/64 12 15 2700 2300 4000 19 128 70
81 417 501 27 2.3 P831_0050K302_0074 MB33 EZ702U 1426 1430 3230 36.96 2365/64 16 15 2700 2300 4000 46 128 80
81 417 501 27 2.3 P831_0050K302_0074 MB33 EZ702U 1426 1430 3230 36.96 2365/64 24 15 2700 2300 4000 46 128 80
81 417 501 27 2.3 P831_0050K302_0074 MB33 EZ702U 1426 1430 3230 36.96 2365/64 32 15 2700 2300 4000 46 128 80
81 469 556 30 2.1 P831_0050K302_0074 MB23 EZ505U 1304 1300 2191 36.96 2365/64 8.0 15 2700 2300 4000 23 128 73
81 469 556 30 2.1 P831_0050K302_0074 MB23 EZ505U 1304 1300 2191 36.96 2365/64 12 15 2700 2300 4000 23 128 73
83 147 160 16 4.7 P831_0070K202_0052 MB23 EZ501U 546 550 2148 36.24 14749/407 8.0 8.0 3000 2600 4000 12 128 61
83 147 160 16 4.7 P831_0070K202_0052 MB23 EZ501U 546 550 2148 36.24 14749/407 12 8.0 3000 2600 4000 12 128 61
83 147 160 16 4.7 P831_0070K202_0052 MB23 EZ501U 546 550 2148 36.24 14749/407 16 8.0 3000 2600 4000 12 128 61
83 160 177 17 4.3 P831_0070K202_0052 MB23 EZ402U 546 550 2148 36.24 14749/407 8.0 8.0 3000 2600 4000 11 128 61
83 160 177 17 4.3 P831_0070K202_0052 MB23 EZ402U 546 550 2148 36.24 14749/407 12 8.0 3000 2600 4000 11 128 61
83 160 177 17 4.3 P831_0070K202_0052 MB23 EZ402U 546 550 2148 36.24 14749/407 16 8.0 3000 2600 4000 11 128 61
83 235 293 25 2.9 P831_0070K202_0052 MB23 EZ404U 989 990 2148 36.24 14749/407 8.0 8.0 3000 2600 4000 12 128 63
83 235 293 25 2.9 P831_0070K202_0052 MB23 EZ404U 989 990 2148 36.24 14749/407 12 8.0 3000 2600 4000 12 128 63
83 235 293 25 2.9 P831_0070K202_0052 MB23 EZ404U 989 990 2148 36.24 14749/407 16 8.0 3000 2600 4000 12 128 63
83 252 273 27 2.7 P831_0070K202_0052 MB23 EZ502U 1057 1060 2148 36.24 14749/407 8.0 8.0 3000 2600 4000 14 128 63
83 252 273 27 2.7 P831_0070K202_0052 MB23 EZ502U 1057 1060 2148 36.24 14749/407 12 8.0 3000 2600 4000 14 128 63
83 252 273 27 2.7 P831_0070K202_0052 MB23 EZ502U 1057 1060 2148 36.24 14749/407 16 8.0 3000 2600 4000 14 128 63
83 252 283 27 2.7 P831_0070K202_0052 MB33 EZ701U 682 680 2887 36.24 14749/407 16 15 3000 2600 4000 39 128 72
83 252 283 27 2.7 P831_0070K202_0052 MB33 EZ701U 682 680 2887 36.24 14749/407 24 15 3000 2600 4000 39 128 72
83 331 378 35 2.1 P831_0070K202_0052 MB23 EZ503U 1279 1280 2148 36.24 14749/407 8.0 15 3000 2600 4000 18 128 65
83 331 378 35 2.1 P831_0070K202_0052 MB23 EZ503U 1279 1280 2148 36.24 14749/407 12 15 3000 2600 4000 18 128 65
83 409 491 44 1.7 P831_0070K202_0052 MB33 EZ702U 1291 1290 2887 36.24 14749/407 16 15 3000 2600 4000 45 128 75
83 409 491 44 1.7 P831_0070K202_0052 MB33 EZ702U 1291 1290 2887 36.24 14749/407 24 15 3000 2600 4000 45 128 75
83 460 546 49 1.5 P831_0070K202_0052 MB23 EZ505U 1279 1280 2148 36.24 14749/407 8.0 15 3000 2600 4000 23 128 68
83 460 546 49 1.5 P831_0070K202_0052 MB23 EZ505U 1279 1280 2148 36.24 14749/407 12 15 3000 2600 4000 23 128 68
98 135 149 17 4.8 P831_0070K202_0044 MB23 EZ402U 460 460 1811 30.55 336/11 8.0 8.0 3000 2600 4000 11 128 61
98 135 149 17 4.8 P831_0070K202_0044 MB23 EZ402U 460 460 1811 30.55 336/11 12 8.0 3000 2600 4000 11 128 61
98 135 149 17 4.8 P831_0070K202_0044 MB23 EZ402U 460 460 1811 30.55 336/11 16 8.0 3000 2600 4000 11 128 61
98 198 247 25 3.3 P831_0070K202_0044 MB23 EZ404U 834 830 1811 30.55 336/11 8.0 8.0 3000 2600 4000 13 128 63
98 198 247 25 3.3 P831_0070K202_0044 MB23 EZ404U 834 830 1811 30.55 336/11 12 8.0 3000 2600 4000 13 128 63
98 198 247 25 3.3 P831_0070K202_0044 MB23 EZ404U 834 830 1811 30.55 336/11 16 8.0 3000 2600 4000 13 128 63
98 213 230 27 3.0 P831_0070K202_0044 MB23 EZ502U 891 890 1811 30.55 336/11 8.0 8.0 3000 2600 4000 15 128 63
98 213 230 27 3.0 P831_0070K202_0044 MB23 EZ502U 891 890 1811 30.55 336/11 12 8.0 3000 2600 4000 15 128 63
98 213 230 27 3.0 P831_0070K202_0044 MB23 EZ502U 891 890 1811 30.55 336/11 16 8.0 3000 2600 4000 15 128 63
98 213 239 27 3.0 P831_0070K202_0044 MB33 EZ701U 575 570 2887 30.55 336/11 16 15 3000 2600 4000 40 128 72
98 213 239 27 3.0 P831_0070K202_0044 MB33 EZ701U 575 570 2887 30.55 336/11 24 15 3000 2600 4000 40 128 72
98 213 239 27 3.0 P831_0070K202_0044 MB33 EZ701U 575 570 2887 30.55 336/11 32 15 3000 2600 4000 40 128 72
98 279 319 36 2.3 P831_0070K202_0044 MB23 EZ503U 1078 1080 1811 30.55 336/11 8.0 15 3000 2600 4000 18 128 65
7 PKright-angle planetary geared motors 7.2 Selection tables
193
