Stober PK - Page 196

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P931K (n
1N
= 3000 rpm, M
2acc,max
= 3110 Nm)
17 1232 1332 16 1.7 P931_0070K402_0250 MB23 EZ502U 3105 – 6210 177.0 29197/165 8.0 8.0 3600 3300 4000 13 305 93
18 660 721 8.9 3.2 P931_0070K402_0230 MB23 EZ501U 2455 – 6210 163.0 3913/24 8.0 8.0 3600 3300 4000 11 305 92
18 660 721 8.9 3.2 P931_0070K402_0230 MB23 EZ501U 2455 – 6210 163.0 3913/24 12 8.0 3600 3300 4000 11 305 92
18 721 798 9.7 2.9 P931_0070K402_0230 MB23 EZ402U 2455 – 6210 163.0 3913/24 8.0 8.0 3600 3300 4000 9.9 305 91
18 721 798 9.7 2.9 P931_0070K402_0230 MB23 EZ402U 2455 – 6210 163.0 3913/24 12 8.0 3600 3300 4000 9.9 305 91
18 1059 1319 14 2.0 P931_0070K402_0230 MB23 EZ404U 3105 – 6210 163.0 3913/24 8.0 8.0 3600 3300 4000 11 305 94
18 1059 1319 14 2.0 P931_0070K402_0230 MB23 EZ404U 3105 – 6210 163.0 3913/24 12 8.0 3600 3300 4000 11 305 94
18 1135 1227 15 1.9 P931_0070K402_0230 MB23 EZ502U 3105 – 6210 163.0 3913/24 8.0 8.0 3600 3300 4000 13 305 93
18 1135 1227 15 1.9 P931_0070K402_0230 MB23 EZ502U 3105 – 6210 163.0 3913/24 12 8.0 3600 3300 4000 13 305 93
21 572 625 8.6 3.7 P931_0070K402_0200 MB23 EZ501U 2128 – 6210 141.4 9331/66 8.0 8.0 3600 3300 4000 11 305 92
21 572 625 8.6 3.7 P931_0070K402_0200 MB23 EZ501U 2128 – 6210 141.4 9331/66 12 8.0 3600 3300 4000 11 305 92
21 572 625 8.6 3.7 P931_0070K402_0200 MB23 EZ501U 2128 – 6210 141.4 9331/66 16 8.0 3600 3300 4000 11 305 92
21 625 692 9.4 3.4 P931_0070K402_0200 MB23 EZ402U 2128 – 6210 141.4 9331/66 8.0 8.0 3600 3300 4000 9.8 305 91
21 625 692 9.4 3.4 P931_0070K402_0200 MB23 EZ402U 2128 – 6210 141.4 9331/66 12 8.0 3600 3300 4000 9.8 305 91
21 625 692 9.4 3.4 P931_0070K402_0200 MB23 EZ402U 2128 – 6210 141.4 9331/66 16 8.0 3600 3300 4000 9.8 305 91
21 918 1144 14 2.3 P931_0070K402_0200 MB23 EZ404U 3105 – 6210 141.4 9331/66 8.0 8.0 3600 3300 4000 11 305 94
21 918 1144 14 2.3 P931_0070K402_0200 MB23 EZ404U 3105 – 6210 141.4 9331/66 12 8.0 3600 3300 4000 11 305 94
21 918 1144 14 2.3 P931_0070K402_0200 MB23 EZ404U 3105 – 6210 141.4 9331/66 16 8.0 3600 3300 4000 11 305 94
21 984 1064 15 2.1 P931_0070K402_0200 MB23 EZ502U 3105 – 6210 141.4 9331/66 8.0 8.0 3600 3300 4000 13 305 93
21 984 1064 15 2.1 P931_0070K402_0200 MB23 EZ502U 3105 – 6210 141.4 9331/66 12 8.0 3600 3300 4000 13 305 93
21 984 1064 15 2.1 P931_0070K402_0200 MB23 EZ502U 3105 – 6210 141.4 9331/66 16 8.0 3600 3300 4000 13 305 93
