Stober PK - Page 233

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH831K (n
1N
= 3000 rpm, M
2acc,max
= 1850 Nm)
112 185 208 17 4.6 PH831_0050K302_0054 MB33 EZ701U 501 500 3140 26.88 215/8 32 15 2700 2300 4000 41 245 79
112 185 208 17 4.6 PH831_0050K302_0054 MB33 EZ701U 501 500 3140 26.88 215/8 45 15 2700 2300 4000 41 245 79
112 243 278 22 3.5 PH831_0050K302_0054 MB23 EZ503U 938 940 1577 26.88 215/8 8.0 15 2700 2300 4000 20 245 71
112 243 278 22 3.5 PH831_0050K302_0054 MB23 EZ503U 938 940 1577 26.88 215/8 12 15 2700 2300 4000 20 245 71
112 300 360 27 2.9 PH831_0050K302_0054 MB33 EZ702U 1026 1030 3140 26.88 215/8 16 15 2700 2300 4000 47 245 81
112 300 360 27 2.9 PH831_0050K302_0054 MB33 EZ702U 1026 1030 3140 26.88 215/8 24 15 2700 2300 4000 47 245 81
112 300 360 27 2.9 PH831_0050K302_0054 MB33 EZ702U 1026 1030 3140 26.88 215/8 32 15 2700 2300 4000 47 245 81
112 300 360 27 2.9 PH831_0050K302_0054 MB33 EZ702U 1026 1030 3140 26.88 215/8 45 15 2700 2300 4000 47 245 81
112 338 400 31 2.5 PH831_0050K302_0054 MB23 EZ505U 938 940 1577 26.88 215/8 8.0 15 2700 2300 4000 24 245 74
112 338 400 31 2.5 PH831_0050K302_0054 MB23 EZ505U 938 940 1577 26.88 215/8 12 15 2700 2300 4000 24 245 74
112 413 521 38 2.1 PH831_0050K302_0054 MB33 EZ703U 1619 1620 3140 26.88 215/8 16 32 2700 2300 4000 58 245 84
112 413 521 38 2.1 PH831_0050K302_0054 MB33 EZ703U 1619 1620 3140 26.88 215/8 24 32 2700 2300 4000 58 245 84
112 533 756 48 1.6 PH831_0050K302_0054 MB33 EZ705U 1619 1620 3140 26.88 215/8 16 32 2700 2300 4000 71 245 90
112 533 756 48 1.6 PH831_0050K302_0054 MB33 EZ705U 1619 1620 3140 26.88 215/8 24 32 2700 2300 4000 71 245 90
150 181 207 25 3.9 PH831_0050K302_0040 MB23 EZ503U 698 700 1173 20.00 20/1 8.0 15 2700 2300 4000 22 245 71
150 181 207 25 3.9 PH831_0050K302_0040 MB23 EZ503U 698 700 1173 20.00 20/1 12 15 2700 2300 4000 22 245 71
150 223 268 28 3.5 PH831_0050K302_0040 MB33 EZ702U 764 760 3520 20.00 20/1 16 15 2700 2300 4000 49 245 81
150 223 268 28 3.5 PH831_0050K302_0040 MB33 EZ702U 764 760 3520 20.00 20/1 24 15 2700 2300 4000 49 245 81
150 223 268 28 3.5 PH831_0050K302_0040 MB33 EZ702U 764 760 3520 20.00 20/1 32 15 2700 2300 4000 49 245 81
150 223 268 28 3.5 PH831_0050K302_0040 MB33 EZ702U 764 760 3520 20.00 20/1 45 15 2700 2300 4000 49 245 81
150 251 298 35 2.8 PH831_0050K302_0040 MB23 EZ505U 698 700 1173 20.00 20/1 8.0 15 2700 2300 4000 27 245 74
150 251 298 35 2.8 PH831_0050K302_0040 MB23 EZ505U 698 700 1173 20.00 20/1 12 15 2700 2300 4000 27 245 74
150 307 387 38 2.5 PH831_0050K302_0040 MB33 EZ703U 1211 1210 3520 20.00 20/1 16 32 2700 2300 4000 61 245 84
150 307 387 38 2.5 PH831_0050K302_0040 MB33 EZ703U 1211 1210 3520 20.00 20/1 24 32 2700 2300 4000 61 245 84
150 307 387 38 2.5 PH831_0050K302_0040 MB33 EZ703U 1211 1210 3520 20.00 20/1 32 32 2700 2300 4000 61 245 84
150 307 387 38 2.5 PH831_0050K302_0040 MB33 EZ703U 1211 1210 3520 20.00 20/1 45 32 2700 2300 4000 61 245 84
150 397 562 50 2.0 PH831_0050K302_0040 MB33 EZ705U 1467 1470 3520 20.00 20/1 16 32 2700 2300 4000 73 245 90
150 397 562 50 2.0 PH831_0050K302_0040 MB33 EZ705U 1467 1470 3520 20.00 20/1 24 32 2700 2300 4000 73 245 90
150 397 562 50 2.0 PH831_0050K302_0040 MB33 EZ705U 1467 1470 3520 20.00 20/1 32 32 2700 2300 4000 73 245 90
150 397 562 50 2.0 PH831_0050K302_0040 MB33 EZ705U 1467 1470 3520 20.00 20/1 45 32 2700 2300 4000 73 245 90
188 145 165 25 3.9 PH831_0040K302_0040 MB23 EZ503U 559 560 939 16.00 16/1 8.0 15 2700 2300 4000 23 185 71
188 145 165 25 3.9 PH831_0040K302_0040 MB23 EZ503U 559 560 939 16.00 16/1 12 15 2700 2300 4000 23 185 71
