Stober PK - Page 273

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PHQ1131K (n
1N
= 2000 rpm, M
2acc,max
= 22000 Nm)
20 3954 5981 22 3.3 PHQ1131_0060K813_0165 MB43 EZ805U 18549 – 30403 98.59 126201/1280 50 115 1900 1800 3000 310 2623 373
22 3572 5402 22 3.6 PHQ1131_0060K813_0150 MB43 EZ805U 16754 – 27461 89.05 28497/320 50 115 1900 1800 3000 314 2623 373
32 2474 3741 22 4.6 PHQ1131_0060K813_0105 MB43 EZ805U 11603 – 19018 61.67 53041/860 50 115 1600 1500 2600 358 2623 373
36 2234 3379 24 4.6 PHQ1131_0060K813_0093 MB43 EZ805U 10480 – 17177 55.70 11977/215 50 115 1600 1500 2600 367 2623 373
40 1984 3000 26 4.6 PHQ1131_0060K813_0082 MB43 EZ805U 9305 – 15251 49.46 96937/1960 50 115 1600 1500 2600 395 2623 373
45 1792 2710 28 4.6 PHQ1131_0060K813_0074 MB43 EZ805U 8404 – 13775 44.67 3127/70 50 115 1600 1500 2600 409 2623 373
PHQ1131K (n
1N
= 3000 rpm, M
2acc,max
= 22000 Nm)
5.1 3959 4441 6.4 3.3 PHQ1131_0060K813_0970 MB33 EZ701U 10701 – 38819 583.0 93279/160 16 15 2800 2500 4000 40 2623 315
5.1 6421 7705 10 2.0 PHQ1131_0060K813_0970 MB33 EZ702U 21465 – 38819 583.0 93279/160 16 15 2800 2500 4000 45 2623 318
5.7 3576 4011 6.2 3.6 PHQ1131_0060K813_0880 MB33 EZ701U 9665 – 35060 526.6 21063/40 16 15 2800 2500 4000 40 2623 315
5.7 5799 6959 10 2.2 PHQ1131_0060K813_0880 MB33 EZ702U 19387 – 35060 526.6 21063/40 16 15 2800 2500 4000 46 2623 318
6.3 3235 3628 6.1 4.0 PHQ1131_0060K813_0790 MB33 EZ701U 8743 – 44000 476.3 45725/96 16 15 2800 2500 4000 41 2623 315
6.3 3235 3628 6.1 4.0 PHQ1131_0060K813_0790 MB33 EZ701U 8743 – 44000 476.3 45725/96 24 15 2800 2500 4000 41 2623 315
6.3 3235 3628 6.1 4.0 PHQ1131_0060K813_0790 MB33 EZ701U 8743 – 44000 476.3 45725/96 32 15 2800 2500 4000 41 2623 315
6.3 5246 6295 9.8 2.5 PHQ1131_0060K813_0790 MB33 EZ702U 17922 – 44000 476.3 45725/96 16 15 2800 2500 4000 47 2623 318
6.3 5246 6295 9.8 2.5 PHQ1131_0060K813_0790 MB33 EZ702U 17922 – 44000 476.3 45725/96 24 15 2800 2500 4000 47 2623 318
6.3 5246 6295 9.8 2.5 PHQ1131_0060K813_0790 MB33 EZ702U 17922 – 44000 476.3 45725/96 32 15 2800 2500 4000 47 2623 318
7.0 2922 3277 5.9 4.4 PHQ1131_0060K813_0720 MB33 EZ701U 7897 – 44000 430.2 10325/24 16 15 2800 2500 4000 42 2623 315
7.0 2922 3277 5.9 4.4 PHQ1131_0060K813_0720 MB33 EZ701U 7897 – 44000 430.2 10325/24 24 15 2800 2500 4000 42 2623 315
7.0 2922 3277 5.9 4.4 PHQ1131_0060K813_0720 MB33 EZ701U 7897 – 44000 430.2 10325/24 32 15 2800 2500 4000 42 2623 315
7.0 4738 5685 9.5 2.7 PHQ1131_0060K813_0720 MB33 EZ702U 16188 – 44000 430.2 10325/24 16 15 2800 2500 4000 47 2623 318
