Stober PK - Page 235

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH931K (n
1N
= 3000 rpm, M
2acc,max
= 4500 Nm)
49 671 805 18 4.5 PH931_0060K513_0100 MB33 EZ702U 2292 – 9000 60.90 609/10 32 15 1900 1800 3200 53 730 116
49 671 805 18 4.5 PH931_0060K513_0100 MB33 EZ702U 2292 – 9000 60.90 609/10 45 15 1900 1800 3200 53 730 116
49 922 1163 24 3.3 PH931_0060K513_0100 MB33 EZ703U 3633 – 9000 60.90 609/10 16 32 1900 1800 3200 65 730 119
49 922 1163 24 3.3 PH931_0060K513_0100 MB33 EZ703U 3633 – 9000 60.90 609/10 24 32 1900 1800 3200 65 730 119
49 922 1163 24 3.3 PH931_0060K513_0100 MB33 EZ703U 3633 – 9000 60.90 609/10 32 32 1900 1800 3200 65 730 119
49 922 1163 24 3.3 PH931_0060K513_0100 MB33 EZ703U 3633 – 9000 60.90 609/10 45 32 1900 1800 3200 65 730 119
49 1190 1688 31 2.5 PH931_0060K513_0100 MB33 EZ705U 4500 – 9000 60.90 609/10 16 32 1900 1800 3200 78 730 125
49 1190 1688 31 2.5 PH931_0060K513_0100 MB33 EZ705U 4500 – 9000 60.90 609/10 24 32 1900 1800 3200 78 730 125
49 1190 1688 31 2.5 PH931_0060K513_0100 MB33 EZ705U 4500 – 9000 60.90 609/10 32 32 1900 1800 3200 78 730 125
49 1190 1688 31 2.5 PH931_0060K513_0100 MB33 EZ705U 4500 – 9000 60.90 609/10 45 32 1900 1800 3200 78 730 125
61 739 932 23 4.1 PH931_0060K513_0081 MB33 EZ703U 2911 – 8465 48.80 17081/350 16 32 1900 1800 3200 69 730 119
61 739 932 23 4.1 PH931_0060K513_0081 MB33 EZ703U 2911 – 8465 48.80 17081/350 24 32 1900 1800 3200 69 730 119
61 739 932 23 4.1 PH931_0060K513_0081 MB33 EZ703U 2911 – 8465 48.80 17081/350 32 32 1900 1800 3200 69 730 119
61 739 932 23 4.1 PH931_0060K513_0081 MB33 EZ703U 2911 – 8465 48.80 17081/350 45 32 1900 1800 3200 69 730 119
61 954 1353 29 3.1 PH931_0060K513_0081 MB33 EZ705U 4479 – 8465 48.80 17081/350 16 32 1900 1800 3200 82 730 125
61 954 1353 29 3.1 PH931_0060K513_0081 MB33 EZ705U 4479 – 8465 48.80 17081/350 24 32 1900 1800 3200 82 730 125
61 954 1353 29 3.1 PH931_0060K513_0081 MB33 EZ705U 4479 – 8465 48.80 17081/350 32 32 1900 1800 3200 82 730 125
61 954 1353 29 3.1 PH931_0060K513_0081 MB33 EZ705U 4479 – 8465 48.80 17081/350 45 32 1900 1800 3200 82 730 125
61 1191 2159 37 2.5 PH931_0060K513_0081 MB43 EZ803U 4500 – 9000 48.80 17081/350 50 65 1900 1800 3000 190 730 155
74 615 775 21 3.8 PH931_0040K513_0100 MB33 EZ703U 2422 – 7042 40.60 203/5 16 32 1900 1800 3200 66 525 119
74 615 775 21 3.8 PH931_0040K513_0100 MB33 EZ703U 2422 – 7042 40.60 203/5 24 32 1900 1800 3200 66 525 119
