n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH931K (n
1N
= 3000 rpm, M
2acc,max
= 4500 Nm)
15 836 925 9.8 3.6 PH931_0060K513_0320 MB23 EZ402U 2846 – 9000 193.8 62031/320 16 8.0 3400 3000 4000 11 730 103
15 1228 1530 14 2.4 PH931_0060K513_0320 MB23 EZ404U 4500 – 9000 193.8 62031/320 8.0 8.0 3400 3000 4000 12 730 105
15 1228 1530 14 2.4 PH931_0060K513_0320 MB23 EZ404U 4500 – 9000 193.8 62031/320 12 8.0 3400 3000 4000 12 730 105
15 1228 1530 14 2.4 PH931_0060K513_0320 MB23 EZ404U 4500 – 9000 193.8 62031/320 16 8.0 3400 3000 4000 12 730 105
15 1317 1423 15 2.3 PH931_0060K513_0320 MB23 EZ502U 4500 – 9000 193.8 62031/320 8.0 8.0 3400 3000 4000 15 730 104
15 1317 1423 15 2.3 PH931_0060K513_0320 MB23 EZ502U 4500 – 9000 193.8 62031/320 12 8.0 3400 3000 4000 15 730 104
15 1317 1423 15 2.3 PH931_0060K513_0320 MB23 EZ502U 4500 – 9000 193.8 62031/320 16 8.0 3400 3000 4000 15 730 104
15 1726 1975 20 1.7 PH931_0060K513_0320 MB23 EZ503U 4500 – 9000 193.8 62031/320 8.0 15 3400 3000 4000 18 730 106
15 2402 2846 28 1.2 PH931_0060K513_0320 MB23 EZ505U 4500 – 9000 193.8 62031/320 8.0 15 3400 3000 4000 23 730 109
21 630 697 9.0 4.8 PH931_0060K513_0240 MB23 EZ402U 2145 – 8447 146.1 11687/80 8.0 8.0 2800 2500 4000 12 730 103
21 630 697 9.0 4.8 PH931_0060K513_0240 MB23 EZ402U 2145 – 8447 146.1 11687/80 12 8.0 2800 2500 4000 12 730 103
21 630 697 9.0 4.8 PH931_0060K513_0240 MB23 EZ402U 2145 – 8447 146.1 11687/80 16 8.0 2800 2500 4000 12 730 103
21 925 1153 13 3.2 PH931_0060K513_0240 MB23 EZ404U 3888 – 8447 146.1 11687/80 8.0 8.0 2800 2500 4000 13 730 105
21 925 1153 13 3.2 PH931_0060K513_0240 MB23 EZ404U 3888 – 8447 146.1 11687/80 12 8.0 2800 2500 4000 13 730 105
21 925 1153 13 3.2 PH931_0060K513_0240 MB23 EZ404U 3888 – 8447 146.1 11687/80 16 8.0 2800 2500 4000 13 730 105
21 992 1073 14 3.0 PH931_0060K513_0240 MB23 EZ502U 4156 – 8447 146.1 11687/80 8.0 8.0 2800 2500 4000 16 730 104
21 992 1073 14 3.0 PH931_0060K513_0240 MB23 EZ502U 4156 – 8447 146.1 11687/80 12 8.0 2800 2500 4000 16 730 104
21 992 1073 14 3.0 PH931_0060K513_0240 MB23 EZ502U 4156 – 8447 146.1 11687/80 16 8.0 2800 2500 4000 16 730 104
21 992 1113 14 3.0 PH931_0060K513_0240 MB33 EZ701U 2681 – 9000 146.1 11687/80 16 15 2800 2500 4000 41 730 114
21 1301 1488 19 2.3 PH931_0060K513_0240 MB23 EZ503U 4500 – 8447 146.1 11687/80 8.0 15 2800 2500 4000 19 730 106
21 1301 1488 19 2.3 PH931_0060K513_0240 MB23 EZ503U 4500 – 8447 146.1 11687/80 12 15 2800 2500 4000 19 730 106