7.0 4738 5685 9.5 2.7 PHQ1131_0060K813_0720 MB33 EZ702U 16188 – 44000 430.2 10325/24 24 15 2800 2500 4000 47 2623 318
7.0 4738 5685 9.5 2.7 PHQ1131_0060K813_0720 MB33 EZ702U 16188 – 44000 430.2 10325/24 32 15 2800 2500 4000 47 2623 318
7.0 6515 8212 13 2.0 PHQ1131_0060K813_0720 MB33 EZ703U 22000 – 44000 430.2 10325/24 16 32 2800 2500 4000 59 2623 320
7.0 8410 11924 17 1.5 PHQ1131_0060K813_0720 MB33 EZ705U 22000 – 44000 430.2 10325/24 16 32 2800 2500 4000 71 2623 326
7.6 2665 2990 5.7 4.9 PHQ1131_0060K813_0650 MB33 EZ701U 7204 – 44000 392.5 188387/480 16 15 2800 2500 4000 43 2623 315
7.6 2665 2990 5.7 4.9 PHQ1131_0060K813_0650 MB33 EZ701U 7204 – 44000 392.5 188387/480 24 15 2800 2500 4000 43 2623 315
7.6 2665 2990 5.7 4.9 PHQ1131_0060K813_0650 MB33 EZ701U 7204 – 44000 392.5 188387/480 32 15 2800 2500 4000 43 2623 315
7.6 2665 2990 5.7 4.9 PHQ1131_0060K813_0650 MB33 EZ701U 7204 – 44000 392.5 188387/480 45 15 2800 2500 4000 43 2623 315
7.6 4322 5187 9.3 3.0 PHQ1131_0060K813_0650 MB33 EZ702U 14768 – 44000 392.5 188387/480 16 15 2800 2500 4000 48 2623 318
7.6 4322 5187 9.3 3.0 PHQ1131_0060K813_0650 MB33 EZ702U 14768 – 44000 392.5 188387/480 24 15 2800 2500 4000 48 2623 318
7.6 4322 5187 9.3 3.0 PHQ1131_0060K813_0650 MB33 EZ702U 14768 – 44000 392.5 188387/480 32 15 2800 2500 4000 48 2623 318
7.6 4322 5187 9.3 3.0 PHQ1131_0060K813_0650 MB33 EZ702U 14768 – 44000 392.5 188387/480 45 15 2800 2500 4000 48 2623 318
7.6 5943 7492 13 2.2 PHQ1131_0060K813_0650 MB33 EZ703U 22000 – 44000 392.5 188387/480 16 32 2800 2500 4000 60 2623 320
7.6 5943 7492 13 2.2 PHQ1131_0060K813_0650 MB33 EZ703U 22000 – 44000 392.5 188387/480 24 32 2800 2500 4000 60 2623 320
7.6 7672 10878 16 1.7 PHQ1131_0060K813_0650 MB33 EZ705U 22000 – 44000 392.5 188387/480 16 32 2800 2500 4000 72 2623 326
7.6 7672 10878 16 1.7 PHQ1131_0060K813_0650 MB33 EZ705U 22000 – 44000 392.5 188387/480 24 32 2800 2500 4000 72 2623 326
8.5 3904 4685 9.0 3.3 PHQ1131_0060K813_0590 MB33 EZ702U 13339 – 44000 354.5 42539/120 16 15 2800 2500 4000 48 2623 318
8.5 3904 4685 9.0 3.3 PHQ1131_0060K813_0590 MB33 EZ702U 13339 – 44000 354.5 42539/120 24 15 2800 2500 4000 48 2623 318
8.5 3904 4685 9.0 3.3 PHQ1131_0060K813_0590 MB33 EZ702U 13339 – 44000 354.5 42539/120 32 15 2800 2500 4000 48 2623 318
8.5 3904 4685 9.0 3.3 PHQ1131_0060K813_0590 MB33 EZ702U 13339 – 44000 354.5 42539/120 45 15 2800 2500 4000 48 2623 318
8.5 5368 6767 12 2.4 PHQ1131_0060K813_0590 MB33 EZ703U 21147 – 44000 354.5 42539/120 16 32 2800 2500 4000 60 2623 320
8.5 5368 6767 12 2.4 PHQ1131_0060K813_0590 MB33 EZ703U 21147 – 44000 354.5 42539/120 24 32 2800 2500 4000 60 2623 320