74 615 775 21 3.8 PH931_0040K513_0100 MB33 EZ703U 2422 – 7042 40.60 203/5 32 32 1900 1800 3200 66 525 119
74 615 775 21 3.8 PH931_0040K513_0100 MB33 EZ703U 2422 – 7042 40.60 203/5 45 32 1900 1800 3200 66 525 119
74 794 1125 27 3.0 PH931_0040K513_0100 MB33 EZ705U 3726 – 7042 40.60 203/5 16 32 1900 1800 3200 78 525 125
74 794 1125 27 3.0 PH931_0040K513_0100 MB33 EZ705U 3726 – 7042 40.60 203/5 24 32 1900 1800 3200 78 525 125
74 794 1125 27 3.0 PH931_0040K513_0100 MB33 EZ705U 3726 – 7042 40.60 203/5 32 32 1900 1800 3200 78 525 125
74 794 1125 27 3.0 PH931_0040K513_0100 MB33 EZ705U 3726 – 7042 40.60 203/5 45 32 1900 1800 3200 78 525 125
74 991 1796 33 2.4 PH931_0040K513_0100 MB43 EZ803U 3840 – 7500 40.60 203/5 50 65 1900 1800 3000 186 525 155
92 493 621 21 4.4 PH931_0040K513_0081 MB33 EZ703U 1941 – 5644 32.54 17081/525 16 32 1900 1800 3200 70 525 119
92 493 621 21 4.4 PH931_0040K513_0081 MB33 EZ703U 1941 – 5644 32.54 17081/525 24 32 1900 1800 3200 70 525 119
92 493 621 21 4.4 PH931_0040K513_0081 MB33 EZ703U 1941 – 5644 32.54 17081/525 32 32 1900 1800 3200 70 525 119
92 493 621 21 4.4 PH931_0040K513_0081 MB33 EZ703U 1941 – 5644 32.54 17081/525 45 32 1900 1800 3200 70 525 119
92 636 902 27 3.4 PH931_0040K513_0081 MB33 EZ705U 2986 – 5644 32.54 17081/525 16 32 1900 1800 3200 82 525 125
92 636 902 27 3.4 PH931_0040K513_0081 MB33 EZ705U 2986 – 5644 32.54 17081/525 24 32 1900 1800 3200 82 525 125
92 636 902 27 3.4 PH931_0040K513_0081 MB33 EZ705U 2986 – 5644 32.54 17081/525 32 32 1900 1800 3200 82 525 125
92 636 902 27 3.4 PH931_0040K513_0081 MB33 EZ705U 2986 – 5644 32.54 17081/525 45 32 1900 1800 3200 82 525 125
92 794 1439 33 2.8 PH931_0040K513_0081 MB43 EZ803U 3840 – 7500 32.54 17081/525 50 65 1900 1800 3000 190 525 155
92 794 1439 33 2.8 PH931_0040K513_0081 MB43 EZ803U 3840 – 7500 32.54 17081/525 72 65 1900 1800 3000 190 525 155
PH1031K (n
1N
= 2000 rpm, M
2acc,max
= 7500 Nm)
41 1951 2951 40 2.5 PH1031_0060K613_0081 MB43 EZ805U 7500 – 15000 48.64 255285/5248 50 115 1800 1700 3000 291 1210 216
PH1031K (n
1N
= 3000 rpm, M
2acc,max
= 7500 Nm)
6.6 1803 1971 7.6 2.8 PH1031_0060K613_0760 MB23 EZ501U 6708 – 15000 456.8 380091/832 8.0 8.0 3100 2800 4000 11 1210 147
6.6 1971 2180 8.4 2.5 PH1031_0060K613_0760 MB23 EZ402U 6708 – 15000 456.8 380091/832 8.0 8.0 3100 2800 4000 9.8 1210 147
6.6 2893 3606 12 1.7 PH1031_0060K613_0760 MB23 EZ404U 7500 – 15000 456.8 380091/832 8.0 8.0 3100 2800 4000 11 1210 149
