Stober PK - Page 194

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P831K (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
98 279 319 36 2.3 P831_0070K202_0044 MB23 EZ503U 1078 1080 1811 30.55 336/11 12 15 3000 2600 4000 18 128 65
98 345 414 44 1.9 P831_0070K202_0044 MB33 EZ702U 1178 1180 2887 30.55 336/11 16 15 3000 2600 4000 45 128 75
98 345 414 44 1.9 P831_0070K202_0044 MB33 EZ702U 1178 1180 2887 30.55 336/11 24 15 3000 2600 4000 45 128 75
98 345 414 44 1.9 P831_0070K202_0044 MB33 EZ702U 1178 1180 2887 30.55 336/11 32 15 3000 2600 4000 45 128 75
98 388 460 50 1.7 P831_0070K202_0044 MB23 EZ505U 1078 1080 1811 30.55 336/11 8.0 15 3000 2600 4000 23 128 68
98 388 460 50 1.7 P831_0070K202_0044 MB23 EZ505U 1078 1080 1811 30.55 336/11 12 15 3000 2600 4000 23 128 68
98 474 598 61 1.4 P831_0070K202_0044 MB33 EZ703U 1220 1220 2887 30.55 336/11 16 32 3000 2600 4000 57 128 77
98 612 868 79 1.1 P831_0070K202_0044 MB33 EZ705U 1220 1220 2887 30.55 336/11 16 32 3000 2600 4000 69 128 83
100 195 243 16 4.6 P831_0050K302_0060 MB23 EZ404U 819 820 1778 30.00 30/1 8.0 8.0 2700 2300 4000 14 128 68
100 195 243 16 4.6 P831_0050K302_0060 MB23 EZ404U 819 820 1778 30.00 30/1 12 8.0 2700 2300 4000 14 128 68
100 195 243 16 4.6 P831_0050K302_0060 MB23 EZ404U 819 820 1778 30.00 30/1 16 8.0 2700 2300 4000 14 128 68
100 209 226 17 4.3 P831_0050K302_0060 MB23 EZ502U 875 880 1778 30.00 30/1 8.0 8.0 2700 2300 4000 16 128 68
100 209 226 17 4.3 P831_0050K302_0060 MB23 EZ502U 875 880 1778 30.00 30/1 12 8.0 2700 2300 4000 16 128 68
100 209 226 17 4.3 P831_0050K302_0060 MB23 EZ502U 875 880 1778 30.00 30/1 16 8.0 2700 2300 4000 16 128 68
100 209 234 17 4.3 P831_0050K302_0060 MB33 EZ701U 565 560 3230 30.00 30/1 16 15 2700 2300 4000 41 128 77
100 209 234 17 4.3 P831_0050K302_0060 MB33 EZ701U 565 560 3230 30.00 30/1 24 15 2700 2300 4000 41 128 77
100 209 234 17 4.3 P831_0050K302_0060 MB33 EZ701U 565 560 3230 30.00 30/1 32 15 2700 2300 4000 41 128 77
100 209 234 17 4.3 P831_0050K302_0060 MB33 EZ701U 565 560 3230 30.00 30/1 45 15 2700 2300 4000 41 128 77
100 274 313 22 3.3 P831_0050K302_0060 MB23 EZ503U 1059 1060 1778 30.00 30/1 8.0 15 2700 2300 4000 20 128 70
100 274 313 22 3.3 P831_0050K302_0060 MB23 EZ503U 1059 1060 1778 30.00 30/1 12 15 2700 2300 4000 20 128 70
100 339 406 27 2.7 P831_0050K302_0060 MB33 EZ702U 1157 1160 3230 30.00 30/1 16 15 2700 2300 4000 47 128 80
100 339 406 27 2.7 P831_0050K302_0060 MB33 EZ702U 1157 1160 3230 30.00 30/1 24 15 2700 2300 4000 47 128 80
100 339 406 27 2.7 P831_0050K302_0060 MB33 EZ702U 1157 1160 3230 30.00 30/1 32 15 2700 2300 4000 47 128 80
100 339 406 27 2.7 P831_0050K302_0060 MB33 EZ702U 1157 1160 3230 30.00 30/1 45 15 2700 2300 4000 47 128 80
100 381 452 30 2.4 P831_0050K302_0060 MB23 EZ505U 1059 1060 1778 30.00 30/1 8.0 15 2700 2300 4000 24 128 73
100 381 452 30 2.4 P831_0050K302_0060 MB23 EZ505U 1059 1060 1778 30.00 30/1 12 15 2700 2300 4000 24 128 73
100 466 587 37 1.9 P831_0050K302_0060 MB33 EZ703U 1697 1700 3230 30.00 30/1 16 32 2700 2300 4000 58 128 82
100 466 587 37 1.9 P831_0050K302_0060 MB33 EZ703U 1697 1700 3230 30.00 30/1 24 32 2700 2300 4000 58 128 82
100 601 852 48 1.5 P831_0050K302_0060 MB33 EZ705U 1697 1700 3230 30.00 30/1 16 32 2700 2300 4000 71 128 88
100 601 852 48 1.5 P831_0050K302_0060 MB33 EZ705U 1697 1700 3230 30.00 30/1 24 32 2700 2300 4000 71 128 88
107 182 227 26 3.4 P831_0070K202_0040 MB23 EZ404U 764 760 1660 28.00 28/1 8.0 8.0 3000 2600 4000 13 128 63
107 182 227 26 3.4 P831_0070K202_0040 MB23 EZ404U 764 760 1660 28.00 28/1 12 8.0 3000 2600 4000 13 128 63
