Stober PK - Page 236

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH1031K (n
1N
= 3000 rpm, M
2acc,max
= 7500 Nm)
10 1945 2103 11 2.6 PH1031_0060K613_0480 MB23 EZ502U 7500 – 15000 286.4 119133/416 16 8.0 3100 2800 4000 14 1210 149
10 2549 2917 15 2.0 PH1031_0060K613_0480 MB23 EZ503U 7500 – 15000 286.4 119133/416 8.0 15 3100 2800 4000 18 1210 151
10 2549 2917 15 2.0 PH1031_0060K613_0480 MB23 EZ503U 7500 – 15000 286.4 119133/416 12 15 3100 2800 4000 18 1210 151
10 3548 4205 21 1.4 PH1031_0060K613_0480 MB23 EZ505U 7500 – 15000 286.4 119133/416 8.0 15 3100 2800 4000 23 1210 154
10 3548 4205 21 1.4 PH1031_0060K613_0480 MB23 EZ505U 7500 – 15000 286.4 119133/416 12 15 3100 2800 4000 23 1210 154
13 1456 1815 10 3.4 PH1031_0060K613_0380 MB23 EZ404U 6119 – 13293 229.9 470859/2048 8.0 8.0 3100 2800 4000 13 1210 149
13 1456 1815 10 3.4 PH1031_0060K613_0380 MB23 EZ404U 6119 – 13293 229.9 470859/2048 12 8.0 3100 2800 4000 13 1210 149
13 1456 1815 10 3.4 PH1031_0060K613_0380 MB23 EZ404U 6119 – 13293 229.9 470859/2048 16 8.0 3100 2800 4000 13 1210 149
13 1561 1688 11 3.2 PH1031_0060K613_0380 MB23 EZ502U 6541 – 13293 229.9 470859/2048 8.0 8.0 3100 2800 4000 15 1210 149
13 1561 1688 11 3.2 PH1031_0060K613_0380 MB23 EZ502U 6541 – 13293 229.9 470859/2048 12 8.0 3100 2800 4000 15 1210 149
13 1561 1688 11 3.2 PH1031_0060K613_0380 MB23 EZ502U 6541 – 13293 229.9 470859/2048 16 8.0 3100 2800 4000 15 1210 149
13 1561 1751 11 3.2 PH1031_0060K613_0380 MB33 EZ701U 4220 – 15000 229.9 470859/2048 16 15 3100 2800 4000 40 1210 158
13 2047 2342 14 2.4 PH1031_0060K613_0380 MB23 EZ503U 7500 – 13293 229.9 470859/2048 8.0 15 3100 2800 4000 19 1210 151
13 2047 2342 14 2.4 PH1031_0060K613_0380 MB23 EZ503U 7500 – 13293 229.9 470859/2048 12 15 3100 2800 4000 19 1210 151
13 2532 3038 17 2.0 PH1031_0060K613_0380 MB33 EZ702U 7500 – 15000 229.9 470859/2048 16 15 3100 2800 4000 45 1210 161
13 2849 3376 20 1.8 PH1031_0060K613_0380 MB23 EZ505U 7500 – 13293 229.9 470859/2048 8.0 15 3100 2800 4000 23 1210 154
13 2849 3376 20 1.8 PH1031_0060K613_0380 MB23 EZ505U 7500 – 13293 229.9 470859/2048 12 15 3100 2800 4000 23 1210 154
16 1210 1509 9.4 4.1 PH1031_0060K613_0320 MB23 EZ404U 5087 – 11051 191.1 391437/2048 8.0 8.0 3100 2800 4000 14 1210 149
16 1210 1509 9.4 4.1 PH1031_0060K613_0320 MB23 EZ404U 5087 – 11051 191.1 391437/2048 12 8.0 3100 2800 4000 14 1210 149
16 1210 1509 9.4 4.1 PH1031_0060K613_0320 MB23 EZ404U 5087 – 11051 191.1 391437/2048 16 8.0 3100 2800 4000 14 1210 149
16 1298 1403 10 3.9 PH1031_0060K613_0320 MB23 EZ502U 5438 – 11051 191.1 391437/2048 8.0 8.0 3100 2800 4000 16 1210 149