8.5 5368 6767 12 2.4 PHQ1131_0060K813_0590 MB33 EZ703U 21147 – 44000 354.5 42539/120 32 32 2800 2500 4000 60 2623 320
8.5 6930 9825 16 1.9 PHQ1131_0060K813_0590 MB33 EZ705U 22000 – 44000 354.5 42539/120 16 32 2800 2500 4000 73 2623 326
8.5 6930 9825 16 1.9 PHQ1131_0060K813_0590 MB33 EZ705U 22000 – 44000 354.5 42539/120 24 32 2800 2500 4000 73 2623 326
8.5 6930 9825 16 1.9 PHQ1131_0060K813_0590 MB33 EZ705U 22000 – 44000 354.5 42539/120 32 32 2800 2500 4000 73 2623 326
10 3237 3885 8.5 4.0 PHQ1131_0060K813_0490 MB33 EZ702U 11061 – 44000 293.9 16461/56 16 15 2800 2500 4000 52 2623 318
10 3237 3885 8.5 4.0 PHQ1131_0060K813_0490 MB33 EZ702U 11061 – 44000 293.9 16461/56 24 15 2800 2500 4000 52 2623 318
10 3237 3885 8.5 4.0 PHQ1131_0060K813_0490 MB33 EZ702U 11061 – 44000 293.9 16461/56 32 15 2800 2500 4000 52 2623 318
10 3237 3885 8.5 4.0 PHQ1131_0060K813_0490 MB33 EZ702U 11061 – 44000 293.9 16461/56 45 15 2800 2500 4000 52 2623 318
10 4451 5611 12 2.9 PHQ1131_0060K813_0490 MB33 EZ703U 17535 – 44000 293.9 16461/56 16 32 2800 2500 4000 63 2623 320
10 4451 5611 12 2.9 PHQ1131_0060K813_0490 MB33 EZ703U 17535 – 44000 293.9 16461/56 24 32 2800 2500 4000 63 2623 320
10 4451 5611 12 2.9 PHQ1131_0060K813_0490 MB33 EZ703U 17535 – 44000 293.9 16461/56 32 32 2800 2500 4000 63 2623 320
10 4451 5611 12 2.9 PHQ1131_0060K813_0490 MB33 EZ703U 17535 – 44000 293.9 16461/56 45 32 2800 2500 4000 63 2623 320
10 5746 8147 15 2.3 PHQ1131_0060K813_0490 MB33 EZ705U 22000 – 44000 293.9 16461/56 16 32 2800 2500 4000 76 2623 326
10 5746 8147 15 2.3 PHQ1131_0060K813_0490 MB33 EZ705U 22000 – 44000 293.9 16461/56 24 32 2800 2500 4000 76 2623 326
10 5746 8147 15 2.3 PHQ1131_0060K813_0490 MB33 EZ705U 22000 – 44000 293.9 16461/56 32 32 2800 2500 4000 76 2623 326
10 5746 8147 15 2.3 PHQ1131_0060K813_0490 MB33 EZ705U 22000 – 44000 293.9 16461/56 45 32 2800 2500 4000 76 2623 326
11 2924 3509 8.2 4.4 PHQ1131_0060K813_0440 MB33 EZ702U 9990 – 44000 265.5 531/2 16 15 2800 2500 4000 52 2623 318
11 2924 3509 8.2 4.4 PHQ1131_0060K813_0440 MB33 EZ702U 9990 – 44000 265.5 531/2 24 15 2800 2500 4000 52 2623 318
11 2924 3509 8.2 4.4 PHQ1131_0060K813_0440 MB33 EZ702U 9990 – 44000 265.5 531/2 32 15 2800 2500 4000 52 2623 318
11 2924 3509 8.2 4.4 PHQ1131_0060K813_0440 MB33 EZ702U 9990 – 44000 265.5 531/2 45 15 2800 2500 4000 52 2623 318
11 4020 5068 11 3.2 PHQ1131_0060K813_0440 MB33 EZ703U 15838 – 44000 265.5 531/2 16 32 2800 2500 4000 64 2623 320
9 PHQKright-angle planetary geared motors 9.2 Selection tables
273