107 182 227 26 3.4 P831_0070K202_0040 MB23 EZ404U 764 760 1660 28.00 28/1 16 8.0 3000 2600 4000 13 128 63
107 195 211 27 3.2 P831_0070K202_0040 MB23 EZ502U 817 820 1660 28.00 28/1 8.0 8.0 3000 2600 4000 15 128 63
107 195 211 27 3.2 P831_0070K202_0040 MB23 EZ502U 817 820 1660 28.00 28/1 12 8.0 3000 2600 4000 15 128 63
107 195 211 27 3.2 P831_0070K202_0040 MB23 EZ502U 817 820 1660 28.00 28/1 16 8.0 3000 2600 4000 15 128 63
107 195 219 27 3.2 P831_0070K202_0040 MB33 EZ701U 527 530 2887 28.00 28/1 16 15 3000 2600 4000 40 128 72
107 195 219 27 3.2 P831_0070K202_0040 MB33 EZ701U 527 530 2887 28.00 28/1 24 15 3000 2600 4000 40 128 72
107 195 219 27 3.2 P831_0070K202_0040 MB33 EZ701U 527 530 2887 28.00 28/1 32 15 3000 2600 4000 40 128 72
107 195 219 27 3.2 P831_0070K202_0040 MB33 EZ701U 527 530 2887 28.00 28/1 45 15 3000 2600 4000 40 128 72
107 256 292 36 2.5 P831_0070K202_0040 MB23 EZ503U 988 990 1660 28.00 28/1 8.0 15 3000 2600 4000 19 128 65
107 256 292 36 2.5 P831_0070K202_0040 MB23 EZ503U 988 990 1660 28.00 28/1 12 15 3000 2600 4000 19 128 65
107 316 379 45 2.0 P831_0070K202_0040 MB33 EZ702U 1080 1080 2887 28.00 28/1 16 15 3000 2600 4000 46 128 75
107 316 379 45 2.0 P831_0070K202_0040 MB33 EZ702U 1080 1080 2887 28.00 28/1 24 15 3000 2600 4000 46 128 75
107 316 379 45 2.0 P831_0070K202_0040 MB33 EZ702U 1080 1080 2887 28.00 28/1 32 15 3000 2600 4000 46 128 75
107 316 379 45 2.0 P831_0070K202_0040 MB33 EZ702U 1080 1080 2887 28.00 28/1 45 15 3000 2600 4000 46 128 75
107 356 422 50 1.8 P831_0070K202_0040 MB23 EZ505U 988 990 1660 28.00 28/1 8.0 15 3000 2600 4000 23 128 68
107 356 422 50 1.8 P831_0070K202_0040 MB23 EZ505U 988 990 1660 28.00 28/1 12 15 3000 2600 4000 23 128 68
107 435 548 61 1.4 P831_0070K202_0040 MB33 EZ703U 1185 1180 2887 28.00 28/1 16 32 3000 2600 4000 57 128 77
107 561 796 79 1.1 P831_0070K202_0040 MB33 EZ705U 1185 1180 2887 28.00 28/1 16 32 3000 2600 4000 70 128 83
112 174 217 16 5.0 P831_0050K302_0054 MB23 EZ404U 733 730 1593 26.88 215/8 8.0 8.0 2700 2300 4000 14 128 68
112 174 217 16 5.0 P831_0050K302_0054 MB23 EZ404U 733 730 1593 26.88 215/8 12 8.0 2700 2300 4000 14 128 68
112 174 217 16 5.0 P831_0050K302_0054 MB23 EZ404U 733 730 1593 26.88 215/8 16 8.0 2700 2300 4000 14 128 68
112 187 202 17 4.6 P831_0050K302_0054 MB23 EZ502U 784 780 1593 26.88 215/8 8.0 8.0 2700 2300 4000 16 128 68
112 187 202 17 4.6 P831_0050K302_0054 MB23 EZ502U 784 780 1593 26.88 215/8 12 8.0 2700 2300 4000 16 128 68
112 187 202 17 4.6 P831_0050K302_0054 MB23 EZ502U 784 780 1593 26.88 215/8 16 8.0 2700 2300 4000 16 128 68
112 187 210 17 4.6 P831_0050K302_0054 MB33 EZ701U 506 510 3108 26.88 215/8 16 15 2700 2300 4000 41 128 77
112 187 210 17 4.6 P831_0050K302_0054 MB33 EZ701U 506 510 3108 26.88 215/8 24 15 2700 2300 4000 41 128 77
112 187 210 17 4.6 P831_0050K302_0054 MB33 EZ701U 506 510 3108 26.88 215/8 32 15 2700 2300 4000 41 128 77
112 187 210 17 4.6 P831_0050K302_0054 MB33 EZ701U 506 510 3108 26.88 215/8 45 15 2700 2300 4000 41 128 77
112 245 281 22 3.5 P831_0050K302_0054 MB23 EZ503U 948 950 1593 26.88 215/8 8.0 15 2700 2300 4000 20 128 70
112 245 281 22 3.5 P831_0050K302_0054 MB23 EZ503U 948 950 1593 26.88 215/8 12 15 2700 2300 4000 20 128 70
112 303 364 27 2.9 P831_0050K302_0054 MB33 EZ702U 1037 1040 3108 26.88 215/8 16 15 2700 2300 4000 46 128 80
112 303 364 27 2.9 P831_0050K302_0054 MB33 EZ702U 1037 1040 3108 26.88 215/8 24 15 2700 2300 4000 46 128 80
7.2 Selection tables 7 PKright-angle planetary geared motors
194