16 1298 1403 10 3.9 PH1031_0060K613_0320 MB23 EZ502U 5438 – 11051 191.1 391437/2048 12 8.0 3100 2800 4000 16 1210 149
16 1298 1403 10 3.9 PH1031_0060K613_0320 MB23 EZ502U 5438 – 11051 191.1 391437/2048 16 8.0 3100 2800 4000 16 1210 149
16 1298 1456 10 3.9 PH1031_0060K613_0320 MB33 EZ701U 3508 – 15000 191.1 391437/2048 16 15 3100 2800 4000 41 1210 158
16 1298 1456 10 3.9 PH1031_0060K613_0320 MB33 EZ701U 3508 – 15000 191.1 391437/2048 24 15 3100 2800 4000 41 1210 158
16 1701 1947 13 2.9 PH1031_0060K613_0320 MB23 EZ503U 6578 – 11051 191.1 391437/2048 8.0 15 3100 2800 4000 20 1210 151
16 1701 1947 13 2.9 PH1031_0060K613_0320 MB23 EZ503U 6578 – 11051 191.1 391437/2048 12 15 3100 2800 4000 20 1210 151
16 2105 2526 16 2.4 PH1031_0060K613_0320 MB33 EZ702U 7192 – 15000 191.1 391437/2048 16 15 3100 2800 4000 46 1210 161
16 2105 2526 16 2.4 PH1031_0060K613_0320 MB33 EZ702U 7192 – 15000 191.1 391437/2048 24 15 3100 2800 4000 46 1210 161
16 2368 2807 18 2.1 PH1031_0060K613_0320 MB23 EZ505U 6578 – 11051 191.1 391437/2048 8.0 15 3100 2800 4000 24 1210 154
16 2368 2807 18 2.1 PH1031_0060K613_0320 MB23 EZ505U 6578 – 11051 191.1 391437/2048 12 15 3100 2800 4000 24 1210 154
21 1586 1904 15 3.2 PH1031_0060K613_0240 MB33 EZ702U 5420 – 15000 144.0 73749/512 16 15 2600 2300 4000 48 1210 161
21 1586 1904 15 3.2 PH1031_0060K613_0240 MB33 EZ702U 5420 – 15000 144.0 73749/512 24 15 2600 2300 4000 48 1210 161
21 1586 1904 15 3.2 PH1031_0060K613_0240 MB33 EZ702U 5420 – 15000 144.0 73749/512 32 15 2600 2300 4000 48 1210 161
21 2181 2750 21 2.3 PH1031_0060K613_0240 MB33 EZ703U 7500 – 15000 144.0 73749/512 16 32 2600 2300 4000 60 1210 164
21 2816 3992 27 1.8 PH1031_0060K613_0240 MB33 EZ705U 7500 – 15000 144.0 73749/512 16 32 2600 2300 4000 73 1210 169
26 1015 1161 14 3.9 PH1031_0060K613_0190 MB23 EZ503U 3922 – 6589 114.0 51057/448 8.0 15 2600 2300 4000 24 1210 151
26 1015 1161 14 3.9 PH1031_0060K613_0190 MB23 EZ503U 3922 – 6589 114.0 51057/448 12 15 2600 2300 4000 24 1210 151
26 1255 1506 14 4.0 PH1031_0060K613_0190 MB33 EZ702U 4288 – 15000 114.0 51057/448 16 15 2600 2300 4000 51 1210 161
26 1255 1506 14 4.0 PH1031_0060K613_0190 MB33 EZ702U 4288 – 15000 114.0 51057/448 24 15 2600 2300 4000 51 1210 161
26 1255 1506 14 4.0 PH1031_0060K613_0190 MB33 EZ702U 4288 – 15000 114.0 51057/448 32 15 2600 2300 4000 51 1210 161
26 1255 1506 14 4.0 PH1031_0060K613_0190 MB33 EZ702U 4288 – 15000 114.0 51057/448 45 15 2600 2300 4000 51 1210 161