21 1609 1931 23 1.9 PH931_0060K513_0240 MB33 EZ702U 4500 – 9000 146.1 11687/80 16 15 2800 2500 4000 46 730 116
21 1810 2145 26 1.7 PH931_0060K513_0240 MB23 EZ505U 4500 – 8447 146.1 11687/80 8.0 15 2800 2500 4000 24 730 109
21 1810 2145 26 1.7 PH931_0060K513_0240 MB23 EZ505U 4500 – 8447 146.1 11687/80 12 15 2800 2500 4000 24 730 109
26 735 916 12 4.1 PH931_0060K513_0195 MB23 EZ404U 3090 – 6714 116.1 27869/240 8.0 8.0 2800 2500 4000 14 730 105
26 735 916 12 4.1 PH931_0060K513_0195 MB23 EZ404U 3090 – 6714 116.1 27869/240 12 8.0 2800 2500 4000 14 730 105
26 735 916 12 4.1 PH931_0060K513_0195 MB23 EZ404U 3090 – 6714 116.1 27869/240 16 8.0 2800 2500 4000 14 730 105
26 789 853 13 3.8 PH931_0060K513_0195 MB23 EZ502U 3304 – 6714 116.1 27869/240 8.0 8.0 2800 2500 4000 17 730 104
26 789 853 13 3.8 PH931_0060K513_0195 MB23 EZ502U 3304 – 6714 116.1 27869/240 12 8.0 2800 2500 4000 17 730 104
26 789 853 13 3.8 PH931_0060K513_0195 MB23 EZ502U 3304 – 6714 116.1 27869/240 16 8.0 2800 2500 4000 17 730 104
26 789 885 13 3.8 PH931_0060K513_0195 MB33 EZ701U 2131 – 9000 116.1 27869/240 16 15 2800 2500 4000 42 730 114
26 789 885 13 3.8 PH931_0060K513_0195 MB33 EZ701U 2131 – 9000 116.1 27869/240 24 15 2800 2500 4000 42 730 114
26 1034 1183 17 2.9 PH931_0060K513_0195 MB23 EZ503U 3996 – 6714 116.1 27869/240 8.0 15 2800 2500 4000 20 730 106
26 1034 1183 17 2.9 PH931_0060K513_0195 MB23 EZ503U 3996 – 6714 116.1 27869/240 12 15 2800 2500 4000 20 730 106
26 1279 1535 21 2.3 PH931_0060K513_0195 MB33 EZ702U 4369 – 9000 116.1 27869/240 16 15 2800 2500 4000 47 730 116
26 1279 1535 21 2.3 PH931_0060K513_0195 MB33 EZ702U 4369 – 9000 116.1 27869/240 24 15 2800 2500 4000 47 730 116
26 1439 1705 24 2.1 PH931_0060K513_0195 MB23 EZ505U 3996 – 6714 116.1 27869/240 8.0 15 2800 2500 4000 25 730 109
26 1439 1705 24 2.1 PH931_0060K513_0195 MB23 EZ505U 3996 – 6714 116.1 27869/240 12 15 2800 2500 4000 25 730 109
31 611 762 12 4.9 PH931_0060K513_0160 MB23 EZ404U 2570 – 5583 96.56 26071/270 8.0 8.0 2300 2200 3600 16 730 105
31 611 762 12 4.9 PH931_0060K513_0160 MB23 EZ404U 2570 – 5583 96.56 26071/270 12 8.0 2300 2200 3600 16 730 105
31 611 762 12 4.9 PH931_0060K513_0160 MB23 EZ404U 2570 – 5583 96.56 26071/270 16 8.0 2300 2200 3600 16 730 105
31 656 709 13 4.6 PH931_0060K513_0160 MB23 EZ502U 2747 – 5583 96.56 26071/270 8.0 8.0 2300 2200 3600 18 730 104
31 656 709 13 4.6 PH931_0060K513_0160 MB23 EZ502U 2747 – 5583 96.56 26071/270 12 8.0 2300 2200 3600 18 730 104
