Stober PK - Page 195

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P831K (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
112 303 364 27 2.9 P831_0050K302_0054 MB33 EZ702U 1037 1040 3108 26.88 215/8 32 15 2700 2300 4000 46 128 80
112 303 364 27 2.9 P831_0050K302_0054 MB33 EZ702U 1037 1040 3108 26.88 215/8 45 15 2700 2300 4000 46 128 80
112 341 405 31 2.5 P831_0050K302_0054 MB23 EZ505U 948 950 1593 26.88 215/8 8.0 15 2700 2300 4000 24 128 73
112 341 405 31 2.5 P831_0050K302_0054 MB23 EZ505U 948 950 1593 26.88 215/8 12 15 2700 2300 4000 24 128 73
112 417 526 38 2.1 P831_0050K302_0054 MB33 EZ703U 1636 1640 3108 26.88 215/8 16 32 2700 2300 4000 58 128 82
112 417 526 38 2.1 P831_0050K302_0054 MB33 EZ703U 1636 1640 3108 26.88 215/8 24 32 2700 2300 4000 58 128 82
112 539 764 48 1.6 P831_0050K302_0054 MB33 EZ705U 1636 1640 3108 26.88 215/8 16 32 2700 2300 4000 71 128 88
112 539 764 48 1.6 P831_0050K302_0054 MB33 EZ705U 1636 1640 3108 26.88 215/8 24 32 2700 2300 4000 71 128 88
150 183 209 25 3.9 P831_0050K302_0040 MB23 EZ503U 706 710 1186 20.00 20/1 8.0 15 2700 2300 4000 22 128 70
150 183 209 25 3.9 P831_0050K302_0040 MB23 EZ503U 706 710 1186 20.00 20/1 12 15 2700 2300 4000 22 128 70
150 226 271 28 3.5 P831_0050K302_0040 MB33 EZ702U 772 770 3230 20.00 20/1 16 15 2700 2300 4000 48 128 80
150 226 271 28 3.5 P831_0050K302_0040 MB33 EZ702U 772 770 3230 20.00 20/1 24 15 2700 2300 4000 48 128 80
150 226 271 28 3.5 P831_0050K302_0040 MB33 EZ702U 772 770 3230 20.00 20/1 32 15 2700 2300 4000 48 128 80
150 226 271 28 3.5 P831_0050K302_0040 MB33 EZ702U 772 770 3230 20.00 20/1 45 15 2700 2300 4000 48 128 80
150 254 301 35 2.8 P831_0050K302_0040 MB23 EZ505U 706 710 1186 20.00 20/1 8.0 15 2700 2300 4000 26 128 73
150 254 301 35 2.8 P831_0050K302_0040 MB23 EZ505U 706 710 1186 20.00 20/1 12 15 2700 2300 4000 26 128 73
150 310 391 38 2.5 P831_0050K302_0040 MB33 EZ703U 1223 1220 3230 20.00 20/1 16 32 2700 2300 4000 60 128 82
150 310 391 38 2.5 P831_0050K302_0040 MB33 EZ703U 1223 1220 3230 20.00 20/1 24 32 2700 2300 4000 60 128 82
150 310 391 38 2.5 P831_0050K302_0040 MB33 EZ703U 1223 1220 3230 20.00 20/1 32 32 2700 2300 4000 60 128 82
150 310 391 38 2.5 P831_0050K302_0040 MB33 EZ703U 1223 1220 3230 20.00 20/1 45 32 2700 2300 4000 60 128 82
150 401 568 50 2.0 P831_0050K302_0040 MB33 EZ705U 1482 1480 3230 20.00 20/1 16 32 2700 2300 4000 73 128 88
150 401 568 50 2.0 P831_0050K302_0040 MB33 EZ705U 1482 1480 3230 20.00 20/1 24 32 2700 2300 4000 73 128 88
150 401 568 50 2.0 P831_0050K302_0040 MB33 EZ705U 1482 1480 3230 20.00 20/1 32 32 2700 2300 4000 73 128 88
150 401 568 50 2.0 P831_0050K302_0040 MB33 EZ705U 1482 1480 3230 20.00 20/1 45 32 2700 2300 4000 73 128 88
188 146 167 25 3.9 P831_0040K302_0040 MB23 EZ503U 565 560 948 16.00 16/1 8.0 15 2700 2300 4000 22 109 70
188 146 167 25 3.9 P831_0040K302_0040 MB23 EZ503U 565 560 948 16.00 16/1 12 15 2700 2300 4000 22 109 70
188 181 217 28 3.5 P831_0040K302_0040 MB33 EZ702U 617 620 2845 16.00 16/1 16 15 2700 2300 4000 49 109 80
188 181 217 28 3.5 P831_0040K302_0040 MB33 EZ702U 617 620 2845 16.00 16/1 24 15 2700 2300 4000 49 109 80
188 181 217 28 3.5 P831_0040K302_0040 MB33 EZ702U 617 620 2845 16.00 16/1 32 15 2700 2300 4000 49 109 80
188 181 217 28 3.5 P831_0040K302_0040 MB33 EZ702U 617 620 2845 16.00 16/1 45 15 2700 2300 4000 49 109 80
188 203 241 35 2.8 P831_0040K302_0040 MB23 EZ505U 565 560 948 16.00 16/1 8.0 15 2700 2300 4000 27 109 73