6.6 3103 3354 13 1.6 PH1031_0060K613_0760 MB23 EZ502U 7500 – 15000 456.8 380091/832 8.0 8.0 3100 2800 4000 13 1210 149
7.8 1509 1649 7.2 3.3 PH1031_0060K613_0640 MB23 EZ501U 5613 – 15000 382.3 391437/1024 8.0 8.0 3100 2800 4000 11 1210 147
7.8 1509 1649 7.2 3.3 PH1031_0060K613_0640 MB23 EZ501U 5613 – 15000 382.3 391437/1024 12 8.0 3100 2800 4000 11 1210 147
7.8 1649 1824 7.9 3.0 PH1031_0060K613_0640 MB23 EZ402U 5613 – 15000 382.3 391437/1024 8.0 8.0 3100 2800 4000 10 1210 147
7.8 1649 1824 7.9 3.0 PH1031_0060K613_0640 MB23 EZ402U 5613 – 15000 382.3 391437/1024 12 8.0 3100 2800 4000 10 1210 147
7.8 2421 3017 12 2.1 PH1031_0060K613_0640 MB23 EZ404U 7500 – 15000 382.3 391437/1024 8.0 8.0 3100 2800 4000 11 1210 149
7.8 2421 3017 12 2.1 PH1031_0060K613_0640 MB23 EZ404U 7500 – 15000 382.3 391437/1024 12 8.0 3100 2800 4000 11 1210 149
7.8 2596 2807 12 1.9 PH1031_0060K613_0640 MB23 EZ502U 7500 – 15000 382.3 391437/1024 8.0 8.0 3100 2800 4000 14 1210 149
7.8 2596 2807 12 1.9 PH1031_0060K613_0640 MB23 EZ502U 7500 – 15000 382.3 391437/1024 12 8.0 3100 2800 4000 14 1210 149
10 1130 1235 6.6 4.4 PH1031_0060K613_0480 MB23 EZ501U 4205 – 15000 286.4 119133/416 8.0 8.0 3100 2800 4000 12 1210 147
10 1130 1235 6.6 4.4 PH1031_0060K613_0480 MB23 EZ501U 4205 – 15000 286.4 119133/416 12 8.0 3100 2800 4000 12 1210 147
10 1130 1235 6.6 4.4 PH1031_0060K613_0480 MB23 EZ501U 4205 – 15000 286.4 119133/416 16 8.0 3100 2800 4000 12 1210 147
10 1235 1367 7.3 4.0 PH1031_0060K613_0480 MB23 EZ402U 4205 – 15000 286.4 119133/416 8.0 8.0 3100 2800 4000 11 1210 147
10 1235 1367 7.3 4.0 PH1031_0060K613_0480 MB23 EZ402U 4205 – 15000 286.4 119133/416 12 8.0 3100 2800 4000 11 1210 147
10 1235 1367 7.3 4.0 PH1031_0060K613_0480 MB23 EZ402U 4205 – 15000 286.4 119133/416 16 8.0 3100 2800 4000 11 1210 147
10 1814 2260 11 2.8 PH1031_0060K613_0480 MB23 EZ404U 7500 – 15000 286.4 119133/416 8.0 8.0 3100 2800 4000 12 1210 149
10 1814 2260 11 2.8 PH1031_0060K613_0480 MB23 EZ404U 7500 – 15000 286.4 119133/416 12 8.0 3100 2800 4000 12 1210 149
10 1814 2260 11 2.8 PH1031_0060K613_0480 MB23 EZ404U 7500 – 15000 286.4 119133/416 16 8.0 3100 2800 4000 12 1210 149
10 1945 2103 11 2.6 PH1031_0060K613_0480 MB23 EZ502U 7500 – 15000 286.4 119133/416 8.0 8.0 3100 2800 4000 14 1210 149
10 1945 2103 11 2.6 PH1031_0060K613_0480 MB23 EZ502U 7500 – 15000 286.4 119133/416 12 8.0 3100 2800 4000 14 1210 149
8 PHKright-angle planetary geared motors 8.2 Selection tables