188 179 215 28 3.5 PH831_0040K302_0040 MB33 EZ702U 611 610 2816 16.00 16/1 16 15 2700 2300 4000 49 185 81
188 179 215 28 3.5 PH831_0040K302_0040 MB33 EZ702U 611 610 2816 16.00 16/1 24 15 2700 2300 4000 49 185 81
188 179 215 28 3.5 PH831_0040K302_0040 MB33 EZ702U 611 610 2816 16.00 16/1 32 15 2700 2300 4000 49 185 81
188 179 215 28 3.5 PH831_0040K302_0040 MB33 EZ702U 611 610 2816 16.00 16/1 45 15 2700 2300 4000 49 185 81
188 201 238 35 2.8 PH831_0040K302_0040 MB23 EZ505U 559 560 939 16.00 16/1 8.0 15 2700 2300 4000 27 185 74
188 201 238 35 2.8 PH831_0040K302_0040 MB23 EZ505U 559 560 939 16.00 16/1 12 15 2700 2300 4000 27 185 74
188 246 310 38 2.5 PH831_0040K302_0040 MB33 EZ703U 968 970 2816 16.00 16/1 16 32 2700 2300 4000 61 185 84
188 246 310 38 2.5 PH831_0040K302_0040 MB33 EZ703U 968 970 2816 16.00 16/1 24 32 2700 2300 4000 61 185 84
188 246 310 38 2.5 PH831_0040K302_0040 MB33 EZ703U 968 970 2816 16.00 16/1 32 32 2700 2300 4000 61 185 84
188 246 310 38 2.5 PH831_0040K302_0040 MB33 EZ703U 968 970 2816 16.00 16/1 45 32 2700 2300 4000 61 185 84
188 317 450 50 2.0 PH831_0040K302_0040 MB33 EZ705U 1174 1170 2816 16.00 16/1 16 32 2700 2300 4000 74 185 90
188 317 450 50 2.0 PH831_0040K302_0040 MB33 EZ705U 1174 1170 2816 16.00 16/1 24 32 2700 2300 4000 74 185 90
188 317 450 50 2.0 PH831_0040K302_0040 MB33 EZ705U 1174 1170 2816 16.00 16/1 32 32 2700 2300 4000 74 185 90
188 317 450 50 2.0 PH831_0040K302_0040 MB33 EZ705U 1174 1170 2816 16.00 16/1 45 32 2700 2300 4000 74 185 90
PH931K (n
1N
= 3000 rpm, M
2acc,max
= 4500 Nm)
10 1140 1246 10 2.6 PH931_0060K513_0480 MB23 EZ501U 4243 – 9000 289.0 8091/28 8.0 8.0 3400 3000 4000 11 730 103
10 1246 1379 11 2.4 PH931_0060K513_0480 MB23 EZ402U 4243 – 9000 289.0 8091/28 8.0 8.0 3400 3000 4000 10 730 103
10 1830 2281 16 1.6 PH931_0060K513_0480 MB23 EZ404U 4500 – 9000 289.0 8091/28 8.0 8.0 3400 3000 4000 11 730 105
10 1962 2122 17 1.5 PH931_0060K513_0480 MB23 EZ502U 4500 – 9000 289.0 8091/28 8.0 8.0 3400 3000 4000 14 730 104
13 912 997 9.4 3.3 PH931_0060K513_0390 MB23 EZ501U 3395 – 9000 231.2 8091/35 8.0 8.0 3400 3000 4000 12 730 103
13 912 997 9.4 3.3 PH931_0060K513_0390 MB23 EZ501U 3395 – 9000 231.2 8091/35 12 8.0 3400 3000 4000 12 730 103
13 997 1103 10 3.0 PH931_0060K513_0390 MB23 EZ402U 3395 – 9000 231.2 8091/35 8.0 8.0 3400 3000 4000 10 730 103
13 997 1103 10 3.0 PH931_0060K513_0390 MB23 EZ402U 3395 – 9000 231.2 8091/35 12 8.0 3400 3000 4000 10 730 103
13 1464 1825 15 2.0 PH931_0060K513_0390 MB23 EZ404U 4500 – 9000 231.2 8091/35 8.0 8.0 3400 3000 4000 12 730 105
13 1464 1825 15 2.0 PH931_0060K513_0390 MB23 EZ404U 4500 – 9000 231.2 8091/35 12 8.0 3400 3000 4000 12 730 105
13 1570 1697 16 1.9 PH931_0060K513_0390 MB23 EZ502U 4500 – 9000 231.2 8091/35 8.0 8.0 3400 3000 4000 14 730 104
13 1570 1697 16 1.9 PH931_0060K513_0390 MB23 EZ502U 4500 – 9000 231.2 8091/35 12 8.0 3400 3000 4000 14 730 104
15 765 836 9.0 3.9 PH931_0060K513_0320 MB23 EZ501U 2846 – 9000 193.8 62031/320 8.0 8.0 3400 3000 4000 12 730 103
15 765 836 9.0 3.9 PH931_0060K513_0320 MB23 EZ501U 2846 – 9000 193.8 62031/320 12 8.0 3400 3000 4000 12 730 103
15 765 836 9.0 3.9 PH931_0060K513_0320 MB23 EZ501U 2846 – 9000 193.8 62031/320 16 8.0 3400 3000 4000 12 730 103
15 836 925 9.8 3.6 PH931_0060K513_0320 MB23 EZ402U 2846 – 9000 193.8 62031/320 8.0 8.0 3400 3000 4000 11 730 103
15 836 925 9.8 3.6 PH931_0060K513_0320 MB23 EZ402U 2846 – 9000 193.8 62031/320 12 8.0 3400 3000 4000 11 730 103
8 PHKright-angle planetary geared motors 8.2 Selection tables