21 1290 1477 19 1.6 P931_0070K402_0200 MB23 EZ503U 3105 – 6210 141.4 9331/66 8.0 15 3600 3300 4000 17 305 95
21 1796 2128 27 1.2 P931_0070K402_0200 MB23 EZ505U 3105 – 6210 141.4 9331/66 8.0 15 3600 3300 4000 21 305 98
25 493 539 8.3 4.3 P931_0070K402_0175 MB23 EZ501U 1834 – 6210 121.8 731/6 8.0 8.0 3400 3000 4000 12 305 92
25 493 539 8.3 4.3 P931_0070K402_0175 MB23 EZ501U 1834 – 6210 121.8 731/6 12 8.0 3400 3000 4000 12 305 92
25 493 539 8.3 4.3 P931_0070K402_0175 MB23 EZ501U 1834 – 6210 121.8 731/6 16 8.0 3400 3000 4000 12 305 92
25 539 596 9.0 3.9 P931_0070K402_0175 MB23 EZ402U 1834 – 6210 121.8 731/6 8.0 8.0 3400 3000 4000 10 305 91
25 539 596 9.0 3.9 P931_0070K402_0175 MB23 EZ402U 1834 – 6210 121.8 731/6 12 8.0 3400 3000 4000 10 305 91
25 539 596 9.0 3.9 P931_0070K402_0175 MB23 EZ402U 1834 – 6210 121.8 731/6 16 8.0 3400 3000 4000 10 305 91
25 791 986 13 2.7 P931_0070K402_0175 MB23 EZ404U 3105 – 6210 121.8 731/6 8.0 8.0 3400 3000 4000 12 305 94
25 791 986 13 2.7 P931_0070K402_0175 MB23 EZ404U 3105 – 6210 121.8 731/6 12 8.0 3400 3000 4000 12 305 94
25 791 986 13 2.7 P931_0070K402_0175 MB23 EZ404U 3105 – 6210 121.8 731/6 16 8.0 3400 3000 4000 12 305 94
25 848 917 14 2.5 P931_0070K402_0175 MB23 EZ502U 3105 – 6210 121.8 731/6 8.0 8.0 3400 3000 4000 14 305 93
25 848 917 14 2.5 P931_0070K402_0175 MB23 EZ502U 3105 – 6210 121.8 731/6 12 8.0 3400 3000 4000 14 305 93
25 848 917 14 2.5 P931_0070K402_0175 MB23 EZ502U 3105 – 6210 121.8 731/6 16 8.0 3400 3000 4000 14 305 93
25 1112 1272 19 1.9 P931_0070K402_0175 MB23 EZ503U 3105 – 6210 121.8 731/6 8.0 15 3400 3000 4000 18 305 95
25 1112 1272 19 1.9 P931_0070K402_0175 MB23 EZ503U 3105 – 6210 121.8 731/6 12 15 3400 3000 4000 18 305 95
25 1548 1834 26 1.4 P931_0070K402_0175 MB23 EZ505U 3105 – 6210 121.8 731/6 8.0 15 3400 3000 4000 22 305 98
25 1548 1834 26 1.4 P931_0070K402_0175 MB23 EZ505U 3105 – 6210 121.8 731/6 12 15 3400 3000 4000 22 305 98
25 480 524 8.2 4.4 P931_0070K402_0170 MB23 EZ501U 1785 – 6210 118.6 3913/33 8.0 8.0 3600 3300 4000 11 305 92
25 480 524 8.2 4.4 P931_0070K402_0170 MB23 EZ501U 1785 – 6210 118.6 3913/33 12 8.0 3600 3300 4000 11 305 92
25 480 524 8.2 4.4 P931_0070K402_0170 MB23 EZ501U 1785 – 6210 118.6 3913/33 16 8.0 3600 3300 4000 11 305 92
25 524 580 9.0 4.0 P931_0070K402_0170 MB23 EZ402U 1785 – 6210 118.6 3913/33 8.0 8.0 3600 3300 4000 10 305 91