188 203 241 35 2.8 P831_0040K302_0040 MB23 EZ505U 565 560 948 16.00 16/1 12 15 2700 2300 4000 27 109 73
188 248 313 38 2.5 P831_0040K302_0040 MB33 EZ703U 979 980 2845 16.00 16/1 16 32 2700 2300 4000 61 109 82
188 248 313 38 2.5 P831_0040K302_0040 MB33 EZ703U 979 980 2845 16.00 16/1 24 32 2700 2300 4000 61 109 82
188 248 313 38 2.5 P831_0040K302_0040 MB33 EZ703U 979 980 2845 16.00 16/1 32 32 2700 2300 4000 61 109 82
188 248 313 38 2.5 P831_0040K302_0040 MB33 EZ703U 979 980 2845 16.00 16/1 45 32 2700 2300 4000 61 109 82
188 321 455 50 2.0 P831_0040K302_0040 MB33 EZ705U 1186 1190 2845 16.00 16/1 16 32 2700 2300 4000 73 109 88
188 321 455 50 2.0 P831_0040K302_0040 MB33 EZ705U 1186 1190 2845 16.00 16/1 24 32 2700 2300 4000 73 109 88
188 321 455 50 2.0 P831_0040K302_0040 MB33 EZ705U 1186 1190 2845 16.00 16/1 32 32 2700 2300 4000 73 109 88
188 321 455 50 2.0 P831_0040K302_0040 MB33 EZ705U 1186 1190 2845 16.00 16/1 45 32 2700 2300 4000 73 109 88
250 110 125 25 3.9 P831_0030K302_0040 MB23 EZ503U 423 420 711 12.00 12/1 8.0 15 2700 2300 4000 24 83 70
250 110 125 25 3.9 P831_0030K302_0040 MB23 EZ503U 423 420 711 12.00 12/1 12 15 2700 2300 4000 24 83 70
250 135 163 28 3.5 P831_0030K302_0040 MB33 EZ702U 463 460 2134 12.00 12/1 16 15 2700 2300 4000 50 83 80
250 135 163 28 3.5 P831_0030K302_0040 MB33 EZ702U 463 460 2134 12.00 12/1 24 15 2700 2300 4000 50 83 80
250 135 163 28 3.5 P831_0030K302_0040 MB33 EZ702U 463 460 2134 12.00 12/1 32 15 2700 2300 4000 50 83 80
250 135 163 28 3.5 P831_0030K302_0040 MB33 EZ702U 463 460 2134 12.00 12/1 45 15 2700 2300 4000 50 83 80
250 152 181 35 2.8 P831_0030K302_0040 MB23 EZ505U 423 420 711 12.00 12/1 8.0 15 2700 2300 4000 28 83 73
250 152 181 35 2.8 P831_0030K302_0040 MB23 EZ505U 423 420 711 12.00 12/1 12 15 2700 2300 4000 28 83 73
250 186 235 38 2.5 P831_0030K302_0040 MB33 EZ703U 734 730 2134 12.00 12/1 16 32 2700 2300 4000 62 83 82
250 186 235 38 2.5 P831_0030K302_0040 MB33 EZ703U 734 730 2134 12.00 12/1 24 32 2700 2300 4000 62 83 82
250 186 235 38 2.5 P831_0030K302_0040 MB33 EZ703U 734 730 2134 12.00 12/1 32 32 2700 2300 4000 62 83 82
250 186 235 38 2.5 P831_0030K302_0040 MB33 EZ703U 734 730 2134 12.00 12/1 45 32 2700 2300 4000 62 83 82
250 240 341 50 2.0 P831_0030K302_0040 MB33 EZ705U 889 890 2134 12.00 12/1 16 32 2700 2300 4000 75 83 88
250 240 341 50 2.0 P831_0030K302_0040 MB33 EZ705U 889 890 2134 12.00 12/1 24 32 2700 2300 4000 75 83 88
250 240 341 50 2.0 P831_0030K302_0040 MB33 EZ705U 889 890 2134 12.00 12/1 32 32 2700 2300 4000 75 83 88
250 240 341 50 2.0 P831_0030K302_0040 MB33 EZ705U 889 890 2134 12.00 12/1 45 32 2700 2300 4000 75 83 88
P931K (n
1N
= 3000 rpm, M
2acc,max
= 3110 Nm)
15 787 860 9.3 2.7 P931_0070K402_0280 MB23 EZ501U 2927 – 6210 194.4 9331/48 8.0 8.0 3600 3300 4000 11 305 92
15 860 951 10 2.4 P931_0070K402_0280 MB23 EZ402U 2927 – 6210 194.4 9331/48 8.0 8.0 3600 3300 4000 9.7 305 91
15 1262 1573 15 1.7 P931_0070K402_0280 MB23 EZ404U 3105 – 6210 194.4 9331/48 8.0 8.0 3600 3300 4000 11 305 94
15 1354 1463 16 1.6 P931_0070K402_0280 MB23 EZ502U 3105 – 6210 194.4 9331/48 8.0 8.0 3600 3300 4000 13 305 93
17 716 783 9.1 2.9 P931_0070K402_0250 MB23 EZ501U 2664 – 6210 177.0 29197/165 8.0 8.0 3600 3300 4000 11 305 92
17 783 866 9.9 2.7 P931_0070K402_0250 MB23 EZ402U 2664 – 6210 177.0 29197/165 8.0 8.0 3600 3300 4000 9.5 305 91
17 1149 1432 15 1.8 P931_0070K402_0250 MB23 EZ404U 3105 – 6210 177.0 29197/165 8.0 8.0 3600 3300 4000 11 305 94
7 PKright-angle planetary geared motors 7.2 Selection tables