31 656 709 13 4.6 PH931_0060K513_0160 MB23 EZ502U 2747 – 5583 96.56 26071/270 16 8.0 2300 2200 3600 18 730 104
31 656 736 13 4.6 PH931_0060K513_0160 MB33 EZ701U 1772 – 9000 96.56 26071/270 16 15 2300 2200 3600 43 730 114
31 656 736 13 4.6 PH931_0060K513_0160 MB33 EZ701U 1772 – 9000 96.56 26071/270 24 15 2300 2200 3600 43 730 114
31 656 736 13 4.6 PH931_0060K513_0160 MB33 EZ701U 1772 – 9000 96.56 26071/270 32 15 2300 2200 3600 43 730 114
31 860 984 16 3.5 PH931_0060K513_0160 MB23 EZ503U 3323 – 5583 96.56 26071/270 8.0 15 2300 2200 3600 22 730 106
31 860 984 16 3.5 PH931_0060K513_0160 MB23 EZ503U 3323 – 5583 96.56 26071/270 12 15 2300 2200 3600 22 730 106
31 1063 1276 20 2.8 PH931_0060K513_0160 MB33 EZ702U 3633 – 9000 96.56 26071/270 16 15 2300 2200 3600 48 730 116
31 1063 1276 20 2.8 PH931_0060K513_0160 MB33 EZ702U 3633 – 9000 96.56 26071/270 24 15 2300 2200 3600 48 730 116
31 1063 1276 20 2.8 PH931_0060K513_0160 MB33 EZ702U 3633 – 9000 96.56 26071/270 32 15 2300 2200 3600 48 730 116
31 1196 1418 23 2.5 PH931_0060K513_0160 MB23 EZ505U 3323 – 5583 96.56 26071/270 8.0 15 2300 2200 3600 26 730 109
31 1196 1418 23 2.5 PH931_0060K513_0160 MB23 EZ505U 3323 – 5583 96.56 26071/270 12 15 2300 2200 3600 26 730 109
39 846 1016 19 3.5 PH931_0060K513_0130 MB33 EZ702U 2892 – 9000 76.85 1537/20 16 15 2300 2200 3600 50 730 116
39 846 1016 19 3.5 PH931_0060K513_0130 MB33 EZ702U 2892 – 9000 76.85 1537/20 24 15 2300 2200 3600 50 730 116
39 846 1016 19 3.5 PH931_0060K513_0130 MB33 EZ702U 2892 – 9000 76.85 1537/20 32 15 2300 2200 3600 50 730 116
39 846 1016 19 3.5 PH931_0060K513_0130 MB33 EZ702U 2892 – 9000 76.85 1537/20 45 15 2300 2200 3600 50 730 116
39 1164 1467 26 2.6 PH931_0060K513_0130 MB33 EZ703U 4500 – 9000 76.85 1537/20 16 32 2300 2200 3600 62 730 119
39 1164 1467 26 2.6 PH931_0060K513_0130 MB33 EZ703U 4500 – 9000 76.85 1537/20 24 32 2300 2200 3600 62 730 119
39 1502 2130 34 2.0 PH931_0060K513_0130 MB33 EZ705U 4500 – 9000 76.85 1537/20 16 32 2300 2200 3600 74 730 125
39 1502 2130 34 2.0 PH931_0060K513_0130 MB33 EZ705U 4500 – 9000 76.85 1537/20 24 32 2300 2200 3600 74 730 125
49 671 805 18 4.5 PH931_0060K513_0100 MB33 EZ702U 2292 – 9000 60.90 609/10 16 15 1900 1800 3200 53 730 116
49 671 805 18 4.5 PH931_0060K513_0100 MB33 EZ702U 2292 – 9000 60.90 609/10 24 15 1900 1800 3200 53 730 116
8.2 Selection tables 8 PHKright-angle planetary geared motors