25 524 580 9.0 4.0 P931_0070K402_0170 MB23 EZ402U 1785 – 6210 118.6 3913/33 12 8.0 3600 3300 4000 10 305 91
25 524 580 9.0 4.0 P931_0070K402_0170 MB23 EZ402U 1785 – 6210 118.6 3913/33 16 8.0 3600 3300 4000 10 305 91
25 770 959 13 2.7 P931_0070K402_0170 MB23 EZ404U 3105 – 6210 118.6 3913/33 8.0 8.0 3600 3300 4000 11 305 94
25 770 959 13 2.7 P931_0070K402_0170 MB23 EZ404U 3105 – 6210 118.6 3913/33 12 8.0 3600 3300 4000 11 305 94
25 770 959 13 2.7 P931_0070K402_0170 MB23 EZ404U 3105 – 6210 118.6 3913/33 16 8.0 3600 3300 4000 11 305 94
25 826 893 14 2.5 P931_0070K402_0170 MB23 EZ502U 3105 – 6210 118.6 3913/33 8.0 8.0 3600 3300 4000 14 305 93
25 826 893 14 2.5 P931_0070K402_0170 MB23 EZ502U 3105 – 6210 118.6 3913/33 12 8.0 3600 3300 4000 14 305 93
25 826 893 14 2.5 P931_0070K402_0170 MB23 EZ502U 3105 – 6210 118.6 3913/33 16 8.0 3600 3300 4000 14 305 93
25 1082 1238 19 1.9 P931_0070K402_0170 MB23 EZ503U 3105 – 6210 118.6 3913/33 8.0 15 3600 3300 4000 17 305 95
25 1082 1238 19 1.9 P931_0070K402_0170 MB23 EZ503U 3105 – 6210 118.6 3913/33 12 15 3600 3300 4000 17 305 95
25 1506 1785 26 1.4 P931_0070K402_0170 MB23 EZ505U 3105 – 6210 118.6 3913/33 8.0 15 3600 3300 4000 22 305 98
25 1506 1785 26 1.4 P931_0070K402_0170 MB23 EZ505U 3105 – 6210 118.6 3913/33 12 15 3600 3300 4000 22 305 98
31 430 476 8.5 4.9 P931_0070K402_0140 MB23 EZ402U 1463 – 5761 97.20 9331/96 8.0 8.0 3400 3000 4000 11 305 91
31 430 476 8.5 4.9 P931_0070K402_0140 MB23 EZ402U 1463 – 5761 97.20 9331/96 12 8.0 3400 3000 4000 11 305 91
31 430 476 8.5 4.9 P931_0070K402_0140 MB23 EZ402U 1463 – 5761 97.20 9331/96 16 8.0 3400 3000 4000 11 305 91
31 631 786 13 3.3 P931_0070K402_0140 MB23 EZ404U 2652 – 5761 97.20 9331/96 8.0 8.0 3400 3000 4000 12 305 94
31 631 786 13 3.3 P931_0070K402_0140 MB23 EZ404U 2652 – 5761 97.20 9331/96 12 8.0 3400 3000 4000 12 305 94
31 631 786 13 3.3 P931_0070K402_0140 MB23 EZ404U 2652 – 5761 97.20 9331/96 16 8.0 3400 3000 4000 12 305 94
31 677 732 13 3.1 P931_0070K402_0140 MB23 EZ502U 2835 – 5761 97.20 9331/96 8.0 8.0 3400 3000 4000 15 305 93
31 677 732 13 3.1 P931_0070K402_0140 MB23 EZ502U 2835 – 5761 97.20 9331/96 12 8.0 3400 3000 4000 15 305 93
31 677 732 13 3.1 P931_0070K402_0140 MB23 EZ502U 2835 – 5761 97.20 9331/96 16 8.0 3400 3000 4000 15 305 93
7.2 Selection tables 7 PKright-angle planetary geared motors