26 1412 1673 20 2.8 PH1031_0060K613_0190 MB23 EZ505U 3922 – 6589 114.0 51057/448 8.0 15 2600 2300 4000 28 1210 154
26 1412 1673 20 2.8 PH1031_0060K613_0190 MB23 EZ505U 3922 – 6589 114.0 51057/448 12 15 2600 2300 4000 28 1210 154
26 1726 2176 19 2.9 PH1031_0060K613_0190 MB33 EZ703U 6798 – 15000 114.0 51057/448 16 32 2600 2300 4000 62 1210 164
26 1726 2176 19 2.9 PH1031_0060K613_0190 MB33 EZ703U 6798 – 15000 114.0 51057/448 24 32 2600 2300 4000 62 1210 164
26 1726 2176 19 2.9 PH1031_0060K613_0190 MB33 EZ703U 6798 – 15000 114.0 51057/448 32 32 2600 2300 4000 62 1210 164
26 2228 3159 25 2.2 PH1031_0060K613_0190 MB33 EZ705U 7500 – 15000 114.0 51057/448 16 32 2600 2300 4000 75 1210 169
26 2228 3159 25 2.2 PH1031_0060K613_0190 MB33 EZ705U 7500 – 15000 114.0 51057/448 24 32 2600 2300 4000 75 1210 169
26 2228 3159 25 2.2 PH1031_0060K613_0190 MB33 EZ705U 7500 – 15000 114.0 51057/448 32 32 2600 2300 4000 75 1210 169
32 1049 1258 13 4.8 PH1031_0060K613_0160 MB33 EZ702U 3583 – 15000 95.21 54839/576 16 15 2200 2000 3500 53 1210 161
32 1049 1258 13 4.8 PH1031_0060K613_0160 MB33 EZ702U 3583 – 15000 95.21 54839/576 24 15 2200 2000 3500 53 1210 161
32 1049 1258 13 4.8 PH1031_0060K613_0160 MB33 EZ702U 3583 – 15000 95.21 54839/576 32 15 2200 2000 3500 53 1210 161
32 1049 1258 13 4.8 PH1031_0060K613_0160 MB33 EZ702U 3583 – 15000 95.21 54839/576 45 15 2200 2000 3500 53 1210 161
32 1442 1817 18 3.5 PH1031_0060K613_0160 MB33 EZ703U 5680 – 15000 95.21 54839/576 16 32 2200 2000 3500 65 1210 164
32 1442 1817 18 3.5 PH1031_0060K613_0160 MB33 EZ703U 5680 – 15000 95.21 54839/576 24 32 2200 2000 3500 65 1210 164
32 1442 1817 18 3.5 PH1031_0060K613_0160 MB33 EZ703U 5680 – 15000 95.21 54839/576 32 32 2200 2000 3500 65 1210 164
32 1442 1817 18 3.5 PH1031_0060K613_0160 MB33 EZ703U 5680 – 15000 95.21 54839/576 45 32 2200 2000 3500 65 1210 164
32 1861 2639 24 2.7 PH1031_0060K613_0160 MB33 EZ705U 7500 – 15000 95.21 54839/576 16 32 2200 2000 3500 77 1210 169
32 1861 2639 24 2.7 PH1031_0060K613_0160 MB33 EZ705U 7500 – 15000 95.21 54839/576 24 32 2200 2000 3500 77 1210 169
32 1861 2639 24 2.7 PH1031_0060K613_0160 MB33 EZ705U 7500 – 15000 95.21 54839/576 32 32 2200 2000 3500 77 1210 169
32 1861 2639 24 2.7 PH1031_0060K613_0160 MB33 EZ705U 7500 – 15000 95.21 54839/576 45 32 2200 2000 3500 77 1210 169
40 1147 1446 17 4.4 PH1031_0060K613_0125 MB33 EZ703U 4520 – 13144 75.77 9699/128 16 32 2200 2000 3500 69 1210 164
40 1147 1446 17 4.4 PH1031_0060K613_0125 MB33 EZ703U 4520 – 13144 75.77 9699/128 24 32 2200 2000 3500 69 1210 164
8.2 Selection tables 8 PHKright-angle planetary geared motors
236
